LC-5500R
EXERCISE BIKE
Console Assembly
AK19-00052-0001(R) Eng/Eng
AK19-00052-0002(R) Eng/Met
AK19-00052-0003(R) Ger/Met
AK19-00052-0006(R) Jap/Met
AK19-00052-0007(R) Frn/Met
AK19-00052-0004(R) Spn/Met
AK19-00052-0005(R) Swe/Met
AK19-00052-0008(R) Ilt/Met
AK19-00052-0009(R) Dut/Met
Seat Back
OK19-01078-0003
Levelers w/Pads(2)
0017-00009-0795
Overlay Bezel
AK19-00040-0001 Eng/Eng
AK19-00040-0002 Eng/Met
AK19-00040-0003 Ger/Met
AK19-00040-0006 Jap/Met
AK19-00040-0007 Frn/Met
AK19-00040-0004 Spn/Met
AK19-00040-0005 Swe/Met
AK19-00040-0008 Ilt/Met
AK19-00040-0009 Dut/Met
Seat Bottom
OK19-01079-0003
Stabilizer Bar
SK18-00070-0000
1 of 3
GK19-00003-XXXX
SN 301-310, 400001-406405
Console Case
OK18-01243-0001
9 Volt Battery
0017-00003-0757
Console Logo Decal
OK18-01178-0006
Console Post w/Decal
AK19-00048-0000
Console Post Cap
OK19-01125-0000
Revision Date: Friday, January 12, 2001
