Adaptec AUA-3121 User Manual

Adaptec AUA-3121 User Manual

Duoconnect adapter
Hide thumbs Also See for AUA-3121:

Advertisement

Quick Links

Download this manual See also: User Manual, Installation Manual
R
U
'
G
SER
S
UIDE
A
AUA-3121
DAPTEC
D
C
A
UO
ONNECT
DAPTER

Advertisement

loading
Need help?

Need help?

Do you have a question about the AUA-3121 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Adaptec AUA-3121

Summary of Contents for Adaptec AUA-3121

  • Page 1 ’ UIDE AUA-3121 DAPTEC ONNECT DAPTER...
  • Page 2 Copyright ©2001 Adaptec, Inc. All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording or otherwise, without the prior written consent of Adaptec, Inc., 691 South Milpitas Blvd., Milpitas, CA 95035.
  • Page 3 Adaptec Customer Support If you have questions about installing or using your Adaptec product, check this document first—you will find answers to most of your questions here. If you need further assistance, use the support options listed below. Technical Support Identification (TSID) Number Before contacting Technical Support, you’ll need your TSID.
  • Page 4 Monday to Thursday, 9:30 to 12:30 and 13:30 to 16:30; Friday, 9:30 to 12:30 and 13:30 to 15:00, Central European Time. To expedite your service, have your computer in front of you. To order Adaptec products, including accessories and cables, call +32 11 300 379. Australia and New Zealand Visit our Web site at http://www.adaptec.com.au...
  • Page 5 Limited 5-Year Hardware Warranty 1. Adaptec, Inc. (“Adaptec”) warrants to the purchaser of this product that it will be free from defects in material and workmanship for a period of five (5) years from the date of purchase. If the product should become defective within the warranty period, Adaptec, at its option, will repair or replace the product, or refund the purchaser’s purchase price for the product,...
  • Page 6 Software is furnished will be free from defects in material or workmanship under normal use and service for a period of thirty (30) days from the date of delivery to you. ADAPTEC AND ITS LICENSORS DO NOT AND CANNOT WARRANT THE PERFORMANCE OR RESULTS YOU MAY OBTAIN BY USING THE SOFTWARE OR DOCUMENTATION.
  • Page 7 This warranty gives you specific legal rights and you may also have other rights which vary from state to state. 8. The entire liability of Adaptec and its licensors, and your exclusive remedy for a breach of this warranty, shall be: a.
  • Page 8 (1) this device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation. Adaptec, Inc. AUA-3121 DuoConnect Tested to Comply With FCC Standards FOR HOME OR OFFICE USE...
  • Page 9 Canadian Compliance Statement This Class B digital apparatus meets all requirements of the Canadian Interference- Causing Equipment Regulations. Cet appareil numérique de la classe B respecte toutes les exigences du Règlement sur le matériel brouilleur du Canada. Japanese Compliance (Voluntary Control Council Initiative)
  • Page 10 This guide explains how to install the DuoConnect Host Bus Adapter in a PCI slot and how to install its associated drivers. It also describes how to connect a USB device and a digital video camera. Overview The DuoConnect adapter allows you to connect USB 1.1 (EHCI), USB 2.0 (OHCI), and FireWire (IEEE 1394) devices to your PC- compatible or Macintosh computer.

  • Page 11: Kit Contents

    G3s. For the latest information on Mac OS X support, see the file on the DuoConnect CD-ROM or Readme check the Adaptec Web site at http://www.adaptec.com Other Requirements Available PCI slot (32- or 64-bit, 3.3 or 5-volt compatible, 33- or...

  • Page 12: Installing The Duoconnect Adapter

    Installing the DuoConnect Adapter Installing the DuoConnect Adapter 1 Discharge any static electricity from your body by touching a grounded metal object (such as the exposed metal parts on the back of your computer). 2 Turn off power to the computer and disconnect the power cord. 3 Open the computer cabinet.
  • Page 13 This connector supplies optional bus power to the FireWire ports. If your system does not have a spare power connector, you can buy one at www.adaptec.com Adapter power connector System power connector 7 Close the computer cabinet and reattach the power cord.

  • Page 14: Installing The Windows Drivers

    Description USB 1.1 NEC USB OHCI-compliant USB 2.0 Adaptec AUA-3121 PCI to USB EHCI-compliant FireWire Texas Instruments OHCI-compliant IEEE 1394 When successfully installed, these controllers are displayed separately in the Windows Device Manager. Keep in mind the following notes if they apply to your computer.
  • Page 15 Installing the Windows Drivers 3 The Found New Hardware Wizard opens. Click Next. 4 On the Install Hardware Device Drivers window, select Search for a suitable driver for my device (Recommended), and click Next.
  • Page 16 Installing the Windows Drivers 5 On the Locate Driver Files window, uncheck all options except CD-ROM drives, and click Next. 6 On the Driver Files Search Results window, ensure that the Install one of the other drivers check box is not checked, and click Next. 7 When Windows is finished copying drivers, click Finish.
  • Page 17 Installing the Windows Drivers 8 Restart your computer. 9 To verify that the driver is installed, right-click the My Computer desktop icon, select Properties, click the Hardware tab, and click the Device Manager button. Then, expand IEEE 1394 Bus host controllers and Universal Serial Bus Controllers.
  • Page 18 Installing the Windows Drivers Windows Me 1 Turn on or restart your computer. 2 Insert the DuoConnect CD-ROM. 3 When the Add New Hardware Wizard appears, select Automatic search for a better driver (Recommended) and click Next. 4 After the driver is copied, click Finish. 5 Windows will now install the FireWire drivers.
  • Page 19 Installing the Windows Drivers 7 If you see a message that the PCI Universal Serial Bus driver was not located, select Automatic search for a better driver (Recommended). Then, insert the DuoConnect CD-ROM and click Next. 8 When Windows has finished copying the USB 2.0 drivers from the DuoConnect CD-ROM, click Finish.
  • Page 20 Installing the Windows Drivers 10 To verify that the driver is installed, right-click the My Computer desktop icon, select Properties, and click the Device Manager tab. expand 1394 Bus Controller and Universal Serial Bus Controllers. You should find the information shown below. FireWire controller USB 2.0 controller USB controllers...
  • Page 21 Installing the Windows Drivers Windows 98 SE 1 Turn on or restart your computer. 2 Insert the DuoConnect CD-ROM. 3 When the Add New Hardware Wizard opens, click Next. 4 Select Search for the best driver for your device (Recommended), and click Next. 5 In the window shown below, uncheck all options and click Next.
  • Page 22 Installing the Windows Drivers 6 In the window shown below, click Next. 7 Click Next again. If Windows prompts you to restart your computer, click No. 8 When the Add New Hardware Wizard opens, click Next. 9 Select Search for the best driver for your device (Recommended), and click Next.
  • Page 23 Installing the Windows Drivers 10 In the window shown below, uncheck all options and click Next. 11 Select The updated driver (Recommended), and click Next.
  • Page 24 Installing the Windows Drivers 12 You may see a message that Windows is searching for the driver. Click Next. 13 When you see the following prompt, insert your Windows 98 SE CD-ROM and click OK. 14 Type the drive letter for your CD-ROM drive (which may be , etc.) in the Copy files from box, as shown below, and click OK.
  • Page 25 Installing the Windows Drivers 15 When the third driver has been copied onto your system, the following window appears. Click Finish. 16 Now, the driver for the first OHCI (USB 1.1) controller is installed. To install the driver for the second OHCI controller, repeat steps through 15.
  • Page 26 Installing the Windows Drivers 18 Select Search for the best driver for your device (Recommended), and click Next. 19 Check the CD-ROM drive option, insert the DuoConnect CD-ROM, and click Next.
  • Page 27 Installing the Windows Drivers 20 Select The updated driver (Recommended), and click Next. 21 Windows will show you the location of the driver. Click Next. 22 When Windows is finished copying files, click Finish. 23 Windows will now install the FireWire drivers. When the wizard starts, click Next.
  • Page 28 Installing the Windows Drivers 25 In the window shown below, uncheck all options and click Next. 26 Select The updated driver (Recommended), and click Next. 27 You may see a message that Windows is searching for the driver. Click Next.
  • Page 29 Installing the Windows Drivers 28 When you see the following prompt, insert your Windows 98 SE CD-ROM in your CD-ROM drive and click OK. 29 Type the drive letter for your CD-ROM drive (which may be , etc.) in the Copy files from box, as shown below, and click OK. Note: If you have copied your driver files onto your hard drive and know where they are located, you can browse to that folder instead of inserting the Windows 98 SE CD.
  • Page 30 Installing the Windows Drivers 30 When the following window appears, click Finish.
  • Page 31 Installing the Windows Drivers 31 To verify that the drivers are installed, right-click the My Computer desktop icon, select Properties, and click the Device Manager tab. Then, expand IEEE 1394 Bus Controller and Universal Serial Bus Controllers. You should find the information shown below.

  • Page 32: Installing The Macintosh Driver

    Installing the Macintosh Driver Installing the Macintosh Driver In this procedure, you install the DisableSleep driver, which prepares your Macintosh computer to use the DuoConnect card. Note: Blue and white G3s are not supported. 1 Turn on or restart the computer and insert the DuoConnect CD. 2 Double-click the Start Installation Here file on the CD.
  • Page 33 If you do not see the adapter listed, verify that the Apple USB extensions are loaded and enabled. Also, verify that the adapter is seated properly. If you are still unable to resolve a problem, see the Adaptec Web site at or the Adaptec Support Knowledgebase http://www.adaptec.com...
  • Page 34 Installing the Macintosh Driver DuoConnect and Deep Sleep The DuoConnect adapter does not support Deep Sleep on Power Macintosh G4 computers. When you use the DuoConnect installer as described on page 23, the DisableSleep driver (shown at right) is installed and the Deep Sleep feature is disabled.

  • Page 35: Connecting Usb Devices

    Connecting USB Devices Connecting USB Devices You can connect standard USB 1.1 or high-speed USB 2.0 devices to the connectors of the DuoConnect adapter, as shown below. Hotplugging The DuoConnect adapter supports hot-plugging, allowing USB devices to be attached and recognized while the computer is on. Device manufacturers support hot-plugging in different ways.
  • Page 36 Connecting USB Devices Connecting a Digital Video Camera Two types of FireWire connectors are commonly used: a 4-pin and a 6-pin. The DuoConnect adapter contains two external 6-pin connectors suitable for use with a camera. Digital video cameras use a 4-pin connector and may not include a cable. (Other peripherals typically use a 6-pin connector.) To attach a digital video camera 1 Using a standard 6-to-4 pin FireWire cable (included in the kit)

  • Page 37: Troubleshooting

    Is the cable properly connected to the DuoConnect adapter and the device? Is the adapter seated evenly in the PCI slot? Are your drivers current? Check for the http://www.adaptec.com latest driver availability. If you encounter any problems with the software, check the User’s Guide and file on the CD-ROM.
  • Page 38 Adaptec, Inc. 691 South Milpitas Boulevard Milpitas, CA 95035 USA © 2001 Adaptec, Inc. All rights reserved. Adaptec and the Adaptec logo are trademarks of Adaptec, Inc. which may be registered in some jurisdictions. : 512925-06, Ver. AC MKL 08/01...
