Connecting the Power Cord

WARNING: TV and AC receptacle must be installed at least
5 feet away from standing water, such as (but not limited to) a
pool or spa. Please allow for additional clearance if TV is in use
on a SkyVue Portable Cart.
Connect the power cord after you have made connections to your video equipment. Connect the power cord to an
outdoor AC outlet that is in compliance with local regulations.
Manual Controls Panel
The Side or Bottom Control Panel can be found by reaching your hand on the
underside of the SkyVue logo .
This button switches between the different sources of the TV. When the On-Screen Display (OSD) is active, this
INPUT
button acts as the enter button and confirms the menu selection.
These buttons change the TV channel up or down. If the OSD is active, these buttons function as up or down
CH+/CH-
controls for the menu.
This button activates the OSD. If a sub-menu is active, pressing this button will return selection to the previous
MENU
menu level.
These buttons increase or decrease the volume. If a sub-menu is active, pressing these buttons will move the
VOL+ / VOL-
selection left or right. If the OSD is active, Vol+/Vol- is used to select the highlighted options.
POWER
Turn on the TV by pressing the button once. Press the button again to turn off the TV.

Front Panel Lights and Sensors

Owner's Manual -
Model NXG-4650
Location of
Manual Controls Panel
Ambient Light Sensor
IR - Remote Sensor
Service Indicator Light
