Page 1: Quick Start Guide
TELINDUS 1130/1131 ADSL ROUTER/BRIDGE Quick Start Guide Version 2.0 Telindus Technical Publications - Geldenaaksebaan 335 - B-3001 Leuven Belgium - Tel. +32 16 382011 Page 1 of 23... -
Page 2: Copyright Notice
Disclaimer This publication could include technical inaccuracies or typographical errors, for which Telindus never can or shall be held liable. Changes are made periodically to the information herein; these changes will be incorporated in new editions of this publication. Telindus may make improvements and/or changes in the product(s) described in this publication at any time, without prior notice. -
Page 3: Conformity Statements
Bij deze verklaart TELINDUS dat deze TELINDUS 1130/1131 ROUTER/BRIDGE in overeenstemming is met de essentiële vereisten en andere relevante bepalingen van Richtlijn 1999/5/EC. Par la présente, TELINDUS déclare que ce TELINDUS 1130/1131 ROUTER/BRIDGE est en conformité avec les exigences essentielles et autres articles applicables de la Directive 1999/5/EC. -
Page 4: Safety Instructions
Safety instructions IMPORTANT SAFETY INSTRUCTIONS Unplug the unit from the wall power outlet before installing, adjusting or servicing. ACHTUNG! WICHTIGE SICHERHEITSINSTRUKTIONEN Vor sämtlichen Arbeiten am Gerät (Installation, Einstellungen, Reparaturen etc.) sollten Sie den Netzstecker aus der Steckdose ziehen. SAFETY WARNING To avoid damage to the equipment, please observe all procedures described in this manual. -
Page 5: Table Of Contents
Introduction Thank your purchase TELINDUS 1130/1131 ADSL ROUTER/BRIDGE. The ADSL Router provides you with a high-speed broadband Internet connection using your existing phone line that at the same time allows you to make phone calls. The ADSL Ethernet & USB Router can be connected to any computer/notebook with a USB Port or 10/100 Base-T Ethernet card. -
Page 6: Minimum System Requirements
Minimum System Requirements Pentium ® MMX 233MHz • • A CD-ROM Drive • Ethernet card installed with TCP/IP Protocol (required only if you are connecting to the ETHERNET port of your DSL Router) • USB port (required by if you are connecting to the USB Port of your ADSL Router) •... -
Page 7: Adsl Router Overview
ADSL Router Overview Front Indicators ②④ ① ③ ⑤ ① PPP Lights up when the PPP connection is established. ② PWR Lights up when power is supplied to the Router. ③ Lights up when the ADSL connection is established. Flickers when the ADSL Router is trying to establish a connection with the ADSL Service Provider ④... -
Page 8: Back Panel
Back Panel ④ ② ③ ⑤ ① ① DSL Telephone jack (RJ-11) to connect to your Telephone Wall Socket (ADSL line). ② USB USB Port to connect to the USB port on your Computer/Notebook. ③ ETHERNET 10/100 Base-T Ethernet jack (RJ-45) to connect to your Ethernet Network card or Ethernet Hub / Switch. -
Page 9: Step 1: Connecting The Adsl Router To Your Computer/Notebook
Step 1: Connecting the ADSL Router to Your Computer/Notebook Power off your Computer/Notebook or/and any connected devices before connecting to the ADSL Router! To connect to your ADSL Router, you need to have either an Ethernet Port or a USB Port present on your computer/Notebook. - Page 10 See the following illustration. Computer/Notebook with USB Port Ethernet Switch/Hub Ethernet Computers/Notebooks with Ethernet Network Cards For details on the connection and types of Ethernet Network cable to use with the Ethernet Switch/ Hub, please refer to documentation that comes with your Ethernet Switch/Hub.
-
Page 11: Connecting To The Ethernet
1.1.2 (a) Connecting to the Ethernet (This connection is not required if you are connecting to an Ethernet Switch/Hub for multiple-users connection). Back view of a computer Ethernet Port Ethernet Network Card Back view of the ADSL Router Ethernet Network cable You may now proceed to Step 1.2. - Page 12 Step 1.2 Connecting to the ADSL Line To connect the ADSL Ethernet Modem to the ADSL line, carried out Step 1.2(a). To connect the ADSL Ethernet Modem to the ADSL line and a Telephone Set, carried out Step 1.2(b). To connect to the ADSL line Back view of the Telephone ADSL Ethernet...
- Page 13 Connecting your ADSL Router to the Power Outlet via the Power adapter (that comes with your ADSL Router package). Connect the other end of Back view of The Power Adapter to the The ADSL Router Power Outlet Step 1.4 Powering On Power on the Power Outlet that is connected to your ADSL Router.
-
Page 14: Step 2: Configuring Your Ethernet Network Card/ Installing Your Usb Device
Step 2: Configuring Your Ethernet Network Card/ Installing your USB Device If your computer/notebook is connected to the Ethernet Port of the ADSL Router, proceed with section 2.1. If your computer/notebook is connected to the USB Port of the ADSL Router, proceed with section 2.2. If your computer/notebooks are connected to both the Ethernet Port and USB Port of your ADSL Router, please proceed with both sections 2.1 and 2.2. -
Page 15: Installing The Usb Device Driver
® ® 2.1.2 For Windows 2000 / Windows ® Windows 2000: From your Windows desktop, right-click on the icon My Network Places and select Properties. At the Network and Dial-up Connections window, right-click on the Local Area Connection icon and select Properties. ®... - Page 16 1. Proceed with this section ONLY if your computer/notebook is connected to the USB Port of your ADSL Router! 2. The following screen shots illustrated serve only as examples. For any dissimilarities, please follow closely the instructions prompted on your Computer/Notebook.
- Page 17 vi Select the updated driver (recommended) DSL Router USB Remote NDIS Network Device and click Next. vii Click Next to proceed installation with indicated driver. Depending on your system configurations, you may be prompted for your windows CD-ROM during installation. At the prompt, replace the Installation CD in your CD- ROM Drive with your Windows CD-ROM and click OK.
- Page 18 v. Click Next again to proceed installation with the indicator driver. vi Click Finish to complete the USB driver installation. vii Restart your system when prompted. Proceed to Step 3. ® 2.2.3 Installing the USB Device Driver-For Windows 2000 i Power on your computer to start Windows. ii Place the Installation CD into your CD-ROM Drive.
- Page 19 viii. Click Finish when prompted. Upon completion, proceed to Step 3. ® 2.2.4 Installing the USB Device Driver-For Windows i Power on your computer to start Windows. ii Place the Installation CD into your CD-ROM Drive iii At the following prompt, select Install from a list or specific location (Advanced) option and click Next.
- Page 20 v You may be prompted with Hardware Installation dialog box. (This happens when Windows detects your driver as a new version). Click Continue Anyway to proceed with the installation. vi Click Finish when prompted. Upon completion, proceed to Step 3. Page 20 of 23...
-
Page 21: Step 3: Configuring Your Internet Browser
Step 3: Configuring Your Internet Browser ® 3.1 Microsoft Internet Explorer™ (based on IE 5.5) i From your Windows desktop, double-click on your Internet Explorer icon launch your Browser. ii From the Menu, click Tools and select Internet Options. iii Select the Connection tab. Click the field, 'Never dial a connection'. (This option will be grayed off if you have not installed an analog modem on your computer/notebook before. -
Page 22: Step 4: Connecting To The Internet
Step 4: Connecting to the Internet i From your Internet Browser, key in http://192.168.1.1 at the address bar and hit <Enter>. ii You will be prompted for the Username and Password to login to the Web Management. Enter admin for the username and admin for the password (factory defaults). - Page 23 Page 23 of 23...
