Advantage IP Executive Installation Guide

Step 5 Enter the address of the Advantage System

The Public Internet fixed IP address of the Advantage system is entered here. This is necessary
to allow the phone to connect to the Advantage system using the public Internet.
Enter Server IP:
000.000.000.000
Next
Press next when the IP address has been entered.

Step 6 Extension Name and PIN

The Advantage system administrator must allocate a unique extension name and extension PIN
to each IP phone connected to the system. The procedure for this is described in section 4 of
this document. This extension name and PIN must be entered in the Advantage IP Executive. If
you do not know the extension name and PIN, contact the system administrator and obtain
them. When the phone registers with the Advantage system through the public Internet, this
unique extension name and PIN are authenticated.
At the prompts, enter the Extension Name from the phone keypad. Please pay particular
attention to upper case and lower case letters.
Extension Name
_
Next
Press Next and proceed to enter the Extension PIN.
Extension Pin
Enter Pin: _
Next
Press Next to proceed to step 7.

Step 7 Quality of Service

The last option in the wizard allows you to enable quality of service. Once you have answered
Yes or No to this question, the setup wizard is complete and the Advantage IP Executive will
attempt to connect to the Advantage system over the public Internet.
Enable
Quality of Service ?
Yes
During this time the phone will display the message:
Connecting to
Advantage at
213.031.079.150
Please wait...
8
Delete
No
