GET STARTED USER'S GUIDE
1120 ADSL Router
GET STARTED USER'S GUIDE
Version: 5.3
172160
Telindus Technical Publications - Geldenaaksebaan 335 - B-3001 Leuven - Belgium - Tel. +32 16 382011

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1120 and is the answer not in the manual?

Questions and answers

Related Manuals for Telindus 1120

Summary of Contents for Telindus 1120

  • Page 1 GET STARTED USER’S GUIDE 1120 ADSL Router GET STARTED USER’S GUIDE Version: 5.3 172160 Telindus Technical Publications - Geldenaaksebaan 335 - B-3001 Leuven - Belgium - Tel. +32 16 382011...

  • Page 2: Copyright Notice

    Telindus 1120 ADSL Router Copyright notice The information and descriptions contained in this publication are the property of Telindus. Such information and descriptions must not be copied or reproduced by any means, or disseminated or distributed without the express prior written permission of Telindus.
  • Page 3 Telindus 1120 ADSL Router Copyright and statements Statements http://www.telindus.com/products/conformity/ Hereby, TELINDUS declares that this Telindus 1120 ADSL Router is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. deze, verklaart TELINDUS deze Telindus 1120 ADSL Router overeenstemming is met de essentiële vereisten en andere relevante bepalingen van...

  • Page 4: Declaration Of Conformity

    Telindus 1120 ADSL Router Declaration of Conformity issued according to ISO/IEC Guide 22 and EN45014 under the sole responsibility of the manufacturer Hereby, TELINDUS nv/sa, manufacturer represented by the authority indicated below, declares that the product: Product name Telindus 1120 ADSL Router provided that it is installed, maintained and used in the application for which it is intended for, with respect of the “professional practices“, relevant installation standards...
  • Page 5 Le Telindus 1120 ADSL Router peut être connecté aux interfaces suivantes: IEEE 802.3 Ethernet 10Base-T. En cas de problèmes: En cas de doute ou si vous rencontrez des problèmes avec le Telindus 1120 ADSL Router, veuillez demander conseil à votre revendeur Erklärung: Der Telindus 1120 ADSL Router darf benutzt werden, vorausgesetzt, er wird installiert, unterhalten und in der Funktion benutzt für die er entwickelt wurde,...
  • Page 6 Il Telindus 1120 ADSL Router può essere collegato agli le seguenti interfacce: IEEE 802.3 Ethernet 10Base-T. In Caso di Problema: In caso di dubbi o problemi di incontro col Telindus 1120 ADSL Router, per favore contatti il Suo rivenditore per consiglio. Get Started User’s Guide...

  • Page 7: Table Of Contents

    Table of contents Table of Contents 1. Before You Begin ..........1 1.1 Introduction ................1 1.2 Package Includes ..............1 1.3 Diagrams of the Telindus 1120 ADSL Router ......1 1.4 Minimum System Requirements ..........2 1.5 Internet Service ................. 3 1.6 Information You Will Need ............

  • Page 8: Before You Begin

    Information You Will Need 1.1 Introduction The Telindus 1120 ADSL Router is an integrated device that allows multiple workstations to share high-speed bandwidth provided by DSL technology. In addition to fast Internet access and advanced routing technologies, the Telindus 1120 ADSL Router incorporates numerous features that facilitate network access and management.

  • Page 9: Minimum System Requirements

    Front Panel Interface Figure 1.2 Front Panel Interface PWR (Power) A green LED is ON when power is supplied to the Telindus 1120 ADSL Router. DIAG (Diagnostic) When Telindus 1120 ADSL Router is powered on, the DIAG LED flashes while the router is booting up.

  • Page 10: Internet Service

    ADSL Router. If you ordered a Multiple User account from your ISP, they will assign a specific IP Address for your router and a range of IP Addresses for your network. You will need this information when you configure the Telindus 1120 ADSL Router. In this case, the NAT option should not be selected.

  • Page 11: Hardware Installation

    2.1 Setup Instructions Step 1. Choose a location for the Telindus 1120 ADSL Router close to a power outlet and the ADSL line outlet. Preferably, select a convenient location that does not experience too much foot traffic and away from sunlight.

  • Page 12: Connect To The Power Adapter

    Telindus 1120 ADSL Router Hardware Installation 2.4 Connect to the Power Adapter Step 1. Plug the power adapter into the power interface of the Telindus 1120 ADSL Router. Step 2. Connect one end of the power cord to the power adapter, and insert the other end of the power cord to the power outlet on the wall.

  • Page 13: Software Installation & Configuration

    TCP/IP network protocol on the network PCs before you install the Telindus 1120 ADSL Router. Note: To ensure that your Telindus 1120 ADSL Router will assign an IP address to your PCs, if you set them to get IP addresses automatically, we have already configured your Telindus 1120 ADSL Router prior to shipping.

  • Page 14: Installing Tcp/Ip In Windows® 95/98

    Step 2. Click the Gateway tab. Step 3. Type in your Gateway IP Address (the IP address for the Telindus 1120 ADSL Router) from your ISP and then click Add. Step 4. Click the DNS tab. Enter the Host name, Domain name, and DNS Service Search Order (for your LAN) and then click Add.

  • Page 15: Detecting Tcp/Ip In Windows® 2000

    Software Installation & Configuration Telindus 1120 ADSL Router ® 3.4 Detecting TCP/IP in Windows 2000 ® Step 1. Turn on your computer and log-in to Windows 2000. Step 2. Click the Start button and select Settings. Step 3. Choose Control Panel, and then double click Network and Dial-up Connections icon.

  • Page 16: Detecting Tcp/Ip In Windows® Nt

    Telindus 1120 ADSL Router Software Installation & Configuration ® 3.7 Detecting TCP/IP in Windows ® Step 1. Turn on your computer and log-in to Windows Step 2. Click the Start button and select Settings. Step 3. Choose Control Panel, and then double click Network icon.

  • Page 17: Configuring Your Router

    Internet through Telindus 1120 ADSL Router. If you have difficulties configuring your router, consult the Troubleshooting section of this guide, or the help menu in the Telindus 9100 Maintenance Application, or refer to the FAQs located on TELINDUS’s website (http://www.telindus.com).

  • Page 18: Multiple Router Selection Window

    Select the Telindus 1120 ADSL Router that you wish to manage and click Enter to open the Telindus 9100 Maintenance Application, which is where you can configure your router, check your router’s status, or use some router maintenance tools.

  • Page 19: Adsl Configuration

    B. You have the option to choose ANSI T1.413, G.LITE, G.DMT, or Multi Mode as your DSL line mode. Note: The DSL line mode refers to the entire Telindus 1120 ADSL Router unit and not each individual ATM PVC profile. Once you have made your choice, all subsequent ATM PVC profiles created will be using the same line mode.
  • Page 20 J. Click Apply, and review the summary of you basic configuration. K. Click Finish to save the parameters to Telindus 1120 ADSL Router. Congratulations! You are ready to begin using your Telindus 1120 ADSL Router for shared Internet access. Enjoy!

  • Page 21: Troubleshooting

    Another way you can confirm that there is a physical connection to your LAN is by checking the LED located on the front panel of the Telindus 1120 ADSL Router. The LAN Link LED of will lit green to indicate a valid LAN connection. If the LAN Link LED of is not green, then check the connection between the router and your LAN.

  • Page 22: Router And Pc Are Not In The Same Subnet

    192.168.1.2. For Windows NT, use the DOS Command Prompt, type ipconfig/ release and press the Enter key, and then type ipconfig/renew and press the Enter key. You should receive a valid IP Address, such as 192.168.1.2. Re-start the Telindus 9100 Maintenance Application to see if it can detect the router.

  • Page 23: Appendix A: Understanding Configuration Parameters

    Explaining IP Addresses LAN IP Address In the most basic terms, the Primary LAN IP address is the logical location of the Telindus 1120 ADSL Router on the local Ethernet network. If there is another subnet in the Ethernet network you would like Telindus 1120 ADSL Router to be able to access, you can specify a Secondary LAN IP Address.

  • Page 24: Ip Packet Filtering

    Establishing IP packet filters allows you to monitor and selectively filter packets that enter or leave the Telindus 1120 ADSL Router. You can use filtering to protect your network from unauthorized access, and restrict certain web traffic from leaving your LAN. This is done...

  • Page 25: Appendix B: Ethernet Cable Pinout

    Appendix B: Ethernet Cable Pinout Telindus 1120 ADSL Router Appendix B: Ethernet Cable Pinout Get Started User’s Guide...
