LC-5500(RE)
EXERCISE BIKE
Console Assembly
AK17-00134-0001 Eng/Eng
AK17-00134-0002 Eng/Met
AK17-00134-0003 Ger/Met
AK17-00134-0004 Spn/Met
AK17-00134-0007 Frn/Met
AK17-00134-0008 Itl/Met
AK17-00134-0009 Dut/Met
Seat
0017-00009-0746
Seat w/Seatpost
AK18-00183-0000
Seatpost
AK18-00157-0004
Seat Pin w/Molded Knob
OK17-01208-0000
Cap
OK17-01018-0000
Leg Levelers(2)
0017-00009-0795
Foot(2)
OK17-01033-0000
SN: 519922-520221, 521821-528139
9 Volt Battery
0017-00003-0757
Shroud w/Decal(LT)
AK18-00079-0003
Pedal w/Strap(LT)
AK17-00189-0002
Stabilizer Bar
SK18-00070-0000
1 of 2
GE09-00011-XXXX
Overlay Bezel
AK17-00141-0001 Eng/Eng
AK17-00141-0002 Eng/Met
AK17-00141-0003 Ger/Met
AK17-00141-0004 Spn/Met
AK17-00141-0007 Frn/Met
AK17-00141-0008 Itl/Met
AK17-00141-0009 Dut/Met
Console Case
OK24-01566-0000
Handlebar
AK17-00116-0001
Front Cap
OK17-01148-0000
Shroud w/Decal(RT)
AK18-00078-0003
Pedal w/Strap(RT)
AK17-00189-0001
Revision Date: 11/11/98
