Dale Power Solutions Ltd

User Manual

E400 Series UPS
E420
E430
E440
E460
E480
Dale Power Solutions Ltd
Salter Road, Eastfield Industrial Estate, Scarborough, North Yorkshire YO11 3DU, United Kingdom
Telephone: +44 (0) 1723 583511 Email:
info@dalepowersolutions.com www.dalepowersolutions.com
Registration No 941798 England
S5264FU09 Rev 2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the E420 and is the answer not in the manual?

Questions and answers

Related Manuals for Dale Power Solutions E420

Summary of Contents for Dale Power Solutions E420

  • Page 1: User Manual

    Dale Power Solutions Ltd User Manual E400 Series UPS E420 E430 E440 E460 E480 Dale Power Solutions Ltd Salter Road, Eastfield Industrial Estate, Scarborough, North Yorkshire YO11 3DU, United Kingdom Telephone: +44 (0) 1723 583511 Email: info@dalepowersolutions.com www.dalepowersolutions.com Registration No 941798 England...
  • Page 2 Dale Power Solutions plc own the copyright to this document, which may not be copied, reproduced or disclosed to a third party without written permission. Dale Power Solutions plc reserves the right to make changes in specification without notice or liability. All information is subject to Dale Power Solutions plc own data and is considered accurate at time of publishing.

  • Page 3: Table Of Contents

    Contents Safety ................................5 Warning symbols ............................5 Conformity and standards ..........................6 Energy conservation and environmental protection ................6 Product description .............................7 Applications ............................... 7 Product range ............................7 System block diagram ..........................8 Split bypass input ..............................8 Static transfer switch ............................8 Battery temperature compensation ......................
  • Page 4 Inverter information ............................. 25 Battery information .............................. 25 State information ..............................25 Parallel information ............................. 26 Command information ............................26 Setting information .............................. 26 Recorded events list ............................26 Version information ............................. 27 Change settings ............................27 LCD display messages ........................... 29 Maintenance ..............................

  • Page 5: Safety

    Safety instructions in this manual are supplementary to local safety instructions. Dale Power Solutions plc does not accept any liability caused as a result of failure to follow safety instructions. Please note the following: Do not use the UPS for any other purpose than the one for which it was designed.

  • Page 6: Conformity And Standards

    Conformity and standards This equipment complies with CE directives 73/23 & 93/68 (LV Safety) and 89/336 (EMC), and the following product standards for Uninterruptible Power System (UPS): IEC 62040-1-1 General and safety requirements for use in operator access area IEC 62040-2 EMC requirements; Class C3 compliant IEC 62040-3 Performance requirements and test methods Caution: Continued compliance requires installation in accordance with the instructions this manual and the use of manufacturer approved accessories only.

  • Page 7: Product Description

    The following table lists the models available in the E400 series. All models are designed to operate with an external battery. Capacity 20 kVA 30 kVA 40 kVA 60 kVA 80 kVA Model E420 E430 E440 E460 E480 Battery location External E420, E430, E440 E460, E480...

  • Page 8: System Block Diagram

    System block diagram The UPS is connected between the mains a.c. input source and the critical load to provide uninterruptible power free from disturbances on the mains supply such as voltage and frequency variations. This is achieved using high-frequency double-conversion pulse width modulation (PWM) and full digital signal processing (DSP) control.

  • Page 9: Battery Temperature Compensation

    Battery temperature compensation Using optional external battery temperature sensors the UPS is capable of optimising the battery charger output to enhance battery life and performance. This is a non-standard feature that must be purchased separately. Contact your distributor for details. Redundant control power supply board The UPS is equipped with two identical and fully redundant control power supply boards.

  • Page 10: Installation

    Installation Siting considerations Before unpacking and installing the unit, consider the following: DONOT expose the UPS to high temperatures, water ingress, flammable or corrosive gas, dust, direct sunlight or explosives. Locate the UPS indoors on a level surface as close as possible to the equipment it will be powering to minimise cable voltage drops.

  • Page 11: Units In Parallel

    Input Load MCCB (not MCB) Figure 2 Power cable wiring configuration for a single UPS Units in parallel A group of paralleled units behave as if it were one large UPS. To ensure units share the load equally and the system complies with relevant wiring regulations, follow these requirements: Use units of the same rating only and connect them to the same bypass source.

  • Page 12: Operation From A Generator

    Operation from a generator As a guide we recommend that the load capacity should be less than 30% of the generator capacity, and the generator rating should be 1.5 to 2 times the rating of the UPS, depending on the type of generator used.

  • Page 13: Internal Layout (Door Open)

    Mains breaker Power terminals Figure 3 E420, E430 and E440 internal layout Note: E460/E480 units are taller and the E480 is fitted with larger breakers and terminals in the lower part of the cabinet. Terminal and battery connections vary from those shown above.

  • Page 14: Wiring The Ups

    Wiring the UPS Before connecting the UPS, read the siting considerations above and check you have selected breakers and cables with the correct ratings. WARNING! BEFORE ATTEMPTING TO WIRE THE UPS ENSURE ALL BREAKERS ARE IN THE OFF POSITION AND WHERE POSSIBLE LOCKED OFF. Caution: DO NOT mix batteries from different manufacturers or mix different types of batteries.
  • Page 15 BAT− L1 Battery 1 Battery 2 Main input Bypass input Output (split bypass systems only) Figure 5 Cable connections for E420, E430, E440 and E460 units Battery centre tap Links removed in a split bypass system Input Output BAT+ Battery BAT−...
  • Page 16 Check the following: E480: that the links in Figure 6 have been removed. E420/E430/E440/E460: that the short breaker links are fitted (Figure 7). Shortened breaker links Figure 7 E420, E430, E440, E460 breakers linked for split bypass operation b. Wire the split bypass input as follows: E420/E430/E440/E460: to Bypass input (Figure 5)

  • Page 17: Wiring Units In Parallel

    Wiring units in parallel You can operate 2, 3 or 4 units in parallel. Caution: Each unit requires its own battery bank. You cannot use a common battery bank for more than one unit working in parallel mode. When operating units in parallel you must not use the built-in bypass as it is rated for one unit only.
  • Page 18 3. Below the black start switch on each UPS, remove the plate that covers the parallel connectors. 4. Connect the CAN bus, labelled Parallel Port 1 and Parallel Port 2, in a ring arrangement using the supplied cables as shown below. Make sure you wire all CAN bus connectors and secure them in place using their captive screw locks.

  • Page 19: Operation

    Operation Working modes The UPS has the following modes of operation: On-line mode Battery mode Auto-restart mode Bypass mode ECO mode Frequency converter mode Each operating mode is described below. On-Line mode This is the default mode of operation in which the load is supplied via the inverter when the a.c. input and load are within their normal ranges.

  • Page 20: Eco Mode

    ECO mode If specified, your UPS may be set to operate in ECO mode instead of on-line mode. In ECO mode the load is supplied via the bypass circuit and not the inverter, allowing the UPS to work at higher efficiency. The battery is trickle charged in this mode.

  • Page 22: Commissioning Test Procedure

    5. Switch on the UPS main breaker. After a few seconds the Mains and Inverter LEDs are illuminated and the Bypass LED goes out (see Figure 9 on page 23). Note: If switching on into a transformer load, ensure the UPS is initially working in bypass mode before switching to on-line mode.

  • Page 23: Front Panel Controls And Indicators

    Front panel controls and indicators The front panel controls and indicators are shown in Figure 9. Using the buttons, LEDs and the menu structure displayed on the LCD panel you can: Check the status of the UPS Check and make changes to the settings Note: Your UPS is setup to your requirements by the distributor prior to delivery.

  • Page 24: Navigating The System Menu

    The following table describes the button functions: Button Definition Press to confirm an operation or enter a lower menu level Press to cancel an operation or return to the previous menu level Press to select another menu item or change a parameter Press to select another menu item or change a parameter Press to view event and alarm logs 0 to 9...

  • Page 25: Output Information

    Output information Inverter information Battery information State information...

  • Page 26: Parallel Information

    Parallel information Command information Setting information Recorded events list This page shows up to 120 of the most recently recorded events (normal operation and fault information).

  • Page 27: Version Information

    Version information Change settings At the time of installation your installer will alter the settings to meet your order requirements, however if you need to make a change, use the following procedure. To change a system setting: 1. Press to highlight the Setting tab. 2.
  • Page 28 Setting Parameter Description Backlight Delay Adjust how long the backlight stays on for in minutes Contrast Adjust the display contrast Work Mode Single (default, stand-alone UPS in on-line mode) ECO (single UPS only, UPS in off-line high efficiency mode) Master (sets UPS as master in a master/slave system) Slave (sets UPS as a slave in a master/slave system) Parallel LBS Setting...

  • Page 29: Lcd Display Messages

    Max charge current Set to 10% of the battery Ah capacity rating in amperes. _ _ A (E420 and E430, 1 to 15 A; E440, E460 and E480, 1 to 30 A in 1 A steps) LCD display messages Display messages appear on the bottom line of the LCD display.

  • Page 30: Maintenance

    Maintenance At normal room ambient temperature the fans will operate continuously for 20,000 to 40,000 hours. Increased ambient temperatures will shorten this lifetime. Periodically ensure that air is blowing out of the rear of the unit. Battery We recommend the use of sealed lead acid, maintenance free batteries. Battery life depends on the ambient temperature and the number of discharge/charge cycles.

  • Page 31: Function Check

    Function check Perform the following function checking every 6 months: 1. Press the INVERTER OFF button to ensure the buzzer, indicators and LCD are operating normally. 2. Press the INVERTER ON button. Check the indicators, LCD and UPS inverter, and ensure they are working normally.

  • Page 32: Alarm Information

    Display message Description boost charge mode Positive battery float charging The positive batteries are being float charged Negative battery boost charging The negative batteries are in constant-voltage or constant-current boost charge mode Negative battery float charging The negative batteries are being float charged Int.
  • Page 33 Display message Description to work but the FPSU must be replaced. DC bus over voltage Rectifier, inverter and battery converter shutdown DC bus below voltage Rectifier, inverter and battery converter shutdown DC bus unbalance The difference between the positive and negative DC buses exceeds 30 V Mains site wiring fault Wrong input phase rotation...

  • Page 34: Frequently Asked Questions

    Display message Description Overload The load exceeds the UPS capacity Parallel overload DC component over limitation The DC component exceeds the specified value Bypass over current An over current alarm is given Ext. fire alarm External fire detector has been activated Ext.

  • Page 35: Appendix 1 Signals Options

    Appendix 1 Signals options RS232 serial port E400 series units are fitted with a standard RS232 serial port, which can be used to: Monitor the UPS power status Monitor the UPS alarm information Monitor the UPS running parameters Perform a battery test To enable RS232 control: 1.

  • Page 36: Snmp Card With Environmental Monitor

    SNMP card with environmental monitor If your unit is fitted with the optional SNMP card (located in the Intelligent Slot on the front panel), connect it to your computer with a network cable. You can also connect a modem and environment controls as shown in Figure 12.

  • Page 37: Relay Card (Monitoring And Control)

    Relay card (monitoring and control) E400 series units are fitted with a relay card (located in the Intelligent Slot, see Figure 3 on page 13) you have access to monitoring and control functionality via a set of dry contacts and a single opto-coupled input.

  • Page 38: Dry Contact Relay Signals

    To connect to the relay card: 1. Unlock and open the front door. 2. On the front panel, unscrew the card and slide it out completely or sufficiently to access the terminal block. 3. Using the information in the tables above, wire your signal cables to the terminal block (Figure 13). 4.

  • Page 39: Battery Temperature Sensor

    Connections: Signal name Description Provides a +12 V 100 mA isolated supply on each connector row FIRE Fire alarm input signal SMOG Smog alarm input signal SURGE Surge alarm output signal No connection BP_C Anti-backfeed relay common BP_S Anti-backfeed relay normally open To prevent the input being energised by backfeeding in the event of an internal failure, connect this signal to an external circuit breaker trip Generator signal input...

  • Page 40: Appendix 2 Parallel Operation

    Appendix 2 Parallel operation The following signals are available on each UPS for parallel operation: Parallel port connectors. These must be connected as described in Wiring units in parallel on page 17. LBS (Load Bus Synchronisation) signals. These may be used to synchronise two paralleled systems as described below.

  • Page 41: Appendix 3 Specifications

    Appendix 3 Specifications Electrical Model E420 E430 E440 E460 E480 Capacity 20 kVA 30 kVA 40 kVA 60 kVA 80 kVA Input Input current (maximum) 40 A 63 A 80 A 125 A 160 A Power factor 0.99 Input type...
  • Page 42 Output Overload 110%, 1 h 125%, 10min 150%, 1min bypass mode: 125% to 170%, 10 min Bypass and ECO voltage range Adjustable via the LCD panel using ‘bypass volt upper limit’ and ‘bypass volt lower limit’ Efficiency in line mode Efficiency in battery mode 20/30 kVA, 93%: 40/60/80 kVA, 94% Efficiency in ECO mode...

  • Page 43: Mechanical

    Height (mm) 1200 1800 Width (mm) Depth (mm) Net weight (gross weight) E420: 186 kg (226 kg) E430: 192 kg (232 kg) E440: 201 kg (248 kg) E460: 297 kg (354 kg) E480: 312 kg (369 kg) Audible noise <56 dB (1m)
