AFL2-12A-D525 Series Panel PC
IEI Technology Corp.
MODEL:
AFL2-12A-D525
Fanless Flat Bezel Panel PC with 1.8 GHz Intel® Atom™ Processor
TFT LCD, Wi-Fi, Touch Screen, RFID Reader, Dual GbE LAN
Rev. 1.00 - 16 September, 2011
RS-232/422/485, Camera, RoHS
User Manual
User Manual
Page I

Advertisement

Table of Contents
loading

Related Manuals for IEI Technology AFL2-12A-D525

Summary of Contents for IEI Technology AFL2-12A-D525

  • Page 1 AFL2-12A-D525 Series Panel PC IEI Technology Corp. MODEL: AFL2-12A-D525 Fanless Flat Bezel Panel PC with 1.8 GHz Intel® Atom™ Processor TFT LCD, Wi-Fi, Touch Screen, RFID Reader, Dual GbE LAN RS-232/422/485, Camera, RoHS User Manual User Manual Page I Rev. 1.00 - 16 September, 2011...
  • Page 2 AFL2-12A-D525 Series Panel PC Revision Date Version Changes Initial release 16 September, 2011 1.00 Page II...
  • Page 3 AFL2-12A-D525 Series Panel PC Copyright COPYRIGHT NOTICE The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer. In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.

  • Page 4: Table Of Contents

    AFL2-12A-D525 Series Panel PC Table of Contents 1 INTRODUCTION......................14 1.1 AFL2-12A-D525 F PC O ..........15 EZEL ANEL VERVIEW 1.1.1 Model Variations ....................15 1.1.2 Features ......................16 1.1.3 Applications ..................... 16 1.2 E ....................17 XTERNAL VERVIEW 1.2.1 Front Panel ...................... 17 1.2.1.1 LED Indicators..................
  • Page 5 AFL2-12A-D525 Series Panel PC 2.7 S ....................... 32 YSTEM OWER 2.7.1 Power Mode ..................... 32 2.7.1.1 ATX Power Mode (Default)..............32 2.7.1.2 AT Power Mode ..................32 2.7.2 Power Adapter ....................33 3 UNPACKING ....................... 34 3.1 U ......................35 NPACKING 3.1.1 Packing List .....................
  • Page 6 AFL2-12A-D525 Series Panel PC 5.3 T ....................63 URN OFF THE OWER 5.4 O ....................63 PENING THE YSTEM 5.4.1 Removing the Back Cover................63 5.4.2 Removing the Internal Aluminum Cover............64 5.5 R ..................65 EPLACING OMPONENTS 5.5.1 Memory Module Replacement ................. 65 5.5.2 WLAN Card Replacement ................
  • Page 7 AFL2-12A-D525 Series Panel PC 7.1 A ................102 VAILABLE OFTWARE RIVERS 7.2 S ................102 TARTING THE RIVER ROGRAM 7.3 C ................102 HIPSET RIVER NSTALLATION 7.4 G ................107 RAPHICS RIVER NSTALLATION 7.5 A ................111 UDIO RIVER NSTALLATION 7.6 T ..................113...
  • Page 8 AFL2-12A-D525 Series Panel PC C.4.3 Restore Your Last Backup................153 C.4.4 Manual ......................154 C.5 O .................... 154 THER NFORMATION C.5.1 Using AHCI Mode or ALi M5283 / VIA VT6421A Controller ...... 154 C.5.2 System Memory Requirement ................ 157 D WATCHDOG TIMER ....................158 E HAZARDOUS MATERIALS DISCLOSURE ............
  • Page 9 AFL2-12A-D525 Series Panel PC List of Figures Figure 1-1: AFL2-12A-D525 Flat Bezel Panel PC ...............15 Figure 1-2: AFL2-12A-D525 Front View ..................17 Figure 1-3: LED Indicators......................18 Figure 1-4: Function Keys ......................19 Figure 1-5: AFL2-12A-D525 Rear View ..................20 Figure 1-6: AFL2-12A-D525 I/O Interface Panel .................22 Figure 1-7: Top Panel View......................22...
  • Page 10 AFL2-12A-D525 Series Panel PC Figure 4-17: Install into a Rack/Cabinet ..................56 Figure 4-18: LAN Connection ......................57 Figure 4-19: DB-9 Serial Port Connector..................58 Figure 4-20: RJ-45 Serial Port Connector ..................59 Figure 4-21: USB Device Connection ..................60 Figure 5-1: Back Cover Retention Screws .................64 Figure5-2: Internal Cover Retention Screws................65...
  • Page 11 AFL2-12A-D525 Series Panel PC Figure 7-24: Configuration Screen................... 118 Figure 7-25: Calibration Initiation Screen ................118 Figure 7-26: Calibration Screen ....................119 Figure 7-27: AMCap Driver Welcome Screen ................. 120 Figure 7-28: AMCap Driver Choose Install Location.............. 120 Figure 7-29: AMCap Driver Installation Complete..............121 Figure C-1: IEI One Key Recovery Tool Menu ................
  • Page 12 AFL2-12A-D525 Series Panel PC Figure C-30: System Backup Complete Window ..............152 Figure C-31: Restore Backup ....................153 Figure C-32: Restore System Backup Complete Window ............. 153 Figure C-33: Symantec Ghost Window ................... 154 Page XII...
  • Page 13 AFL2-12A-D525 Series Panel PC List of Tables Table 1-1: AFL2-12A-D525 Model Variations ................16 Table 1-2: LED Indicators ......................19 Table 1-3: Function Key Descriptions ..................20 Table 1-4: System Specifications....................25 Table 6-1: BIOS Navigation Keys ....................73 Page XIII...

  • Page 14: Introduction
