O
PERATING
VRF SYSTEM
INDOOR UNIT
Duct Type
ARXD07LATH
ARXD09LATH
ARXD12LATH
ARXD14LATH
ARXD18LATH
ARXD24LATH
KEEP THIS MANUAL FOR FUTURE REFERENCE
DIESE ANLEITUNG BITTE SORGFÄLTIG AUFBEWAHREN
CONSERVEZ CE MODE D'EMPLOI AFIN DE POUVOIR VOUS Y RÉFÉRER ULTÉRIEUREMENT
GUARDE ESTE MANUAL PARA PODERLO CONSULTAR EN EL FUTURO
CONSERVARE QUESTO MANUALE PER OGNI EVENTUALE FUTURO RIFERIMENTO
ΚΡΑΤΗΣΤΕ Τ ΕΓ ΕΙΡΙ∆Ι
GUARDE ESTE MANUAL PARA CONSULTA POSTERIOR
СОХРАНИТЕ НАСТОЯЩЕЕ РУКОВОДСТВО ДЛЯ БУДУЩИХ ССЫЛОК
BU KILAVUZU, DAHA SONRA BAfiVURMAK ÜZERE SAKLAYIN
FUJITSU GENERAL LIMITED
TM
M
ANUAL
ΓΙΑ ΜΕΛΛ ΝΤΙΚΗ ΑΝΑΦ ΡΑ
OPERATING MANUAL
BEDIENUNGSANLEITUNG
MODE D'EMPLOI
MANUAL DE FUNCIONAMIENTO
MANUALE DI ISTRUZIONI
ΕΓ ΕΙΡΙ∆Ι
MANUAL DE INSTRUÇÕES
РУКОВОДСТВО ПО ЭКСПЛУАТАЦИИ
KULLANIM K‹TABI
ΛΕΙΤ ΥΡΓΙΑΣ
P/N9374343058-02
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for AirStage ARXD07LATH
Summary of Contents for AirStage ARXD07LATH
-
Page 1: Operating Manual
PERATING ANUAL MANUAL DE INSTRUÇÕES РУКОВОДСТВО ПО ЭКСПЛУАТАЦИИ VRF SYSTEM KULLANIM K‹TABI INDOOR UNIT Duct Type ARXD07LATH ARXD09LATH ARXD12LATH ARXD14LATH ARXD18LATH ARXD24LATH KEEP THIS MANUAL FOR FUTURE REFERENCE DIESE ANLEITUNG BITTE SORGFÄLTIG AUFBEWAHREN CONSERVEZ CE MODE D’EMPLOI AFIN DE POUVOIR VOUS Y RÉFÉRER ULTÉRIEUREMENT... -
Page 2: Safety Precautions
CONTENTS 1. SAFETY PRECAUTIONS ........1 5. CLEANING AND CARE ........5 2. NAME OF PARTS ..........2 6. TROUBLESHOOTING ........6 3. MANUAL AUTO OPERATION ......3 7. SPECIFICATIONS ..........8 4. OPERATING TIPS ..........4 SAFETY PRECAUTIONS Before using the appliance, read these “PRECAUTIONS” thoroughly and operate in the correct way. The instructions in this section all relate to safety;... -
Page 3: Name Of Parts
NAME OF PARTS ARXD 07/09/12/14/18/24 Ceiling Concealed Wall Mounted / Floor Standing Concealed 1 Outlet Port 2 Intake Port Control unit (optional) Wireless Remote Controller Wired Remote Controller Simple Remote Controller Be sure to use after connecting receiver unit. For operation method, please refer to the Operating Manual of each device. En-2... - Page 4 MANUAL AUTO OPERATION (Only when receiver unit is connected) Use the MANUAL AUTO operation in the event the remote control unit is lost or otherwise unavailable. *Limited to only when receiver unit is connected. Do not press the MANUAL AUTO button with wet hands or pointed objects, otherwise an electric CAUTION! shock or malfunction may occur.
-
Page 5: Operating Tips
OPERATING TIPS Operation and Performance About priority state and standby state G Multiple indoor units can be connected within the same system. Depending on the system, choice of operating mode are limited. Cooling priority state When the other indoor units within the same system operate in cooling or dry mode, heating can not be selected at the same time. -
Page 6: Cleaning And Care
CLEANING AND CARE G Before cleaning the unit, be sure to stop the unit and disconnect the power supply. CAUTION! G Do not stand on an unstable platform when cleaning. G When removing and replacing the air filters, be sure not to touch the heat exchanger, as per- sonal injury may result. -
Page 7: Troubleshooting
TROUBLESHOOTING The following conditions are not breakdowns or operation failures. Symptom Problem See Page G If the unit is stopped and then immediately started again, the compressor will not Doesn’t operate immedi- — ately: operate for about 3 minutes, in order to prevent fuse blowouts. G Whenever the electrical breaker is turned off then on again, the protection circuit —... - Page 8 TROUBLESHOOTING The following conditions may not be breakdowns so check again. Symptom Items to check See Page G Has there been a power failure? Doesn’t operate at all: — G Has a fuse blown out, or a circuit breaker been tripped? —...
-
Page 9: Specifications
SPECIFICATIONS MODEL ARXD07LATH ARXD09LATH ARXD12LATH ARXD14LATH ARXD18LATH ARXD24LATH POWER SOURCE 230 V~50 Hz AVAILABLE VOLTAGE RANGE 198 to 264 V COOLING CAPACITY [kW] HEATING CAPACITY [kW] SOUND PRESSURE LEVEL HIGH dB(A) dB(A) dB(A) DIMENSIONS & WEIGHT HEIGHT [mm] WIDTH [mm]...
