Revision History - Benchmark DAC1 Instruction Manual

Benchmark Media Systems, Inc.

Revision History:

Revision Filename
A DAC1 – Manual – Rev A. Doc
B DAC1 – Manual – Rev B. Doc
C DAC1 – Manual – Rev C. Doc
D DAC1 – Manual – Rev D. Doc
E DAC1 – Manual – Rev E. Doc
F DAC1 – Manual – Rev F. Doc
G DAC1 – Manual – Rev G. Doc
H DAC1 – Manual – Rev H. Doc
I DAC1 – Manual – Rev I. Doc
J DAC1 – Manual – Rev J. Doc
K DAC1 – Manual – Rev K. Doc
L DAC1 – Manual – Rev L. Doc
M DAC1 – Manual – Rev L. Doc
N DAC1 – Manual – Rev L. Doc
Manual Revision Notes:
Revision Note
I Added 176.4 and 192kHz phase and latency specifications.
J Updated PCB revision notes for PCB revision G.
K Corrections on page 17 – factory default
L RoHS notes and Warranty update, Corrections on page 9 – 192 kHz Optical Input
M Clarification to calibration 'Caution' statement
N Updated output levels in variable mode
PCB Revision Notes:
PCB Rev. Note
C Added internal 10, 20, and 30 dB pads with jumpers for XLR outputs.
F Changed unbalanced output impedance to 30Ω Ω Ω Ω , upgraded optical input for 192kHz
capability, reduced DC offsets, added balance trim pot.
G Minor change to BUF634 mounting pads. No circuit or performance changes.
Date PCB Rev.
10/01/02 A
11/27/02 A
05/08/03 C
07/11/03 C
08/04/03 C
03/01/04 C
06/03/04 C
11/22/04 F
01/13/06 F, G
03/08/06 F, G
05/16/06 F, G
01/31/07 F, G
01/10/09 F, G
10/26/09 F, G
