  • Page 1 ’ EFERENCE SCSI C 2906...
  • Page 2 691 South Milpitas Boulevard Milpitas, CA 95035 © 1998 Adaptec, Inc. All rights reserved. Adaptec, and the Adaptec logo are trademarks of Adaptec, Inc. which may be regis- tered in some jurisdictions. Printed in Singapore STOCK NO.: 512170-00 Rev. A MPO 11/98...
  • Page 3 AVA-2906 SCSI Card 2906 User’s Reference...

  • Page 5: Table Of Contents

    Hard Disk Drives 13 Scanners 13 Installing Multiple SCSI Cards 14 Using SCSI and IDE (or EIDE) Devices 14 Replacing a Non-Adaptec SCSI Card with an Adaptec SCSI Card 14 Configuring the SCSI Card 2906 with SCSI Select 15 Starting SCSISelect 16...
  • Page 6 SCSI Card 2906 User’s Reference Obtaining SCSI Cables 20 External Cables 20 External Connector Diagrams 20 Internal Cable 21 Internal Connector Diagrams 21 Maximum Cable Lengths 21 Contacting Adaptec 23 Electronic Support 23 Technical and Product Support 24 Sales and Ordering Information 24...

  • Page 7: Understanding Scsi

    SCSI devices (such as a hard disk drive, CD-ROM drive, or scanner) to a common SCSI bus. A SCSI bus is an electrical pathway that consists of a SCSI card (such as the SCSI Card 2906) installed in a computer and one or more SCSI devices.

  • Page 8: Scsi Ids

    SCSI ID 7 has the highest priority on the SCSI bus. The priority of the remaining IDs, in descending order, is 6 to 0. Adaptec presets the SCSI Card 2906 to SCSI ID 7, giving it the highest priority on the SCSI bus. You should not change this setting.

  • Page 9: Terminating The Scsi Bus

    To ensure reliable communication on the SCSI bus, you must termi- nate both ends of the SCSI bus. If the SCSI Card 2906 is connected at one end of the SCSI bus, you must still terminate the device at the other end.

  • Page 10: Troubleshooting

    PCI slots, select Enabled. Bus mastering must be enabled. Check your computer documentation for more information on bus mastering. – If there is an option to enable or disable individual PCI slots, be sure the slot in which you install the SCSI Card 2906 is Enabled.

  • Page 11: Troubleshooting Questions And Answers

    Click the Device Manager tab. Double-click the SCSI Controller icon. The driver for the SCSI Card 2906 is listed as Adaptec AIC-7850 PCI SCSI Controller. If the driver is listed without any extra 95/98 symbols or marks, the SCSI Card 2906 driver is loading properly.
  • Page 12 Note: Software upgrades (including downloadable drivers) for Adaptec products are available on the Adaptec Web Site at http://www.adaptec.com . Why does an “X” inside a red circle appear by the SCSI Card 2906 software driver in Device Manager? The SCSI Card 2906 software driver is disabled and isn’t loading.
  • Page 13 In the System Properties window, open the Performance tab. One of the following messages may appear: The Master Boot Record has been modified. Your system is configured for optimal performance. <Drive letter> using MS-DOS compatibility mode file system. SCSI Card 2906 User’s Reference See Page...
  • Page 14 If the second message (b) appears, you must update or install the driver. For information on downloadable drivers, refer to the Adaptec Web Site http://www.adaptec.com/support/index.html. Click on the Drivers section for more information on how to download the correct driver.
  • Page 15 In the screen above, setting 10 is not listed and, therefore, is an available IRQ. Note: Do not use an IRQ below IRQ 9 for a SCSI Card 2906. Do not allow the SCSI Card 2906 and another card to share the same IRQ.
  • Page 16 Select Yes on the second screen of the Add New Hardware Wizard to have Windows search for the SCSI Card 2906. Follow the onscreen instructions. If Windows 95/98 does not detect the SCSI card, run the Add New Hardware wizard again: In the Control Panel, double-click the Add New Hardware...
  • Page 17 Select SCSI controllers on the next screen. Select the model of your Adaptec SCSI Card. If SCSI Card 2906 is not on the list, you may be able to install a SCSI card driver from the Windows 95/98 CD-ROM (or from the Adaptec EZ-SCSI Setup Diskette).

  • Page 18: Common Error Messages

    Common Error Messages “Device connected, but not ready” The SCSI card received no answer when it requested data from an installed SCSI device. Make sure the drive is set to spin up when the power is switched on. (See the documentation for the device.) If you still have problems, you may have a bad drive.

  • Page 19: Using The Scsi Card 2906 And Scsi Devices

    Scanners You must install the scanner manufacturer’s proprietary soft- ware drivers. See your scanner’s documentation for details. If the Adaptec driver loads successfully and you have problems with your system, contact your scanner manufacturer for support. You may need to make the following two system changes to help your scanner work well in your system.

  • Page 20: Installing Multiple Scsi Cards

    To use a hard disk drive previously connected to a non-Adaptec SCSI card, you must low-level format the drive after connecting it to the Adaptec SCSI card. (See Using SCSI Disk Utilities on page 19.) Caution: A low-level format destroys all data on the drive.

  • Page 21: Configuring The Scsi Card 2906 With Scsiselect

    Host Adapter SCSI Termination Automatic, Additional Options SCSI Device Configuration: Initiate Sync Negotiation Maximum Sync Transfer Rate Enable Disconnection Advanced Configuration Options: Plug-and-Play SCAM Support SCSI Card 2906 User’s Reference Available Settings Default Setting Enabled, Disabled Enabled Automatic Enabled, Disabled Yes, No (Enabled) 10.0, 8.0, 6.7, 5.0...

  • Page 22: Starting Scsiselect

    SCSI Card 2906 User’s Reference Starting SCSI Select Follow these steps to start SCSISelect: Turn or restart your computer. Allow it to boot to a prompt. At the DOS prompt, insert the SCSISelect diskette and change to the a:\ prompt.

  • Page 23: Using Scsiselect Settings

    SCSI Bus Interface Definitions Host Adapter SCSI ID—Sets the SCSI ID for the SCSI card. The SCSI Card 2906 is set at ID 7, which gives it the highest pri- ority on the SCSI bus. You should not change this setting.

  • Page 24: Scsi Device Configuration

    Enable Disconnection—When set to Yes, allows the SCSI device to disconnect from the SCSI bus. Leave the setting at Yes if two or more SCSI devices are connected to the SCSI card. If only one SCSI device is connected, changing the setting to No results in slightly better performance.

  • Page 25: Using Scsi Disk Utilities

    If the utility finds bad blocks on the media, it prompts you to reassign them; if you select yes, those blocks are longer used. You can press Esc at any time to abort the utility. SCSI Card 2906 User’s Reference...

  • Page 26: Obtaining Scsi Cables

    SCSI Card 2906 User’s Reference Obtaining SCSI Cables High-quality cables are required in high-performance SCSI systems to ensure data integrity. Adaptec provides the highest quality SCSI cables designed specifically for use with Adaptec SCSI cards. For purchasing information, see page 24.

  • Page 27: Internal Cable

    Internal Cable Description 5 position (4 devices and SCSI card) standard 50-pin connectors (1.5 m) Internal Connector Diagrams The following diagram shows a Standard 50-pin internal connector: Maximum Cable Lengths The total length of cabling (internal and external) on the SCSI bus may not exceed the maximum lengths listed in the following table.

  • Page 29: Contacting Adaptec

    Contacting Adaptec If you have questions about installing or using your Adaptec prod- uct, check this User’s Reference first—you will find answers to most of your questions here. If you need further assistance, please contact us. We offer the following support and information services:...

  • Page 30: Technical And Product Support

    For sales information, call 800-959-7274 or 408-945-2550, M–F, 6:00 . to 5:00 ., Pacific Time. To order Adaptec software and SCSI cables, call 800-442-7274 or 408-957-7274, M–F, 6:00 To request additional documentation for Adaptec products, call 800-934-2766 or 510-732-3829, M–F, 6:00 Pacific Time.
  • Page 31 Copyright © 1998 Adaptec, Inc. All rights reserved. No part of this publication may be repro- duced, stored in a retrieval system, or transmitted in any form or by any means, elec- tronic, mechanical, photocopying, recording or otherwise, without the prior written consent of Adaptec, Inc., 691 South Milpitas Blvd., Milpitas, CA 95035.
  • Page 32 This device complies with part 15 of the FCC rules. Operation is subject to the following two con- ditions: (1) this device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation. Adaptec, Inc. Tested To Comply With FCC Standards...
  • Page 33 (30) days from the date of delivery to you. ADAPTEC DOES NOT AND CANNOT WARRANT THE PERFORMANCE OR RESULTS YOU MAY OBTAIN BY USING THE SOFTWARE OR DOCUMENTATION.
  • Page 34 Agreement, in a writing signed by an officer of Adaptec. You assume full responsibility for the use of the Software and agree to use the Software legally and responsibly. This Agreement shall be governed by California law except as to copyright matters which are covered by Federal law.
  • Page 35 Limited 5-Year Warranty Adaptec, Inc. (“Adaptec”) warrants to the purchaser of this product that it will be free from defects in material and workmanship for a period of five (5) years from the date of purchase. If the product should become defective within the warranty period, Adaptec, at its option, will repair or replace the product, or refund the purchaser’s purchase price for the product, provided it is deliv-...
