Skyvue NXG-4650 Owner's Manual page 18

Installation/Mounting Notes
WARNING: Use at least two people when transporting the TV.
Tools Needed: Phillips screwdriver
Supplied -
(4 qty.) Additional #8-32 Phillips Head Screws (figure 1)
(4 qty. ) Speakerbar Mounting Brackets (figure 2)
1. Remove (4 qty.) #8-32 (pre-installed) screws located on the top back of the SkyVue TV. Figure 3.
2. Position the Speakerbar mounting brackets (Figure 2) as shown in (Figure 4) below.
Secure mounting brackets with the same (4) #8-32 screws that were removed in step 1.
3. Screw securely
4. With mounting brackets securly attached to back of television: Position speakerbar as shown in Figure 5.
The sound will be projected in a downward direction.
5. Using the 4 additional #8-32 Phillips Head screws, align the screw holes on the speakerbar mount with the
holes on the speakerbar mounting bracket.
6. Screw securely.
7. Loosen the 3 latches, and open the Component Cover.
8. Take the Speaker Cable from the speaker, making sure
that the Speaker Cable Wire is placed on the Rubber
Sealing Gasket, and plug it into the Speakerbar
L/R Audio Out Ports.
9. When you close the Component Cover, be sure that
the Speaker Cable Wire is placed across the Rubber
Sealing Gasket. As with all wires entering the connec-
tion compartment, leave a drip loop as the wire enters
the TV, this will allow water to drip from the bottom of
the loop.
Remove for Speakerbar
16
Figure 3
Do Not
Remove
Figure 1
Figure 4
All Rights Reserved. 2014 SkyVue
