TRIUMPH BOARD 55” MULTI Touch LED LCD User Manual

Hide thumbs Also See for 55” MULTI Touch LED LCD:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
User Manual v 2.2
March 2015
MULTI Touch LED LCD Series
TRIUMPH BOARD 55" MULTI Touch LED LCD
TRIUMPH BOARD 65" MULTI Touch LED LCD
TRIUMPH BOARD 70" MULTI Touch LED LCD
TRIUMPH BOARD 84" MULTI Touch LED LCD
TRIUMPH BOARD a.s., Neklanova 122/15, 128 00 Praha 2, Czech Republic, European Union, www.triumphboard.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 55” MULTI Touch LED LCD and is the answer not in the manual?

Questions and answers

Related Manuals for TRIUMPH BOARD 55” MULTI Touch LED LCD

Summary of Contents for TRIUMPH BOARD 55” MULTI Touch LED LCD

  • Page 1 TRIUMPH BOARD 55” MULTI Touch LED LCD TRIUMPH BOARD 65” MULTI Touch LED LCD TRIUMPH BOARD 70” MULTI Touch LED LCD TRIUMPH BOARD 84” MULTI Touch LED LCD TRIUMPH BOARD a.s., Neklanova 122/15, 128 00 Praha 2, Czech Republic, European Union, www.triumphboard.com...

  • Page 2: Table Of Contents

    Contents 1. Product Description ....................5 2. Technical specifications ..................6 3. Safety Warning ...................... 9 Placement ............................9 Power Supply ............................ 9 Screen ..............................9 Range of Visibility ..........................9 Temperature ............................9 Humidity ............................. 9 Ventilation ............................10 Headphones ............................
  • Page 3 8. Menu Operation ....................22 One Touch menu operation ......................22 Setting menu ........................... 22 Input setting ..........................22 Brightness settings ........................23 Volume adjustment ........................23 9. More Settings (advanced settings) ..............24 Android channel ..........................24 VGA channel ............................ 25 Screen Setting ..........................
  • Page 4 DECLARATION OF CONFORMITY We TRIUMPH BOARD a.s., Neklanova 122/15, 128 00 Praha 2 Declare under sole responsibility that the product: TRIUMPH BOARD MULTI Touch LED LCD Series Model: 55” MULTI Touch LED LCD, 65” MULTI Touch LED LCD 70” MULTI Touch LED LCD, 84” MULTI Touch LED LCD...

  • Page 5: Product Description

    Engage the audience with the presentation with direct control of the computer through the LED LCD MULTI Touch. TRIUMPH BOARD MULTI Touch LED LCD – no need for a projector! Easy installation! No limitations caused by light conditions! Elegant and stylish appearance!

  • Page 6: Technical Specifications

    2. Technical specifications TRIUMPH BOARD 55“ MULTI Touch LED LCD EAN: 8592580111891 Screen Type: TFT LCD/ A Standard/ LED backlight Resolution: 1920 x1080 Refreshing Sequence: 6 ms, 60 Hz, 1400:1 Display Area: 1209.6(H) × 680.4(V) Outline Dimension: 1369 x 828 x 102 mm...
  • Page 7 Touch System Sensing Type: Infrared Transmission (multi-touch) Response Time: < 15ms Response Area: > ø 5mm Scan Frequency: 100Hz Output Coordinates: 32767×32767 Communication Mode: Full-speed USB Writing Screen: Mohs hardness of 7 PC System: Optional Inputs and Outputs 3 / 4 (1xHDMI 4K, HDMI: 1xHDMI MHL, 2xHDMI)
  • Page 8 TRIUMPH BOARD MINI PC6A for MULTI Touch LED LCD Series EAN: 8592580111877 Processor: Intel i5 Graphics: Integrated Intel® HD Graphics Sound Card: Integrated High Definition Audio Stereo Networking: Integrated 10/100/1000 Mbps adapted Memory: 4 GB DDRIII Hard Drive: 500 GB SATA WIFI: 802.11 a/b/g/n, 2x2, dual-band WiFi 2,4/5 GHz...

  • Page 9: Safety Warning

    3. Safety Warning Before using the machine, please read the instructions carefully. Placement Do not put the machine on surfaces that are unstable, easy to tilt or which can fall. Do not put the machine in places with direct sunlight, or near sources of heat, such as electric heaters or strong light sources.

  • Page 10: Ventilation

    Ventilation Please place the machine in ventilated places, and ensure machine's good heat dissipation. Please ensure ventilation spaces 10 cm on the sides and back, and 20 cm on the top of the machine. Headphones Extended use of headphones at high volumes may damage hearing.. If external headphones/earbuds is needed, please turn down the machine volume in advance.

  • Page 11: Preparing For Installation

    4. Preparing for Installation Unpacking Accessories Quick start guide, remote control, batteries, power cords (UK, US, EU), VGA cable, headphone line, USB line, styluses, USB Flash Drive, AV line and VC Camera Bracket. 2x Stylus Batteries Remote control Quick Start Guide USB Cable Headphone Cable Power Cord (US, UK, EU)

  • Page 12: Control Panel

    Control Panel Number Item Function Description Power on/off HOME HOME button: back to main interface BACK Return button: return to previous level menu MENU Menu button: call up function menu VOL - Volume down button: turn down volume VOL + Volume up button: turn up volume MUTE Mute button: mute volume...

  • Page 13: Terminal Interface

    5. Terminal Interface Items Description of Function Connect USB devices such as mobile hard disk, USB disk, USB keyboard and mouse, USB drives, etc. High-definition multimedia interface signal input, for connecting to PC (personal computer) with HDMI output, set-top box, or other video HDMI IN device and can also implement touch function (HDMI3 can implement MHL function, HDMI4* can implement 4K/2K)

  • Page 14: Remote Control

    6. Remote control Remote control button instructions...

  • Page 15: Detailed Function Description Of Remote Control Buttons

    Detailed function description of remote control buttons Press this button to enter standby mode when power is on; Click this button to switch on in standby mode LCD: Press this button to control your LED LCD screen. Note: Your Remote control has been set-up automatically for the function of your LED LCD.

  • Page 16: Remote Control Use Instructions

    Remote control use instructions Install Batteries 1 Open back cover of battery compartment on the back of remote control 2 Install AAA type batteries according to the corresponding electrode, make sure battery positive and negative poles are correctly placed ("+"to"+", "-" to "-"), please do not mix old and new batteries 3 After batteries are installed, close the back cover of battery compartment, and snap the clip fastener shut against the bottom of the remote.

  • Page 17: Connection And Setting

    7. Connection and Setting CAUTION For the safety of you and the machine, please do not connect any power cord before the external device is prepared. External Computer and Touch Connection USB Cable Audio Cable VGA Cable Computer (1) Use VGA line to connect to VGA output port of external computer, and meanwhile use headphone audio line to connect to external computer audio output interface.

  • Page 18: Audio And Video Equipment

    Audio and video equipment (1) Use AV audio and video lines to connect audio and video equipment with AV output (yellow for video, red for right sound channel, and white for left sound channel) (2) After line connection, plug in power cord, and switch power on to turn equipment on Press (4) Press INPUT key to switch to CVBS port...

  • Page 19: Coaxial Connection

    Coaxial connection (1).Use coaxial line to connect audio device with coaxial input (2). After line connection, plug in power cord, and switch power On (3).Press to turn equipment on Video output connection VGA output connection Computer Computer (1). Use VGA line to connect display devices with VGA input, and use headphone line to connect sound output (2).

  • Page 20: Usb Equipment Connection

    USB Equipment connection Network cable connection Microphone connection WAN connection NOTE: If the user wants the built-in computer and android system to connect to the Internet at the same time, Connect item 6 and item 8 at the same time...

  • Page 21: Usb Equipment Connection

    USB equipment connection Serial port line Computer After using the serial port line to connect central control equipment and the machine, certain functions of the machine can be controlled via the central control equipment, such as: machine ON/OFF, and adjustment of sound volume, etc. PC part basic operations: 1.

  • Page 22: Menu Operation

    8. Menu Operation One Touch menu operation Call up method Take middle point position on the bottom of display screen as starting point, use finger or stylus to drag towards screen center position to call up touch menu, as shown below. Setting menu Input setting Press INPUT button on remote control or via above “A”...

  • Page 23: Brightness Settings

    Brightness settings Press INPUT button on remote control or via touch A method to call up Input Setting menu; Press button on remote control or directly click “Light” icon to enter Brightness setting menu; Press button on remote control or drag brightness adjustment progress bar to adjust brightness;...

  • Page 24: More Settings (Advanced Settings)

    9. More Settings (advanced settings) Android channel Under Android channel, press INPUT button on remote control or via touch method A to call up Settings menu; Press button on remote control or directly click “More” icon to enter advanced settings menu Press button on remote control or click directly to select each option;...

  • Page 25: Vga Channel

    VGA channel Under VGA channel, press INPUT button on remote control or via touch method A to call up settings menu; Press button on remote control under setting menu or directly click “More” icon or directly press Menu on remote control under VGA channel to enter advanced settings menu;...

  • Page 26: Screen Setting

    Screen Setting Under channels other than Android, press Menu button on remote control or via touch method A to call up settings menu; Press button on remote control or directly click “More” icon or directly press Menu on remote control to enter advanced settings menu; Press button on remote control or click directly to select and adjust each option;...

  • Page 27: Annotation Menu

    Annotation menu Fig.1 Fig.2 Place two fingers on the screen (about 20~50mm spacing) and keep in position more than two seconds under any channel to call up annotation menu (Figure 1); In annotation, menu is shown in Figure 2. In annotation state, input only by fingers, stylus and remote control cannot perform annotation operation.

  • Page 28: Android System Interface

    10. Android System Interface Main Interface Switch to Android channel to display main interface as show above; Press key on remote control to select icon below, and press Enter key to enter corresponding program, or directly click the associated icon to enter program; In any program, press Home button on remote control or <Home key>...

  • Page 29: Browser

    1. Storage device display Click with touch pen to enter corresponding storage devices area 2. Menu/exit menu Click menu icon with touch pen to pop up menu options {order (type/size/time)} Click exit icon with touch pen to directly exit resource browse. 3.

  • Page 30: Pip

    Enter channel browse to pop up picture-in-picture interface in displayed image; Press button on remote control or directly click picture-in-picture display interface point, to pop up channel selection list of picture-in-picture, press button on remote control to move selection cursor into channel list, then press button to select corresponding channels.

  • Page 31: Apps

    Apps Caution! Please note that you cannot install your own applications into Apps section! Each application must be suitable for screen resolution and hardware specifications, as some apps may have display or performance problems! Browser See page 29 Settings See page 22 TB Comenius Lite See page 31 TB Comenius Lite...

  • Page 32: Multimedia File Playback Interface

    Select icon Click to select Whiteboard writing symbols, can click or check to select Brush icon Click to write, press long for three seconds to enter setting screen, to set brush color and thickness Eraser icon Click to erase writing symbols, can be erased by box selection Undo icon Click to cancel previous step operation Redo icon...

  • Page 33: Audio Play

    Audio play Close current audio file Play previous audio Play/pause file Play next audio file Playlist Loop play Random play Single play Video play Close current video file played Play previous video File Fast backward Play/pause Fast Forward Play next audio file Playlist...

  • Page 34: Vc Camera Bracket Installation

    12. VC Camera Bracket installation (VC system is not included in the accessory) Note: You need to have TRIUMPH BOARD Videoconferencing System before you start. Please install the bracket on LED LCD when you unpack the unit, before wall mounting.

  • Page 35: Troubleshooting

    13. Troubleshooting Board fails to work normally 1. Check whether there are other objects between remote control and television remote control receiving window, blocking signal transmission and thus leading to failure of remote control. Remote control failure 2. Check whether the battery terminal in the remote control is correctly connected. 3.

  • Page 36: Maintenance

    14. Maintenance Proper maintenance can prevent many early defects; regular, careful cleaning can keep the machine like brand new. Please unplug power plug before cleaning and maintenance, to prevent electric shock. Clean screen Mix a small amount of fabric softener or dishwashing detergent with warm water.

  • Page 37: Repair Service And Contacts

    Please contact your local supplier for the warranty and technical service or find all warranty conditions and service partners on our website www.triumphboard.com. For any questions please email us to info@triumphboard.com TRIUMPH BOARD a.s. Neklanova 122/15 128 00 Praha 2...
