Currys Essentials CUF50W10 Instruction Manual page 5

INSTALLATION
2. Remove the screws and hinge bracket
from the base.
3. Slide the door down and remove away
from the unit.
4. Remove the top hinge pin and spring
inside the door and refit on the opposite
side. Remove the top hinge cover and
refit on the opposite side.
5. Slide the door back on to the top hinge.
Screw the bottom hinge into place on
the new side.
6. Check that the door is aligned
horizontally and vertically and that the
seals are closed on all sides before finally
tightening the bottom hinge. Re-adjust
the levelling feet.
