Summary of Contents for Telindus 1134
- Page 1 TELINDUS 1134/1135 ADSL ROUTER/SWITCH 4P Quick Start Manual Version 2.0 Telindus Technical Publications - Geldenaaksebaan 335 - B-3001 Leuven Belgium - Tel. +32 16 382011 Page 1 of 16...
-
Page 2: Copyright Notice
Disclaimer This publication could include technical inaccuracies or typographical errors, for which Telindus never can or shall be held liable. Changes are made periodically to the information herein; these changes will be incorporated in new editions of this publication. Telindus may make improvements and/or changes in the product(s) described in this publication at any time, without prior notice. -
Page 3: Conformity Statements
Bij deze verklaart TELINDUS dat deze TELINDUS 11134/1135 ROUTER/SWITCH in overeenstemming is met de essentiële vereisten en andere relevante bepalingen van Richtlijn 1999/5/EC. Par la présente, TELINDUS déclare que ce TELINDUS 1134/1135 ROUTER/SWITCH est en conformité avec les exigences essentielles et autres articles applicables de la Directive 1999/5/EC. -
Page 4: Safety Instructions
Safety instructions IMPORTANT SAFETY INSTRUCTIONS Unplug the unit from the wall power outlet before installing, adjusting or servicing. ACHTUNG! WICHTIGE SICHERHEITSINSTRUKTIONEN Vor sämtlichen Arbeiten am Gerät (Installation, Einstellungen, Reparaturen etc.) sollten Sie den Netzstecker aus der Steckdose ziehen. SAFETY WARNING To avoid damage to the equipment, please observe all procedures described in this manual. -
Page 5: Table Of Contents
Step 4: Connecting to the Internet ................16 Introduction Thank you on your purchase of the TELINDUS 1134/1135 ADSL ROUTER /SWITCH! This 4 Port Ethernet ADSL Router allows you to share high-speed broadband ADSL connection with multiple PCs using a single device. With ADSL, you can enjoy high-speed broadband connectivity for email, Internet surfing, corporate access and continue to make phone calls using your existing phone line. -
Page 6: Adsl Router Package
ADSL Router Package For any missing items, please contact your dealer immediately. ADSL Ethernet Router Quick Start Telephone Cable (RJ-11) POTS-Splitter (optional) CAT-5 UTP Straight Power Adapter (DC12V) Ethernet Network cable (RJ-45) 1Depending on your country of purchase, your package may or may not come with a POTS Splitter and/or a second Telephone Cable. - Page 7 ② ETH/ACT Lights up when the Ethernet cable is properly connected from your ADSL Router to the Ethernet Card. Flickers when the ADSL is transmitting/receiving data. ③ Lights up when the ADSL connection is established. Flickers when the ADSL Router is trying to establish a connection with the ADSL Service Provider ④...
-
Page 8: Typical Adsl Router Connections
④ RESET To reset your ADSL Router to factory default settings. (All customised settings that you have saved will be lost!) Please refer to the below footer 2 on how to activate the reset function. ⑤ ADSL Telephone jack (RJ-11) to connect to your Telephone Wall Socket (ADSL line). 2 To activate the reset function: - Ensure that your ADSL Router is powered on. - Page 9 For More than 4 PCs Connections To connect to more than 4 computers/notebooks, you may further cascade to another Ethernet Hub/Switch. For details on how to connect to the Ethernet Switch/Hub, please refer to the documentation that comes with the Ethernet Hub/switch. Computers or Notebooks with Ethernet Network Cards ADSL Router...
-
Page 10: Step 1: Connecting The Adsl Router To Your Computer/Notebook
Step 1: Connecting the ADSL Router to Your Computer/Notebook Power off your Computer/Notebook or/and any connected devices before connecting to the ADSL Router! 1.1 Connecting to the Ethernet Connect your computer(s)/notebook(s) to the ADSL 4 Port Router as illustrated. The following illustration shows the connection of a single computer. Back view of a computer Ethernet Port Ethernet Network Card... -
Page 11: Connecting To The Adsl Line
1.2 Connecting to the ADSL Line To connect the ADSL Ethernet Modem to the ADSL line, perform Step 1.2(a). To connect the ADSL Ethernet Modem to the ADSL line and a Telephone Set, perform Step 1.2(b). To connect to the ADSL line Back view of the Telephone ADSL Router... -
Page 12: Connecting To The Power Outlet
1.3 Checking Your Connections Please check your connections before proceeding. Back view of the ADSL Router To your Power Outlet To your Telephone Wall Socket (ADSL line) To the Ethernet Port on your Computer(s)/Notebook(s) 1.4 Connecting to the Power Outlet Back view of the ADSL Router Connect the other end of the Power... -
Page 13: Step 2: Configuring Your Ethernet Network Card
Step 2: Configuring Your Ethernet Network Card 2.1 Configuring Your Ethernet Network Card The following illustrated screen shots serve only as examples. For any dissimilarities, please follow closely the instructions prompted on your Computer. ® ® 2.2 For Windows 98 Second Edition / Windows From your Windows desktop, right-click on the Network Neighborhood icon. - Page 14 ® ® 2.3 For Windows 2000 / Windows ® Windows 2000: From your Windows desktop, right-click on the icon My Network Places and select Properties. At the Network and Dial-up Connections window, right-click on the Local Area Connection icon and select Properties. ®...
-
Page 15: Step 3: Configuring Your Internet Browser
Step 3: Configuring Your Internet Browser ® 3.1 Microsoft Internet Explorer™ (based on IE 5.5) I From your Windows desktop, double-click on your Internet Explorer icon launch your Browser. II From the Menu, click Tools and select Internet Options. III Select the Connection tab. Click the field, 'Never dial a connection'. (This option will be grayed off if you have not installed an analog modem on your computer/notebook before. -
Page 16: Step 4: Connecting To The Internet
Step 4: Connecting to the Internet i From your Internet Browser, key in http://192.168.1.1 at the address bar and hit <Enter>. ii You will be prompted for the Username and Password to login to the Web Management. Enter admin for the username and admin for the password (factory defaults).
