2.3

Connected State

When the above steps have been completed successfully, the Advantage IP Executive will
connect to the Advantage system, and the display will indicate the date, time and extension
number. The Advantage IP Executive now has access to the full range of system features and
functions in the same way as any other digital extension.
2.4

Unconnected State

Once the phone is in the connected state, the IP settings are no longer accessible. In order to
check or change the IP settings it is necessary to return the phone to the unconnected state.
This can be done by pressing the Menu button and holding it for more than 5 seconds.
In the unconnected state the following menu options can be verified or changed:
Local IP Parameters
Server IP Parameters
Registration Info
Audio Settings
Restart Phone
View log
MAC address
Change Language
Firmware Upgrade
Restore defaults
QoS settings
Disable all QOS
Encryption
2.5

Programming the phone with a web browser

The Advantage IP Executive may be programmed via a web browser interface. Open a browser
on any PC that is on the same LAN and point it to the IP address of the Advantage IP Executive.
Authentication details are as follows:
Username: admin
Password: 1000
There is an online context sensitive help on each page to guide you.
DHCP Client
Current Settings
Change IP Address
Change Subnet Mask
Change Gateway
Current Settings
Change IP Address
Change Alt IP
Change SIG Port
Change RTP Port
Extension Name
Extension PIN
Codec
Frame size
Silence Compression
Request Firmware
Set FTP Server
VLAN Tagging
Diffserv
Advantage IP Executive Installation Guide
9
