Page 1: Cover
OWNER’S MANUAL STANDARD 110 PREMIUM 110 TURBO 220 Manufactured by InnovaSpa 1-819-850-0408 www.innovaspa.ca www.innovaspa.com... -
Page 2: Table Of Contents
TABLE OF CONTENTS COVER ------------------------------------------------------- TABLE OF CONTENTS ------------------------------------------------------- IMPORTANT SAFETY INSTRUCTIONS ------------------------------------------------------- ------------------------------------------------------- ------------------------------------------------------- SPA SPECIFICATIONS ------------------------------------------------------- INSTALLATION & QUICK START UP GUIDE ------------------------------------------------------- ------------------------------------------------------- OZONE GENERATOR INSTALLATION ------------------------------------------------------- PERSISTENT MEMORY RESET ------------------------------------------------------- OPERATING THE SPA CONTROLS ------------------------------------------------------- ROUTINE MAINTENANCE ------------------------------------------------------- WINTERIZING YOUR SPA -------------------------------------------------------... -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS THIS OWNER’S MANUAL CONTAINS IMPORTANT SAFETY INSTRUCTIONS READ AND FOLLOW ALL INSTRUCTIONS CAREFULLY “KEEP THESE INSTRUCTIONS” Most cities, counties, states/provinces and countries require permits for exterior construction and electrical circuits. In addition, some communities have safety codes requiring the property to be equipped with residential barriers such as fencing and/or self closing gates to prevent unsupervised access by children to pools or hot tubs. - Page 4 IMPORTANT SAFETY INSTRUCTIONS READ AND FOLLOW ALL INSTRUCTIONS CAREFULLY When installing and using this equipment, basic safety precautions should always be followed Risk of Accidental Drowning – Extreme caution must be exercised to prevent unauthorized access by children. To avoid accidents, ensure that children cannot use or approach the spa unless they are supervised at all times. Risk of Serious Injury or Death –...
-
Page 5: Read And Follow All Instructions Carefully
IMPORTANT SAFETY INSTRUCTIONS READ AND FOLLOW ALL INSTRUCTIONS CAREFULLY When installing and using this equipment, basic safety precautions should always be followed WARNING: Children should not use spas or hot tubs without adult supervision. AVERTISSEMENT: NE PAS LAISSER LES ENFANTS UTILISER UNE CUVE DE RELAXATION SANS SURVEILLANCE. -
Page 6: Spa Specifications
SPECIFICATIONS Thank you for choosing Urbania from InnovaSpa. Follow the instructions in this owner’s manual for safe and proper operation of your spa and for many years of therapy, relaxation and enjoyment. Urbania is available in three models. Individual specifications for each model are listed below. -
Page 7: Installation & Quick Start Up Guide
INSTALLATION AND QUICK START UP GUIDE Follow these instructions for quick and easy start up of your new InnovaSpa. If you have questions concerning start up, contact your dealer or InnovaSpa directly for help. OUTDOOR INSTALLATION If you are going to install your spa outdoors, select a solid, level surface to place it on. The bottom of your spa is totally protected and it will not rot. - Page 8 CIRCUIT BOARD “DIP” SWITCH CONFIGURATION Position 110 Volt Position 220 Volt DIP # DIP # Fig 1 Fig 2 4 To fill your spa, remove the filter cover and the filter cartridge by turning it counter clockwise. If your source water contains metals, such as iron, it is recommended that you attach a pre filter to your garden hose.
-
Page 9: Ozone Generator Installation
OZONE GENERATOR RETROFIT INSTALLATION The Standard 110 and Premium 110 models of the Urbania spa are manufactured with “Ozone Ready” plumbing. If you want to install an ozone generator on either of these models, follow the instructions below. The ozone generator to be installed must be 110 volt and approved for use on residential spas. The electrical cord must have an amp style, 4 pin, male connector with wire locations as follows;... -
Page 10: Operating The Spa Controls
OPERATING THE SPA CONTROLS PUMP OPERATION The spa pump will operate at two different speeds. This enables you to control the intensity of the spa jets. To change the pump speed, simply depress the jets icon on the top side control. The icon has three positions. -
Page 11: Routine Maintenance
ROUTINE MAINTENANCE Your spa will require periodic maintenance to ensure that you maintain clean and healthy water, a safe spa and a clean and healthy spa environment. By performing regular maintenance, your spa will provide you with many trouble free years of therapy and enjoyment. FILTER Your spa contains a filter cartridge that was designed to trap and remove particles and debris from the spa water. -
Page 12: Winterizing Your Spa
COVER MAINTENANCE To clean the outer surfaces of your cover, use a mild detergent, warm water and a soft brush or cloth. Thoroughly rinse the cover after you have cleaned it. Never use cleaners that contain harsh abrasives or rubbing and buffing compounds. -
Page 13: Understanding Spa Chemicals
UNDERSTANDING SPA CHEMICALS AND HOW THEY ARE USED As a new spa owner, it is very important that you learn and understand how to keep your spa water, and your spa, clean and healthy. This short guide was designed to give you a basic explanation of the most common chemicals used in spas and when they are needed. - Page 14 SPECIALTY CHEMICALS Specialty chemicals address occasional water problems and help to maintain clean, clear water when a spa is heavily used. Whether you will or should use these chemicals will be based on the quality of your source water and how frequently your spa is used. Following is a summary of the most common specialty chemicals and when they should be used.
- Page 15 BROMINE Bromine is a sanitizer that is best suited for use in spas. Unlike chlorine, bromine’s effectiveness is not sharply reduced as pH rises. As chlorine produces byproducts called chloramines, Bromine’s byproduct is called a bromamine. Unlike a chloramine, a bromamine is still an effective sanitizer and it does not create unpleasant odors.
-
Page 16: Troubleshooting
TROUBLESHOOTING If you are experiencing an operating problem, it is recommended that you contact your spa dealer or a qualified repair technician to arrange servicing. Some problems can be diagnosed and rectified with a simple action or procedure. Below are some common problems, possible causes and simple actions that may help to solve them. THE CIRCUIT BREAKER IMMEDIATELY TRIPS WHEN THE SPA IS STARTED. -
Page 17: Diagnostic Messages
DIAGNOSTIC MESSAGES Message Meaning Action Required No message on display. Power has been The control panel will be disabled until power returns. cut off to the spa. Spa settings will be preserved until next start up. Temperature unknown. After the pump has been running for 2 minutes, the -- -- temperature will be displayed. -
Page 18: Component Identification
COMPONENT IDENTIFICATION COMPONENT MANUFACTURER MODEL NUMBER PART NUMBER Equipment Pack Balboa VS300L4 54626-01 Top Side Control Balboa VL406U 55350 UL 1.5 HPR 25 Pump 1.5hpr, 2 Speed Balboa 1014250 14 FT A2 LV60HZ UM GE 4.0 HPR Pump 4.0hpr, 2 Speed Balboa 1016211 2S 20FT A2MB HV B... -
Page 19: Warranty
Components that become defective due to corrosion or scale formation as a result of improper water balance and/or spa maintenance are disclaimed, in their entirety, under this warranty. InnovaSpa assumes no liability or responsibility for incidental, consequential or other damage including, but not limited to, removal of a deck or other custom fixture(s), transportation or shipping charges, telephone charges, rental of a like product during the time warranty service is being performed, travel, loss or damage to personal property and loss of revenue, use, time or convenience resulting from the loss of use of the hot tub covered by this warranty.
