TM
INSTALLATION MANUAL
INSTALLATIONSANLEITUNG
MANUEL D'INSTALLATION
APPAREIL INTÉRIEUR (type conduit)
MANUAL DE INSTALACIÓN
Únicamente para personal de servicio autorizado.
MANUALE DI INSTALLAZIONE
A uso esclusivo del personale tecnico autorizzato.
ΕΓΧΕΙΡΙΔΙΟ ΕΓΚΑΤΑΣΤΑΣΗΣ
ΕΣΩΤΕΡΙΚΗ ΜΟΝΑΔΑ (Τύπος αγωγού)
Μόνο για εξουσιοδοτημένο τεχνικό προσωπικό.
MANUAL DE INSTALAÇÃO
UNIDADE INTERIOR (Tipo de tubagem)
РУКОВОДСТВО ПО УСТАНОВКЕ
Только для авторизованного обслуживающего персонала.
INDOOR UNIT (Duct type)
For authorized service personnel only.
INNENGERÄT (Kanaltyp)
Nur für autorisiertes Fachpersonal.
Pour le personnel agréé uniquement.
UNIDAD INTERIOR (Tipo conducto)
UNITÀ INTERNA (tipo a condotto)
Apenas para técnicos autorizados.
ВНУТРЕННИЙ МОДУЛЬ (Короб)
MONTAJ KILAVUZU
İÇ ÜNİTE (Kanal tipi)
Yalnızca yetkili servis personeli için.
PART NO. 9374342280
Advertisement
Table of Contents
Related Manuals for AirStage ARXB09GALH
Summary of Contents for AirStage ARXB09GALH
-
Page 1: Installation Manual
APPAREIL INTÉRIEUR (type conduit) Pour le personnel agréé uniquement. MANUAL DE INSTALACIÓN UNIDAD INTERIOR (Tipo conducto) ARXB07GALH Únicamente para personal de servicio autorizado. ARXB09GALH MANUALE DI INSTALLAZIONE ARXB12GALH UNITÀ INTERNA (tipo a condotto) ARXB14GALH A uso esclusivo del personale tecnico autorizzato. -
Page 2: Table Of Contents
INSTALLATION MANUAL This mark indicates procedures which, if improperly performed, CAUTION might possibly result in personal harm to the user, or damage to PART NO. 9374342280 property. VRF system indoor unit (Duct type) Read carefully all security information before use or install the air conditioner. Contents Do not attempt to install the air conditioner or a part of the air conditioner by yourself. -
Page 3: Accessories
2.3. Accessories Name and Shape Q’ty Application Cable tie (Medium) For transmission and remote controller cable binding. WARNING For installation purposes, be sure to use the parts supplied by the manufacturer or Cable tie (Large) For fixing the coupler heat insulation. other prescribed parts. -
Page 4: Installation Work
Strong and durable ceiling 3. INSTALLATION WORK 20 mm or more 3.1. Selecting an installation location 300 mm or more Correct initial installation location is important because it is diffi cult to move unit after it is installed. 20 mm or more 2500 mm WARNING or more... - Page 5 3.3A.1. UNIT INSTALLATION EXAMPLE (CEILING AR07/09: 2 fi lters CONCEALED TYPE) AR12/14/18: 3 fi lters Side Inlet - Side Outlet Filter Unit Duct (Field supply) Intake grill (Field supply) Bottom Inlet - Side Outlet Replace the cover as follows. • Remove the 4 tapping screws, and then remove cover. •...
-
Page 6: Installation The Unit (Floor Standing Concealed Type)
• Hang the unit. Level Pass the hanging bolts through the hangers (4 places). Hanger (Accessories) Tapping screw (Accessories) Good Prohibited Hanger bolt 3.3B. Installation the unit (Floor standing Special nut A concealed type) (Accessories) Unit CAUTION To prevent people from touching the parts inside the unit, be sure to install grilles on the inlet and outlet ports. -
Page 7: Pipe Installation
3.3B.2. INSTALLING THE HANGERS 3.3B.5. LEVELING Base horizontal and vertical direction leveling on top of the unit. • Install the hangers (Accessories) to the unit (4 places). Left drain port Right drain port If using the right drain port Hanger 3.3B.3. -
Page 8: Pipe Requirement
4.3.2. Bending pipes 4.2. Pipe requirement • If pipes are shaped by hand, be careful not to collapse them. • Do not bend the pipes in an angle more than 90°. CAUTION • When pipes are repeatedly bend or stretched, the material will harden, making it Refer to the Installation Manual of the outdoor unit for description of the length of diffi... -
Page 9: Installing Heat Insulation
4.4. Installing heat insulation 5. INSTALLING DRAIN PIPES Install the heat insulation material after performing a refrigerant leak check (see the In- Use general hard polyvinyl chloride pipe and connect it with adhesive (polyvinyl chloride) stallation Manual for the outdoor unit for details). so that there is no leakage. -
Page 10: Electrical Wiring
Butt the insulation (2) Be sure to insert Drain hose 1 to the very end of the Drain pan of the unit with no against the unit. space. Control box Applying area of Ensure there Joint pipe adhesive is no space. (Field supply) Slit Drain pipe (VP25) -
Page 11: Electrical Requirement
Model Breaker Pull box ARXB07GALH 0.29 A Power supply ARXB09GALH 0.30 A 20 A ARXB12GALH 0.36 A * Earth (Ground) the remote controller if it has an earth (ground) wire. Connect the earth (ground) wire of the remote controller to the earth (ground) terminal ARXB14GALH 0.48 A... -
Page 12: Unit Wiring
WARNING 6.3. Unit wiring Use ring terminals and tighten the terminal screws to the specifi ed torques, otherwise, Before attaching the cable to terminal block. abnormal overheating may be produced and possibly cause heavy damage inside the unit. 6.3.1 Power supply cable Tightening torque Adjust the length of power supply cable to avoid excessive tension with referring fi... -
Page 13: Airfl Ow Changing
Cable clamp X1, X2: Transmission cable 6.6. External input and external output (Optional parts) Controller PCB Output terminal (CNB01) Apply voltage terminal (CNA03) (CNA01) Dry contact terminal (CNA02) (CNA04) Remote controller cable Y1: Red Cable tie (Medium) Y2: White (Accessories) Y3: Black DIP switch L, N: Power supply cable... - Page 14 ● When function setting is “Operation/Stop” mode. DC power supply [In the case of “Edge” input] P.C.B 12 to 24V Connector Input signal Command Load resistance OFF → ON Operation CNA01 Ch1 of CNA01 or CNA02 ON → OFF Stop P.C.B Load [In the case of “Pulse”...
-
Page 15: Remote Sensor (Optional Parts)
Output select 6.7. Remote sensor (Optional parts) ● When indicator etc. are connected directly • For the installation method, please refer to the INSTALLATION MANUAL of remote P.C.B sensor. Operation Connection methods indicator • Connection terminals Error indicatior Controller PCB Indoor unit Fan status indicator connected unit... -
Page 16: Ir Receiver Unit (Optional Parts)
• Wiring arrangement 6.8. IR receiver unit (Optional parts) Controller PCB • For the installation method, please refer to the INSTALLATION MANUAL of IR receiver unit. Connection methods • Connection terminals Controller PCB Cable tie One touch bushing (Field supply) (Accessories)* Note (*): Remove the mounted cover, and mount the one touch bushing (Accessory). -
Page 17: Custom Code Setting
(1) Indoor unit address 7.2. Custom code setting Rotary switch (IU AD × 1)...Factory setting “0” Rotary switch (IU AD × 10)...Factory setting “0” Selecting the custom code prevents the indoor unit mix-up. When connecting multiple indoor units to 1 refrigerant system, set the address at IU AD SW as shown in the Table A. -
Page 18: Function Setting
7.4. Function setting 9. CHECK LIST • FUNCTION SETTING can be performed with the wired or wireless remote controller. Pay special attention to the check items below when installing the indoor unit(s). After (The remote controller is optional equipment) installation is complete, be sure to check the following check items again. •... - Page 19 Error indications Wired Remote Controller Error Error contents OPERATION TIMER lamp FILTER lamp code lamp (green) (orange) (red) Coil (Expansion value) error Water Drain Abnormal (15) Outdoor unit error (13) RB unit error Display mode : 0.5s ON / 0.5s OFF : 0.1s ON / 0.1s OFF ( ) : Number of fl...
