IEI Technology PPC-5190GS User Manual

Panel pc
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PPC-5190 Flat Panel PC
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PPC-5190GS and is the answer not in the manual?

Questions and answers

Related Manuals for IEI Technology PPC-5190GS

Summary of Contents for IEI Technology PPC-5190GS

  • Page 1 PPC-5190 Flat Panel PC Page 1...
  • Page 2 This document covers the description and installation instructions for the PPC-5190 flat panel PC. COPYRIGHT NOTICE This document is copyrighted 2006, by IEI Technology Corp. All rights are reserved. IEI Technology Corp. reserves the rights to alter the products described in this manual at any time without prior notice.

  • Page 3: Safety Precautions

    PPC-5190 Flat Panel PC SAFETY PRECAUTIONS Prior to installing, moving, and modifying the panel PC, make sure the power is turned off and the power cord is disconnected. Do not apply voltage levels that exceed the specified voltage range. Doing so will cause fire or an electrical shock.
  • Page 4 PPC-5190 Flat Panel PC Avoid environments exposed to direct sunlight, dust, or chemical vapors. The panel PC is actively cooled. In no circumstances should the panel PC operate with the openings obstructed by foreign objects. However, the ambient temperature of the installation site should be observed and controlled to avoid overheating the panel PC.
  • Page 5 PPC-5190 Flat Panel PC ADDITIONAL INFORMATION AND ASSISTANCE Maintenance and Cleaning Note the following precautions before starting to clean the panel PC. When cleaning any single part or component of the computer, please read and understand the details below fully. Except for the properly installed front LCD panel, never spray or squirt liquids directly onto any computer component.
  • Page 6 PPC-5190 Flat Panel PC Cloth - A piece of cloth is the best tool to use when rubbing up a component. Although paper towels or tissues can be used on most hardware as well, it is still recommended that a piece of cloth is used to rub it. Water or rubbing alcohol –...
  • Page 7 PPC-5190 Flat Panel PC CONVENTIONS USED IN THIS MANUAL WARNING! Warnings appear where overlooked details may cause damage to the equipment or result in personal injury. Warnings should be taken seriously. Warnings are easy to recognize. The word “warning” is written as “WARNING,” both capitalized and bold and is followed by text in italics.

  • Page 8: Table Of Contents

    PPC-5190 Flat Panel PC Table of Contents INTRODUCTION....................19 1.1 PPC-5190 F PC O ..............20 ANEL VERVIEW 1.1.1 PPC-5190 Model Variation................20 1.1.2 PPC-5190 Flat Panel PC Applications ............20 1.1.3 PPC-5190 Flat Panel PC Features..............21 1.2 PPC-5190 E ................
  • Page 9 PPC-5190 Flat Panel PC 2.3.3 ICH5 Southbridge Chipset................37 2.4 G ....................38 RAPHICS UPPORT 2.5 P ......... 40 ERIPHERAL EVICE NTERFACES ONNECTORS LOTS 2.5.1 OEM Options ....................40 2.5.2 Internal Slots....................40 2.5.3 Internal Peripheral Device Connectors............40 2.5.4 External Peripheral Device Connectors............42 INSTALLATION AND CONFIGURATION ............
  • Page 10 PPC-5190 Flat Panel PC 3.8.4 Keyboard and Mouse Connection..............67 3.8.5 Parallel Port Connection................. 67 3.8.6 Serial Port Connection ..................67 3.8.7 Audio Port Connection..................67 SYSTEM MAINTENANCE .................. 69 4.1 S ..............70 YSTEM AINTENANCE NTRODUCTION 4.2 M ................70 OTHERBOARD EPLACEMENT 4.3 B...
  • Page 11 PPC-5190 Flat Panel PC 5.3.6.1 General ACPI Configuration..............107 5.3.6.2 Advanced ACPI Configuration ............... 108 5.3.7 MPS Configuration ..................111 5.3.8 Remote Access Configuration .................112 5.3.9 USB Configuration..................113 5.4 PCI/P P .........................115 5.5 B ........................120 5.5.1 Boot Settings Configuration................121 5.5.2 Boot Device Priority ..................
  • Page 12 PPC-5190 Flat Panel PC B.7 USB P ..................160 ONNECTOR B.8 I DA I ................ 161 NFRARED NTERFACE B.9 VGA C ....................162 ONNECTOR B.10 LAN RJ45 C ..................163 ONNECTOR B.11 F ....................163 ONNECTOR B.12 I (LCD B ............
  • Page 13 PPC-5190 Flat Panel PC List of Figures Figure 1-1: PPC-5190 Front View .................22 Figure 1-2: PPC-5190 Rear View..................23 Figure 1-3: PPC-5190 Top View ...................23 Figure 1-4: Bottom View....................24 Figure 1-5: Left View .....................25 Figure 1-6: Right View....................25 Figure 1-7: Internal Components ..................26 Figure 1-8: Dimensions (units in mm) ................33 Figure 3-1: Back Cover Retention Screws ..............48 Figure 3-2: HDD Retention Screws................53...
  • Page 14 PPC-5190 Flat Panel PC Figure 4-3: Internal Elevated Platform Retention Screws ..........73 Figure 4-4: Elevated Platform Retention Screws (Top Panel) ........73 Figure 4-5: Elevated Platform Retention Screws (Right Panel) ........74 Figure 4-6: Elevated Platform Retention Screws (Bottom Panel).........74 Figure 4-7: Elevated Platform Retention Screws (PCI Riser Card) ......74 Figure 4-8: DIMM Socket Clip Locations...............75 Figure 4-9: PSU Motherboard Connectors ..............76 Figure 4-10: PSU Bottom Panel Retention Screws ............76...
  • Page 15 PPC-5190 Flat Panel PC List of Tables Table 1-1: PPC-5190 Model Variation ................20 Table 1-2: PPC-5190 Specifications ................28 Table 1-3: Motherboard Specifications .................29 Table 1-4: 19” TFT LCD Monitor Specifications............30 Table 1-5: ACE-4518AP Power Supply Specifications ..........32 Table 1-6: ACE-4520C Power Supply Specifications ...........33 Table 3-1: Onboard Jumpers ..................47 Table 3-2: CF Card Setup Jumper Settings..............49 Table 3-3: Clear CMOS Jumper Settings..............49...
  • Page 16 PPC-5190 Flat Panel PC List of BIOS Menus BIOS Menu 1: Main .......................84 BIOS Menu 2: Advanced....................86 BIOS Menu 3: CPU Configuration.................87 BIOS Menu 4: IDE Configuration ..................89 BIOS Menu 5: IDE Master and IDE Slave Configuration ..........93 BIOS Menu 6: Floppy Configuration ................97 BIOS Menu 7: Super IO Configuration................98 BIOS Menu 8: Hardware Health Configuration ............
  • Page 17 PPC-5190 Flat Panel PC Glossary Hard Disk Drive AC ’97 Audio Codec 97 ACPI Advanced Configuration and Integrated Data Electronics Power Interface Input/Output Advanced Power Management ICH4 I/O Controller Hub 4 ARMD ATAPI Removable Media Device L1 Cache Level 1 Cache ASKIR Shift Keyed Infrared L2 Cache Level 2 Cache...
  • Page 18 PPC-5190 Flat Panel PC THIS PAGE IS INTENTIONALLY LEFT BLANK Page 18...

  • Page 19: Introduction

    PPC-5190 Flat Panel PC Chapter Introduction Page 19...

  • Page 20: Ppc-5190 Flat Panel Pc Overview

    1.1.1 PPC-5190 Model Variation Four IEI PPC-5190 models are available. The models are listed in Table 1-1. Touch Model Socket Power Screen Intel© Pentium© 4 PPC-5190GS/8520/ACE-4518AP AC Input Intel© Celeron© D Intel© Pentium© 4 PPC-5190GS/8520/ACE-4518AP/T-R AC Input Intel© Celeron© D Intel© Pentium© 4...

  • Page 21: Ppc-5190 Flat Panel Pc Features

    PPC-5190 Flat Panel PC 1.1.3 PPC-5190 Flat Panel PC Features Some of the features of the PPC-5190 flat panel PC include: Mainstream panel PC design with dual display function. Aluminum die-casting front panel meet IP 65 water proof standard High performance Intel Pentium 4 / Celeron CPU support Dual DDR memory DIMM support up to 2GB SDRAM Serial ATA-150 connections High brightness 19”...

  • Page 22: Rear Panel

    PPC-5190 Flat Panel PC Figure 1-1: PPC-5190 Front View 1.2.3 Rear Panel The rear panel has a fan vent, four VESA standard mounting holes and several retention screw holes. The VESA mounting holes are circled in Figure 1-2. Page 22...

  • Page 23: Top Panel

    PPC-5190 Flat Panel PC Figure 1-2: PPC-5190 Rear View 1.2.4 Top Panel The top panel has two fan vents, eight mounting clamp slots and three retention screws for securing the drive bay bracket. The retention screws are circled in Figure 1-3 below. Figure 1-3: PPC-5190 Top View 1.2.5 PPC-5190 Bottom Panel The bottom panel shown in Figure 1-4 has the following interfaces:...

  • Page 24: Left Panel

    PPC-5190 Flat Panel PC 1 x Power input connector 1 x Power switch 6 x USB connectors 1 x Reset button 2 x RJ-45 GbE connectors 2 x PS/2 keyboard/mouse connector 5 x Serial port (COM) connectors 1 x PCI add-on card slot 1 x Parallel port connector 3 x Audio jacks 1 x VGA connector...

  • Page 25: Right Panel

    PPC-5190 Flat Panel PC Figure 1-5: Left View 1.2.7 Right Panel The right side panel provides access to a slim type CD drive bay and a FDD drive bay shown in Figure 1-6. Figure 1-6: Right View 1.3 PPC-5190 Internal Overview The PPC-5190 internal components are configured in three levels.

  • Page 26: Ppc-5190 Specifications

    PPC-5190 Flat Panel PC Figure 1-7: Internal Components 1.4 PPC-5190 Specifications 1.4.1 Preinstalled Hardware Components The PPC-5190 flat panel PC has the following preinstalled components: 1 x Motherboard 1 x 19” TFT LCD screen 1 x Power supply 2 x Cooling fans The technical specifications for these components and the system are shown in the sections below.
  • Page 27 PPC-5190 Flat Panel PC Brightness 300 cd/m2 Contrast Ratio 700:1 LCD MTBF 50,000 hrs Backlight MTBF 50,000 hrs Viewing Angle (H/V) 140/130 Optional 5-wire resistive type touch screen Touch Screen with RS-232 interface Display Supports Dual Display Add-On Card (Optional) Support PCI and CFII One 2.5”...

  • Page 28: Ppc-5190 Motherboard Specifications

    PPC-5190 Flat Panel PC Input voltage: 24VDC (18-36VDC) Output rating: 200W Output voltage: +3.3V@12A +5V@12A +12V@15.4A -12V@0.5A +5VSB@2A Mounting Feature Panel, Arm, Wall, or Rack/Cabinet Color Silver (PANTONE PMS-8001) Operating Temperature 0~50˚C Relative Humidity 5 ~ 85%, non-condensing 5 - 17Hz, 0.1” double amplitude displacement Vibration 17 - 640Hz, 1.5G acceleration, peak to peak Shock...

  • Page 29: Flat Panel Screen

    PPC-5190 Flat Panel PC Southbridge ICH5 Max. FSB 533 MHz Memory 2 x DDR 266/333 DIMM socket up to 2GB BIOS AMI BIOS Label CRT integrated in Intel 852GME Display LVDS Dual 18-bit TTL LCD integrated in Intel 852GM 1 x PCI slot Expansion Interface 1 x CFII Audio...

  • Page 30: Power Supply

    PPC-5190 Flat Panel PC Size 19” Resolution SXGA (1280 x 1024) Active Area (mm) 376.32 x 301.06 Pixel Pitch (mm) 0.294 Mode Number of Colors 16.2M Color Saturation (%) View Angel (H/V) 160 / 160 Brightness (cd/m2) Contrast Ratio 700 : 1 Response Time (ms) (at 25°C) Power Consumption (W) Interface...

  • Page 31: Ace-4518Ap Power Supply

    PPC-5190 Flat Panel PC WARNING: Under no circumstances is the PSU case to be opened. The PSU module is not user serviceable and there are dangerous high-voltages inside the case. If there are any problems with the PSU module, please contact the dealer or reseller immediately.

  • Page 32: Ace-4520C Power Supply

    PPC-5190 Flat Panel PC Temperature 0~50°C (Operating) -20~80°C (Storage) Humidity 5 –95% RH, Non-condensing (Operating & Storage) Dimension 150mm (W) x 81.5mm (H) x 40.5mm (D) Table 1-5: ACE-4518AP Power Supply Specifications 1.4.5.2 ACE-4520C Power Supply Specifications for the ACE-4520C PSU module are shown in (Table 1-6). Voltage 18VDC ~ 36VDC Full Range INPUT...

  • Page 33: Dimensions

    PPC-5190 Flat Panel PC 1.5 Dimensions The dimensions of the PPC-5190 flat panel PC are shown in Figure 1-8 below. Figure 1-8: Dimensions (units in mm) Page 33...
  • Page 34 PPC-5190 Flat Panel PC THIS PAGE IS INTENTIONALLY LEFT BLANK Page 34...

  • Page 35: Pos-8520 Motherboard

    PPC-5190 Flat Panel PC Chapter POS-8520 Motherboard Page 35...

  • Page 36: Introduction

    PPC-5190 Flat Panel PC 2.1 Introduction The PPC-5190 flat screen PC contains a POS-8520 motherboard. The motherboard is the heart of any computer and is responsible for transmitting, receiving and processing data as well as driving the different on-board devices. This chapter gives a brief introduction to the POS-8520 motherboard.

  • Page 37: Ich5 Southbridge Chipset

    PPC-5190 Flat Panel PC Display Analog display support Dual independent pipe support DVO (DVOB and DVOC) support Dedicated Local Flat Panel (LFP) LVDS interface Intel® Embedded Graphics Drivers Graphics interface support Multi-monitor support Dynamic display-mode support Embedded video BIOS 2.3.3 ICH5 Southbridge Chipset The ICH5 southbridge chipset comes with the following features: PCI Bus Interface New: Supports PCI Revision 2.3 Specification at 33 MHz...

  • Page 38: Graphics Support

    PPC-5190 Flat Panel PC Supports up to 8 PCI interrupt pins Supports PCI 2.3 Message Signaled Interrupts Two cascaded 82C59 with 15 interrupts Integrated I/O APIC capability with 24 interrupts Supports Front Side Bus interrupt delivery High-Precision Event Timers 1.5 V operation with 3.3 V I/O 5V tolerant buffers on IDE, PCI, USB Overcurrent and Legacy signals Integrated 1.5 V Voltage Regulator (INTVR) for the Suspend wells Enhanced DMA Controller...
  • Page 39 PPC-5190 Flat Panel PC Enhanced Intelligent Memory Management: Improves memory bandwidth efficiency and platform performance by improving the memory management arbitration between CPU, system memory and graphics memory. Intel® Extreme Graphics 2 specifications are listed below: Enhanced 2D: 256-bit internal path 8/16/32bpp DirectDraw*, GDI, GDI+ Anti-aliased text support...

  • Page 40: Peripheral Device Interfaces, Connectors, And Slots

    PPC-5190 Flat Panel PC Flat panel monitors and TV-out support via AGP Digital Display (ADD) cards 350 MHz DAC for 1800x1440 @ 85Hz max CRT resolution or 2048x1536@60Hz max FP resolution Synchronous display for dual monitor capabilities 350MHz RAMDAC for up to QXGA analog monitor support Dual DVO ports for up to QXGA digital display support Multiple display types (LVDS, DVI, TV-out, CRT) 2.5 Peripheral Device Interfaces, Connectors, and Slots...
  • Page 41 PPC-5190 Flat Panel PC 3 x Fan connectors 1 x FDD connector 2 x IDE device connectors 1 x IrDA connector 1 x Keyboard connector 1 x PS/2 mouse connector 1 x LCD backlight connector 1 x LVDS interface connector 1 x Multi panel connector 1 x Parallel port connector 1 x Reset connector...

  • Page 42: External Peripheral Device Connectors

    PPC-5190 Flat Panel PC 2.5.4 External Peripheral Device Connectors The peripheral device connectors listed below are located on the rear panel of the POS-8520 motherboard. Pinouts for these connectors can be found in Appendix A. 3 x Audio jack connectors 1 x Keyboard connector 1 x Mouse connector 2 x RJ-45 Ethernet connectors...

  • Page 43: Installation And Configuration

    PPC-5190 Flat Panel PC Chapter Installation and Configuration Page 43...

  • Page 44: Installation Precautions

    PPC-5190 Flat Panel PC 3.1 Installation Precautions When installing the PPC-5190, please follow the precautions listed below: Turn power off: When installing the PPC-5190 make sure the power is off. Failing to turn off the power may cause severe injury to the body and/or damage to the system.

  • Page 45: Installation And Configuration Steps

    PPC-5190 Flat Panel PC Removal and reinstallation of some of the components are described in Chapter 4. 3.3 Installation and Configuration Steps The following installation steps must be followed. Step 1: Unpack the PPC-5190. Step 2: Set the jumper settings. Step 3: Install HDD, FDD and CD drive.

  • Page 46: Packing List

    PPC-5190 Flat Panel PC Step 5: Remove both polystyrene ends, one from each side. Step 6: Make sure all the components listed in the packing list are present.Step 0: 3.4.1 Packing List The PPC-5190 flat panel PC is shipped with the following components: 1 x Carton 1 x Power cord 1 x Screw kit...

  • Page 47: Table 3-1: Onboard Jumpers

    PPC-5190 Flat Panel PC NOTE: A jumper is a metal bridge that is used to close an electrical circuit. It consists of two metal pins and a small metal clip (often protected by a plastic cover) that slides over the pins to connect them. To CLOSE/SHORT a jumper means connecting the pins of the jumper with the plastic clip and to OPEN a jumper means removing the plastic clip from a jumper.

  • Page 48: Remove The

    PPC-5190 Flat Panel PC 3.5.1 Remove the Back Cover The back cover is secured to the chassis with fourteen retention screws, eleven on the rear panel and two on the bottom panel (Figure 3-1). Remove the fourteen retention screws and lift the cover off the PPC-5190. Figure 3-1: Back Cover Retention Screws Page 48...

  • Page 49: Cf Card Setup (Jp12)

    PPC-5190 Flat Panel PC 3.5.2 CF Card Setup (JP12) The CF Card Setup jumper configures a CF card as either the slave or the master. JP12 DESCRIPTION Open Slave (Default) Close Master Table 3-2: CF Card Setup Jumper Settings 3.5.3 Clear CMOS Setup (JP1) If the motherboard fails to boot due to improper BIOS settings, use this jumper to clear the CMOS data and reset the system BIOS information.

  • Page 50: Com2 Port Rs232/422/485 Selection (Jp10, Jp20)

    PPC-5190 Flat Panel PC 3.5.4 COM2 Port RS232/422/485 Selection (JP10, JP20) The COM Port jumper configures the COM2 serial port. JP10 JP20 DESCRIPTION 1-2,4-5,7-8,10-11 closed 1-3 closed RS232 (default) 2-3,5-6,8-9,11-12 closed 3-5, 2-4 closed RS422 2-3,5-6,8-9,11-12 closed 3-5, 4-6 closed RS485 Table 3-4: COM2 Port Jumper Settings 3.5.5 COM port RI and Voltage Selection...

  • Page 51: Table 3-7: Com2 Ri And Voltage Selection Jumper

    PPC-5190 Flat Panel PC DESCRIPTION 2-3 closed COM2 RI PIN Use RI 1-2 closed COM2 RI PIN Use Voltage Table 3-7: COM2 RI and Voltage Selection Jumper DESCRIPTION 2-3 closed COM2 RI PIN Use Voltage +12V 1-2 closed COM2 RI PIN Use Voltage +5V Table 3-8: COM2 RI Voltage Selection Jumper Use JP13 and JP15 to set pin 9 of COM3 as signal RI or voltage source.

  • Page 52: Keyboard And Mouse Power Source Setting (Jp18)

    PPC-5190 Flat Panel PC JP14 DESCRIPTION 2-3 closed COM4 RI PIN Use Voltage +12V 1-2 closed COM4 RI PIN Use Voltage +5V Table 3-12: COM4 RI Voltage Selection Jumper 3.5.6 Keyboard and Mouse Power Source Setting (JP18) JP18 DESCRIPTION 1-2 closed VCC (default) 2-3 closed 5VSB...

  • Page 53: Hdd, Fdd And Cd Drive Installation

    PPC-5190 Flat Panel PC 3.6 HDD, FDD and CD Drive Installation 3.6.1 HDD Installation To install a HDD, please follow the steps below: Step 1: Remove the back cover (Section 3.5.1). Step 2: The HDD bracket is attached to the elevated platform by four retention screws. Remove the four retention screws from the elevated platform (Figure 3-2).

  • Page 54: Fdd Installation

    PPC-5190 Flat Panel PC 3.6.2 FDD Installation To install the FDD, please follow the steps below: Step 1: Remove the back cover (Section 3.5.1). Step 2: The FDD bracket is attached to the elevated platform by two retention screws (Figure 3-3). Remove the two retention screws from the elevated platform. Step 3: Remove the FDD bracket by sliding toward the HDD.

  • Page 55: Cd Drive Installation

    PPC-5190 Flat Panel PC Figure 3-4: FDD Adapter and FDD Bracket Installation Step 5: Attach the FDD bracket to the FDD. To do this, align the four retention screw holes in the FDD bracket with the retention screw holes on the sides of the FDD. Insert four retention screws into the bracket of the FDD.

  • Page 56: Figure 3-5: Cd Drive Adapter Installation

    PPC-5190 Flat Panel PC Figure 3-5: CD Drive Adapter Installation Step 4: Remove the back cover of the PPC-5190 (see Section 3.5.1). Step 5: The CD drive blank plate assembly is attached to the rear panel by two retention screws (Figure 3-6). Figure 3-6: CD Drive Retention Screws Remove the two retention screws from the bottom panel and slide the CD drive blank plate assembly toward the PCI riser card until it can be lifted out of the...

  • Page 57: Figure 3-7: Remove Cd Drive

    PPC-5190 Flat Panel PC Figure 3-7: Remove CD Drive Step 6: The CD drive blank plate assembly consists of a blank plate and two brackets that attach the assembly to the chassis. The two brackets each have two screws that attach them to the blank plate. Remove the four screws that attach the brackets to the blank plate.

  • Page 58: Figure 3-9: Cd Drive Blank Plate Assembly

    PPC-5190 Flat Panel PC Figure 3-9: CD Drive Blank Plate Assembly WARNING! The two screws (black M2*3) shown in the left image of Figure 3-9 are different from the two screws (silver M2*2) shown in the right. Please secure the correct screws into the CD drive according to the images shown in the Figure 3-9.

  • Page 59: Mounting The System

    PPC-5190 Flat Panel PC Figure 3-10: CD Drive Installed 3.7 Mounting the System WARNING! When mounting the PPC-5190 flat panel PC onto an arm, wall or into a panel, it is advisable to have more than one person help with the installation to prevent accidental damage to the panel and avoid personal injury.

  • Page 60: Figure 3-11: Wall-Mounting Bracket

    PPC-5190 Flat Panel PC Step 1: Select the location on the wall for the wall-mounting bracket. Step 2: Carefully mark the locations of the four bracket screw holes on the wall. Step 3: Drill four pilot holes at the marked locations on the wall for the bracket retention screws.

  • Page 61: Figure 3-12: Mount The Chassis

    PPC-5190 Flat Panel PC 3-12). Ensure that all four of the mounting screws fit snuggly into their respective slotted holes. NOTE: In the diagram below the bracket is already installed on the wall. Figure 3-12: Mount the Chassis Step 9: Secure the panel PC with the wall-mounting kit.

  • Page 62: Panel/ Mounting

    PPC-5190 Flat Panel PC Figure 3-13: Secure the Chassis 3.7.2 Panel/ Mounting To mount the PPC-5190 flat panel PC into a panel, please follow the steps below. NOTE: The maximum panel thickness should be no more than 6mm. Step 1: Select the position on the panel to mount the PPC-5190.

  • Page 63: Figure 3-14: Cut The Panel

    PPC-5190 Flat Panel PC Figure 3-14: Cut the Panel Step 3: Slide the PPC-5190 through the hole until the metal frame is flush against the panel. Step 4: Insert the panel mounting clamps into the pre-formed holes along the edges of the PPC-5190, behind the metal frame (Figure 3-15).

  • Page 64: Rack And Cabinet Installation

    PPC-5190 Flat Panel PC Step 5: Tighten the screws that pass through the panel mounting clamps until the plastic caps at the front of all the screws are firmly secured to the panel (Figure 3-16). Step 0: Figure 3-16: Tighten the Panel Mounting Clamp Screws 3.7.3 Rack and Cabinet Installation To mount the PPC-5190 monitor into a rack/cabinet, please follow the steps below.

  • Page 65: Arm Mounting

    PPC-5190 Flat Panel PC Figure 3-17: Rack Mounting 3.7.4 Arm Mounting The PPC-5190 is VESA (Video Electronics Standards Association) compliant and can be mounted on an arm with a 100mm interface pad. To mount the PPC-5190 on an arm, please follow the steps below. Step 1: The arm is a separately purchased item.

  • Page 66: External Peripheral Interface Connectors

    PPC-5190 Flat Panel PC screw holes are shown in Figure 3-18. Figure 3-18: Arm Mount Retention Screw Holes Step 4: Secure the PPC-5190 to the interface pad by inserting four retention screws through the mounting arm interface pad and into the PPC-5190 flat panel PC. Step 0: 3.8 External Peripheral Interface Connectors 3.8.1 LCD Panel Connection...

  • Page 67: Usb Connection

    PPC-5190 Flat Panel PC 3.8.3 USB Connection The external peripheral interface USB connectors provide easy and quick access to external USB devices. The external peripheral interface USB connectors are a standard connector and can easily be connected to other USB devices. 3.8.4 Keyboard and Mouse Connection Two PS/2 connectors on the external peripheral interface panel facilitate the connection of a mouse and a keyboard.
  • Page 68 PPC-5190 Flat Panel PC THIS PAGE IS INTENTIONALLY LEFT BLANK Page 68...

  • Page 69: System Maintenance

    PPC-5190 Flat Panel PC Chapter System Maintenance Page 69...

  • Page 70: System Maintenance Introduction

    PPC-5190 Flat Panel PC 4.1 System Maintenance Introduction The following system components may require maintenance. Motherboard DIMM module PSU module Cooling fans If these components fail, they must be replaced. Please contact the system reseller or vendor to purchase replacement parts. Replacement instructions for the above listed components are described below.

  • Page 71: Back Cover Removal

    PPC-5190 Flat Panel PC WARNING! PLEASE TAKE ANTISTATIC PRECAUTIONS WHEN WORKING WITH THE INTERNAL COMPONENTS. The interior of the PPC-5190 contains very sensitive electronic components. These components are easily damaged by electrostatic discharge (ESD). Before working with the internal components, make sure all anti-static precautions described earlier have been observed.

  • Page 72: Detaching The Elevated Platform

    PPC-5190 Flat Panel PC Figure 4-1: Rear Cover Retention Screws (Real Panel) 4.3.2 Detaching the Elevated Platform Please read the warnings at the beginning of Section 4.3 before attempting to access any PPC-5190 internal components. The elevated platform supports the FDD, CD drive and HDD. Back cover removal is discussed in Section 4.3.1.

  • Page 73: Figure 4-2: Cd Drive Retention Screws

    PPC-5190 Flat Panel PC Step 2: Remove the CD drive retention screws from the bottom panel (Figure 4-2). Figure 4-2: CD Drive Retention Screws Step 3: The elevated platform is secured to the chassis with twelve retention screws, two on the internal platform (Figure 4-3), three on the top panel (Figure 4-4), three on the right panel (Figure 4-5), two on the bottom panel (Figure 4-6) and two on the PCI riser card (Figure 4-7).

  • Page 74: Dimm Replacement

    PPC-5190 Flat Panel PC Figure 4-5: Elevated Platform Retention Screws (Right Panel) Figure 4-6: Elevated Platform Retention Screws (Bottom Panel) Figure 4-7: Elevated Platform Retention Screws (PCI Riser Card) 4.4 DIMM Replacement Please read the warnings at the beginning of Section 4.3 before attempting to access any PPC-5190 internal components.

  • Page 75: Psu Module Replacement

    PPC-5190 Flat Panel PC To install/replace the DIMM modules please follow the steps below. Step 1: Remove the back cover (Section 4.3.1). Step 2: Locate the DIMM socket on the motherboard near the right of the chassis. Push down on the white levers of the socket until the DIMM module is dislodged from the socket (Figure 4-8).

  • Page 76: Figure 4-9: Psu Motherboard Connectors

    PPC-5190 Flat Panel PC Step 2: Detach and remove the elevated platform (see Section 4.3.2). Step 3: Disconnect all PSU connections including those to the motherboard (Figure 4-9) and any disk drives. Figure 4-9: PSU Motherboard Connectors The PSU module is secured to the PPC-5190 flat panel PC with six retention screws, two connect to the bottom panel (Figure 4-10), two connect to the internal PSU bracket (Figure 4-12) which is connected to the chassis by two screws (Figure 4-11).

  • Page 77: Install The New Psu

    PPC-5190 Flat Panel PC Figure 4-11: PSU Bracket to Chassis Retention Screws Step 6: Remove the retention screws that connect the PSU to the PSU bracket (Figure 4-12).Step 0: Figure 4-12: PSU Bracket Retention Screws 4.5.2 Install the New PSU To install a new PSU module, please follow the steps below.

  • Page 78: System Cooling Fan Replacement

    PPC-5190 Flat Panel PC Step 4: Bundle the cables of the new PSU module and secure them with a plastic tie similar to the old PSU module. Step 5: Reconnect all previously disconnected power connectors to the motherboard and disk drives. Step 6: Reattach the elevated platform.

  • Page 79: Install The New System Cooling Fans

    PPC-5190 Flat Panel PC Step 4: Remove the system cooling fans retention screws from the left panel (Figure 4-14). Figure 4-14: System Cooling Fans Left Panel Retention Screws Step 5: Remove the system cooling fans from the chassis. Step 0: 4.6.2 Install the New System Cooling Fans To install the new system cooling fans, please follow the steps below.
  • Page 80 PPC-5190 Flat Panel PC THIS PAGE IS INTENTIONALLY LEFT BLANK Page 80...

  • Page 81: Ami Bios

    PPC-5190 Flat Panel PC Chapter AMI BIOS Page 81...

  • Page 82: Introduction

    PPC-5190 Flat Panel PC 5.1 Introduction A licensed copy of AMI BIOS is preprogrammed into the ROM BIOS. The BIOS setup program allows users to modify the basic system configuration. This chapter describes how to access the BIOS setup program and the configuration options that may be changed.

  • Page 83: Getting Help

    PPC-5190 Flat Panel PC Function F1 key General help, only for Status Page Setup Menu and Option Page Setup Menu F2 /F3 key Change color from total 16 colors. F2 to select color forward. F10 key Save all the CMOS changes, only for Main Menu Table 5-1: BIOS Navigation Keys 5.1.3 Getting Help When F1 is pressed a small help window describing the appropriate keys to use and the...

  • Page 84: Main

    PPC-5190 Flat Panel PC 5.2 Main The Main BIOS menu (BIOS Menu 1) appears when the BIOS Setup program is entered. The Main menu gives an overview of the basic system information. BIOS Menu 1: Main System Overview The System Overview lists a brief summary of different system components. The fields in System Overview cannot be changed.

  • Page 85: Advanced

    PPC-5190 Flat Panel PC Count: The number of CPUs on the motherboard System Memory: Displays the auto-detected system memory. Size: Lists memory size The System Overview field also has two user configurable fields: System Time [xx:xx:xx] Use the System Time option to set the system time. Manually enter the hours, minutes and seconds.

  • Page 86: Bios Menu 2: Advanced

    PPC-5190 Flat Panel PC CPU Configuration (Section 5.3.1) IDE Configuration (Section 5.3.2) Floppy Configuration (Section 5.3.3) SuperIO Configuration (Section 5.3.4) Hardware Health Configuration (Section 5.3.5) ACPI Configuration (Section 5.3.6) MPS Configuration (Section 5.3.7) Remote Access Configuration (Section 5.3.8) USB Configuration (Section 5.3.9) BIOS Menu 2: Advanced Page 86...

  • Page 87: Cpu Configuration

    PPC-5190 Flat Panel PC 5.3.1 CPU Configuration Use the CPU Configuration menu (BIOS Menu 3) to view detailed CPU specifications and configure the CPU. BIOS Menu 3: CPU Configuration The CPU Configuration menu (BIOS Menu 3) lists the following CPU details: Manufacturer: Lists the name of the CPU manufacturer Brand String: Lists the brand name of the CPU being used Frequency: Lists the CPU processing speed...

  • Page 88: Max Cupid Value Limit [Disabled]

    PPC-5190 Flat Panel PC The following CPU Configuration menu items can be configured. Max CPUID Value Limit Hyper Threading Technology Max CUPID Value Limit [Disabled] NOTE: If the OS is NT, this value must be set to enabled. Disabled Disables legacy OSes that cannot support CPUs with EFAULT extended CUPID functions from booting up Enabled...

  • Page 89: Ide Configuration

    PPC-5190 Flat Panel PC 5.3.2 IDE Configuration Use the IDE Configuration menu (BIOS Menu 4) to change and/or set the configuration of the IDE devices installed in the system. BIOS Menu 4: IDE Configuration IDE Configuration [P-ATA Only] Use IDE Configuration option to setup the configuration of the hard drive interfaces. Disabled The hard drive interfaces are disabled.

  • Page 90: S-Ata Running Enhanced Mode [Yes]

    PPC-5190 Flat Panel PC P-ATA&S-ATA The hard drive interfaces are configured as P-ATA and S-ATA. S-ATA Running Enhanced Mode [Yes] Use S-ATA Running Enhanced Mode option to select whether the S-ATA interface is running in enhanced mode or legacy mode. The S-ATA interface is running in enhanced mode.

  • Page 91: Configure S-Ata As Raid [No]

    PPC-5190 Flat Panel PC Configure S-ATA as RAID [No] The Configure S-ATA as RAID option can only be selected if the IDE Configuration option is set to “P-ATA Only”. Use Configure S-ATA as RAID option to configure the S-ATA interface as RAID. The S-ATA interface cannot be configured as RAID drive.

  • Page 92: Ata (Pi) 80Pin Cable Detection [Host & Device]

    PPC-5190 Flat Panel PC ATA (PI) 80Pin Cable Detection [Host & Device] When an Ultra ATA/66, an Ultra ATA/100 or an Ultra ATA/133 IDE hard disk drive is used, an 80-conductor ATA cable must be used. The 80-conductor ATA cable is plug compatible with the standard 40-conductor ATA cable.

  • Page 93: Ide Master, Ide Slave

    PPC-5190 Flat Panel PC listed four BIOS configuration options are selected, the IDE configuration options shown in Section 5.3.2.1 appear. 5.3.2.1 IDE Master, IDE Slave Use the IDE Master and IDE Slave configuration menu to view both primary and secondary IDE device details and configure the IDE devices connected to the system. BIOS Menu 5: IDE Master and IDE Slave Configuration Auto-Detected Drive Parameters The “grayed-out”...

  • Page 94: Type [Auto]

    PPC-5190 Flat Panel PC method of addressing data on a disk drive is supported or not. Block (Multi-Sector Transfer): Block mode boosts IDE drive performance by increasing the amount of data transferred. Only 512 bytes of data can be transferred per interrupt if block mode is not used. Block mode allows transfers of up to 64 KB per interrupt.

  • Page 95: Block (Multi Sector Transfer) [Auto]

    PPC-5190 Flat Panel PC Use the LBA/Large Mode option to disable or enable BIOS to auto detects LBA (Logical Block Addressing). LBA is a method of addressing data on a disk drive. In LBA mode, the maximum drive capacity is 137 GB. Disabled BIOS is prevented from using the LBA mode control on the specified channel.

  • Page 96: Auto]

    PPC-5190 Flat Panel PC PIO mode 1 selected with a maximum transfer rate of 5.2MBps PIO mode 2 selected with a maximum transfer rate of 8.3MBps PIO mode 3 selected with a maximum transfer rate of 11.1MBps PIO mode 4 selected with a maximum transfer rate of 16.6MBps (This setting generally works with all hard disk drives manufactured after 1999.

  • Page 97: Floppy Configuration

    PPC-5190 Flat Panel PC 5.3.3 Floppy Configuration Use the Floppy Configuration menu (BIOS Menu 6) to set or change the configurations for floppy disk drives. BIOS Menu 6: Floppy Configuration Floppy A [1.44 MB 3½”] The Floppy A configuration option determines the types of the floppy drive installed in the system.

  • Page 98: Super Io Configuration

    PPC-5190 Flat Panel PC 5.3.4 Super IO Configuration Use the Super IO Configuration menu (BIOS Menu 7) to set or change the configurations for the FDD controllers, parallel ports and serial ports. BIOS Menu 7: Super IO Configuration On Board Floppy Controller [Enabled] Disabled Allows BIOS to disable the floppy controller Enabled...

  • Page 99: Serial Port2 Address [2F8/Irq3]

    PPC-5190 Flat Panel PC 3F8/IRQ4 Serial Port 1 I/O port address is 3F8 and the interrupt EFAULT address is IRQ4 Serial Port 1 I/O port address is 3E8 and the interrupt 3E8/IRQ4 address is IRQ4 2E8/IRQ3 Serial Port 1 I/O port address is 2E8 and the interrupt address is IRQ3 Serial Port2 Address [2F8/IRQ3] Use the Serial Port2 Address option to select the Serial Port 2 base address.

  • Page 100: Parallel Port Mode [Normal]

    PPC-5190 Flat Panel PC Disabled No base address is assigned to the Parallel Port Parallel Port I/O port address is 378 EFAULT Parallel Port I/O port address is 278 Parallel Port I/O port address is 3BC Parallel Port Mode [Normal] Use the Parallel Port Mode option to select the mode the parallel port operates in.

  • Page 101: Parallel Port Irq [Irq7]

    PPC-5190 Flat Panel PC Parallel Port IRQ [IRQ7] Use the Parallel Port IRQ selection to set the parallel port interrupt address. IRQ5 is assigned as the parallel port interrupt address IRQ5 IRQ7 is assigned as the parallel port interrupt address IRQ7 EFAULT Digital I/O Address [280h]...

  • Page 102: Serial Port3 Irq [11]

    PPC-5190 Flat Panel PC Serial Port3 IRQ [11] Use the Serial Port3 IRQ option to select the interrupt address for serial port 3. Serial port 3 IRQ address is 4 Serial port 3 IRQ address is 9 Serial port 3 IRQ address is 10 Serial port 3 IRQ address is 11 EFAULT Serial Port4 Address [2E8]...

  • Page 103: Serial Port5 Address [2F0]

    PPC-5190 Flat Panel PC Serial Port5 Address [2F0] Use the Serial Port5 IRQ option to select the interrupt address for serial port 5. Disabled No base address is assigned to serial port 5 Serial port 5 I/O port address is 3E8 Serial port 5 I/O port address is 2E8 Serial port 5 I/O port address is 2F0 EFAULT...

  • Page 104: Hardware Health Configuration

    PPC-5190 Flat Panel PC Serial Port6 IRQ [10] Use the Serial Port6 IRQ option to select the interrupt address for serial port 6. Serial port 6 IRQ address is 3 Serial port 6 IRQ address is 9 Serial port 6 IRQ address is 10 EFAULT Serial port 6 IRQ address is 11 5.3.5 Hardware Health Configuration...

  • Page 105: H/W Health Function [Enabled]

    PPC-5190 Flat Panel PC H/W Health Function [Enabled] Disabled Disables the health monitoring function Enabled Enables the health monitoring function EFAULT If the H/W Health Function is enabled different system parameters and values are shown. The system parameters that are monitored are: System Temperatures: The following system temperatures are monitored CPU Temperature System Temperature...

  • Page 106: Acpi Configuration

    PPC-5190 Flat Panel PC 5.3.6 ACPI Configuration The ACPI Configuration menu (BIOS Menu 9) configures the Advanced Configuration and Power Interface (ACPI) and Power Management (APM) options. BIOS Menu 9: ACPI Configuration Page 106...

  • Page 107: General Acpi Configuration

    PPC-5190 Flat Panel PC 5.3.6.1 General ACPI Configuration Use the General ACPI Configuration menu (BIOS Menu 10) to select the ACPI state when the system is suspended. BIOS Menu 10: General ACPI Configuration Suspend Mode [S1 (POS)] Use the Suspend Mode option to specify the sleep state the system enters when it is not being used.

  • Page 108: Advanced Acpi Configuration

    PPC-5190 Flat Panel PC 5.3.6.2 Advanced ACPI Configuration Use the Advanced ACPI Configuration menu (BIOS Menu 11) to select the ACPI state when the system is suspended. BIOS Menu 11: Advanced ACPI Configuration Page 108...

  • Page 109: Acpi 2.0 Features [No]

    PPC-5190 Flat Panel PC ACPI 2.0 Features [No] Use the ACPI 2.0 Features option to enable the ACPI (Advanced Configuration and Power Interface) features. By enabling this feature the system RSDP (Root System Description Pointer) is able to obtain physical addresses for other 64-bit fixed system description tables.

  • Page 110: Apic Acpi Sci Irq [Disabled]

    PPC-5190 Flat Panel PC APIC ACPI SCI IRQ [Disabled] Use APIC ACPI SCI IRQ option to enable the system to send a flag report to the ACPI OS if a SCI IRQ interrupt event is made via the APIC. Disabled No flag report is sent to the ACPI OS when there is a EFAULT "SCI IRQ"...

  • Page 111: Mps Configuration

    PPC-5190 Flat Panel PC 5.3.7 MPS Configuration Use the MPS Configuration menu (BIOS Menu 12) to select `he multi-processor table. BIOS Menu 12: MPS Configuration MPS Revision [1.4] Use the Multiprocessor Specification (MPS) for OS option to specify the MPS version to be used.

  • Page 112: Remote Access Configuration

    PPC-5190 Flat Panel PC 5.3.8 Remote Access Configuration Use the Remote Access Configuration menu to configure remote access parameters. The Remote Access Configuration is an AMIBIOS feature and allows a remote host running a terminal program to display and configure the BIOS settings. Remote Access [Disabled] Use the Remote Access option to enable or disable access to the remote functionalities of the system.

  • Page 113: Usb Configuration

    PPC-5190 Flat Panel PC 5.3.9 USB Configuration Use the USB Configuration menu (BIOS Menu 13) to read USB configuration information and configure the USB settings. BIOS Menu 13: USB Configuration USB Configuration The USB Configuration field shows the system USB configuration. The items listed are: Module Version: x.xxxxx.xxxxx USB Devices Enabled The USB Devices Enabled field lists the USB devices that are enabled on the system...

  • Page 114: Usb Function [8 Usb Ports]

    PPC-5190 Flat Panel PC USB Function [8 USB Ports] Use the USB Function BIOS option to select USB function support. Disabled USB function support disabled 2 USB Ports USB function support two USB ports 4 USB Ports USB function support four USB ports USB function support six USB ports 6 USB Ports 8 USB Ports...

  • Page 115: Pci/Pnp

    PPC-5190 Flat Panel PC 5.4 PCI/PnP Use the PCI/PnP menu (BIOS Menu 14) to configure advanced PCI and PnP settings. WARNING! Setting wrong values for the BIOS selections in the PCIPnP BIOS menu may cause the system to malfunction. BIOS Menu 14: PCI/PnP Configuration Plug &...

  • Page 116: Pci Latency Timer [64]

    PPC-5190 Flat Panel PC If the operating system does not meet the Plug and Play EFAULT specifications, this option allows the BIOS to configure all the devices in the system. This setting allows the operating system to change the interrupt, I/O, and DMA settings. Set this option if the system is running Plug and Play aware operating systems.

  • Page 117: Palette Snooping [Disabled]

    PPC-5190 Flat Panel PC Palette Snooping [Disabled] Use the Palette Snooping option to enable or disable the palette snooping function. Disabled Unless the VGA card manufacturer requires palette EFAULT snooping to be enabled, this option should be disabled. Enabled PCI devices are informed that an ISA based Graphics device is installed in the system so the ISA based Graphics card functions correctly.

  • Page 118: Irq# [Available]

    PPC-5190 Flat Panel PC PCI Slot 1 PCI Slot 1 is selected as the location of the OffBoard PCI IDE adapter card. Only select this slot if the adapter card is installed in PCI Slot 1. PCI Slot 2 PCI Slot 2 is selected as the location of the OffBoard PCI IDE adapter card.

  • Page 119: Dma Channel# [Available]

    PPC-5190 Flat Panel PC Available IRQ addresses are: IRQ3 IRQ4 IRQ5 IRQ7 IRQ9 IRQ10 IRQ 11 IRQ 14 IRQ 15 DMA Channel# [Available] Use the DMA Channel# option to assign a specific DMA channel to a particular PCI/PnP device. The specified DMA is available to be used by Available EFAULT PCI/PnP devices...

  • Page 120: Boot

    PPC-5190 Flat Panel PC Reserved Memory Size [Disabled] Use the Reserved Memory Size BIOS option to specify the amount of memory that should be reserved for legacy ISA devices. Disabled No memory block reserved for legacy ISA devices EFAULT 16KB reserved for legacy ISA devices 32KB reserved for legacy ISA devices 64KB reserved for legacy ISA devices 5.5 Boot...

  • Page 121: Boot Settings Configuration

    PPC-5190 Flat Panel PC 5.5.1 Boot Settings Configuration Use the Boot Settings Configuration menu (BIOS Menu 16) to configure advanced system boot options. BIOS Menu 16: Boot Settings Configuration Quick Boot [Enabled] Use the Quick Boot BIOS option to make the computer speed up the boot process. Disabled No POST procedures are skipped Enabled...

  • Page 122: Addon Rom Display Mode [Force Bios]

    PPC-5190 Flat Panel PC Disabled Normal POST messages displayed EFAULT Enabled OEM Logo displayed instead of POST messages AddOn ROM Display Mode [Force BIOS] Use the AddOn ROM Display Mode option to allow add-on ROM (read-only memory) messages to be displayed. Force BIOS The system forces third party BIOS to display EFAULT...

  • Page 123: Boot Device Priority

    PPC-5190 Flat Panel PC Disabled PS/2 mouse support is disabled and prevented from using system resources. Allows the system to use a PS/2 mouse. Enabled Auto The system auto-adjusts PS/2 mouse support. EFAULT 5.5.2 Boot Device Priority Use the Boot Device Priority menu (BIOS Menu 17) to specify the boot sequence from the available devices.

  • Page 124: Removable Drives

    PPC-5190 Flat Panel PC 5.5.3 Removable Drives Use the Removable Drives menu (BIOS Menu 18) to specify the boot sequence of the available FDDs. When the menu is opened, the FDDs connected to the system are listed as shown below: 1st Drive [1st FLOPPY DRIVE] NOTE:...

  • Page 125: Security

    PPC-5190 Flat Panel PC 5.6 Security Use the Security menu (BIOS Menu 19) to set system and user passwords. BIOS Menu 19: Security Change Supervisor Password Use the Change Supervisor Password to set or change a supervisor password. The default for this option is Not Installed. If a supervisor password must be installed, select this field and enter the password.

  • Page 126: Chipset

    PPC-5190 Flat Panel PC 5.7 Chipset Use the Chipset menu (BIOS Menu 20) to access the NorthBridge and SouthBridge configuration menus WARNING! Setting the wrong values for the Chipset BIOS selections in the Chipset BIOS menu may cause the system to malfunction. BIOS Menu 20: Chipset Page 126...

  • Page 127: Northbridge Configuration

    PPC-5190 Flat Panel PC 5.7.1 NorthBridge Configuration Use the NorthBridge Configuration menu (BIOS Menu 21) to configure the northbridge chipset. BIOS Menu 21: NorthBridge Chipset Configuration DRAM Frequency [Auto] Use the DRAM Frequency option to specify the DRAM frequency or allow the system to automatically detect the DRAM frequency.

  • Page 128: Configure Dram Timing By Spd [Enabled]

    PPC-5190 Flat Panel PC Configure DRAM Timing by SPD [Enabled] Use the Configure DRAM Timing by SPD option to determine if the system uses the SPD (Serial Presence Detect) EEPROM to configure the DRAM timing. The SPD EEPROM contains all necessary DIMM specifications including the speed of the individual components such as CAS and bank cycle time as well as valid settings for the module and the manufacturer's code.

  • Page 129: Init. Graphic Adapter Priority [Pci/Int-Vga]

    PPC-5190 Flat Panel PC Init. Graphic Adapter Priority [PCI/Int-VGA] The Init. Graphic Adapter Priority option selects the graphics controller the system uses as a primary boot device. The options are: Internal VGA PCI/Int-VGA EFAULT Internal Graphics Mode Select [Enable, 8MB] Use the Internal Graphic Mode Select option to specify the amount of system memory that can be used by the Internal graphics device.

  • Page 130: Boot Display Device [Crt+Lfp]

    PPC-5190 Flat Panel PC Boot Display Device [CRT+LFP] Use the Boot Display Device option to select the display device used by the system when it boots. Configuration options are listed below. CRT+LFP EFAULT Flat Panel Type [640x480] Use the Flat Panel Type option to select the type of flat panel connected to the system. Configuration options are listed below.

  • Page 131: Southbridge Configuration

    PPC-5190 Flat Panel PC 5.7.2 SouthBridge Configuration The SouthBridge Configuration menu (BIOS Menu 22) the southbridge chipset to be configured. BIOS Menu 22: SouthBridge Chipset Configuration OnBoard AC97 Audio [Auto] Use the OnBoard AC97 Audio option to enable or disable the AC’97 CODEC. The onboard AC’97 automatically detected and enabled Auto EFAULT...

  • Page 132: Power

    PPC-5190 Flat Panel PC 5.8 Power The Power menu (BIOS Menu 23) allows the advanced power management options to be configured. BIOS Menu 23: Power Power Management/APM [Enabled] Use the Power Management/APM BIOS option to enable access to the advanced power management features.

  • Page 133: Video Power Down Mode [Suspend]

    PPC-5190 Flat Panel PC Video Power Down Mode [Suspend] The Video Power Down Mode BIOS option specifies in what system mode the video device can be turned off. Disabled The Video cannot be turned off in the Suspend or Standby mode Standby The video can be turned off in the Standby mode Suspend...

  • Page 134: Suspend Time Out [Disabled]

    PPC-5190 Flat Panel PC 10 Min 20 Min 30 Min 40 Min 50 Min 60 Min Suspend Time Out [Disabled] The Suspend Time Out option specifies what length of time without activity on certain components will place those components in a suspended state. The options are listed below: Disabled Default...

  • Page 135: Restore On Ac Power Loss [Last State]

    PPC-5190 Flat Panel PC Restore on AC Power Loss [Last State] Use the Restore on AC Power Loss option to specify what state the system returns to if there is a sudden loss of power to the system. Power Off The system remains turned off The system turns on Power On...

  • Page 136: Resume On Rtc Alarm [Disabled]

    PPC-5190 Flat Panel PC Resume On RTC Alarm [Disabled] Use the Resume On RTC Alarm option to specify the time the system should be roused from a suspended state. Disabled The real time clock (RTC) cannot generate a wake EFAULT event Enabled If selected, the following appears with values that...

  • Page 137: Exit

    PPC-5190 Flat Panel PC 5.9 Exit Use the Exit menu (BIOS Menu 24) to load default BIOS values, optimal failsafe values and to save configuration changes. BIOS Menu 24:Exit Page 137...

  • Page 138: Save Changes And Exit

    PPC-5190 Flat Panel PC Save Changes and Exit Use the Save Changes and Exit option to save the changes made to the BIOS options and to exit the BIOS configuration setup program. Discard Changes and Exit Use the Discard Changes and Exit option to exit the BIOS configuration setup program without saving the changes made to the system.

  • Page 139: Aiei Panel Pc Product Line

    PPC-5190 Flat Panel PC Appendix IEI Panel PC Product Line Page 139...

  • Page 140: Iei Panel Pc Products

    PPC-5190 Flat Panel PC A.1 IEI Panel PC Products A.1.1 Overview IEI panel PC products are flexible, multi-functional flat panel PCs that can be applied in diverse operational environments and implemented in multi-faceted applications. IEI panel PC products come fully kitted with high-performance motherboards, CPUs, power supply units and a host of other peripheral interface connectors.

  • Page 141: Series Panel Pc Solutions

    PPC-5190 Flat Panel PC Model PPC-2706GS PPC-2708GS Viewing Angle 120/100 120/100 Backlight MTBF 50000hrs 20000hrs SBC Model WAFER-LX800 WAFER-LX800 AMD LX800 AMD LX800 1 x DDR 333/400MHz 1 x DDR 333/400MHz SO DIMM socket up to SO DIMM socket up to 1GB I/O Ports 1 x RS-232 2 x RS-232...
  • Page 142 PPC-5190 Flat Panel PC Model PPC-3708GS PPC-3710GS PPC-3712GS PPC-3715GS PPC-3717GS LCD Size 8.4” TFT LCD 10.4” TFT LCD 12.1” TFT LCD 15” TFT LCD 17” TFT LCD Max. Resolution 800 x 600 800 x 600 800 x 600 1024 x 786 1280 x 1024 Brightness 220 cd/m2...

  • Page 143: Series Panel Pc Solutions

    ® All the models listed in the table below support Intel Pentium® 4 / Celeron® D CPUs up to 2.8GHz. Model PPC-5150GS PPC-5170GS PPC-5190GS LCD Size 15” TFT LCD 17” TFT LCD 19” TFT LCD Max. 1024 x 786 1280 x 1024...
  • Page 144 PPC-5190 Flat Panel PC Model PPC-5150GS PPC-5170GS PPC-5190GS Resolution Brightness 350 cd/m2 300 cd/m2 300 cd/m2 LCD Color 262K 16.2M 16.2M Viewing Angle 120/100 140/130 140/130 Backlight 50000hrs 50000hrs 50000hrs MTBF SBC Model POS-8520 POS-8520 POS-8520 (Socket 478) (Socket 478) (Socket 478) Pentium®...

  • Page 145: Series Panel Pc Solutions

    PPC-5190 Flat Panel PC Model PPC-5150GS PPC-5170GS PPC-5190GS Mounting Stand/Rack/ Stand/Rack/ Stand/Rack/ Wall/Panel/Arm Wall/Panel/Arm Wall/Panel/Arm Dimension 410 x 309 x 110 452 x 356 x 110 482 x 399 x 110 (WxDxH) mm Weight 7/11kg 8/12kg 12.6/18.2kg Front Panel IP 65 compliant...

  • Page 146: Series Panel Pc Solutions

    PPC-5190 Flat Panel PC Model PPC-5150GS PPC-5170GS PPC-5190GS 3 x RS-232 3 x RS-232 3 x RS-232 4 x USB 2.0 6 x USB 2.0 6 x USB 2.0 2 x PS/2 2 x PS/2 2 x PS/2 1 x LPT...
  • Page 147 PPC-5190 Flat Panel PC Model PPC-5350GS LCD Size 15” TFT LCD Max. Resolution 1024 x 786 Brightness 350 cd/m2 LCD Color 262K Viewing Angle 120/100 Backlight MTBF 50000hrs SBC Model A-300 (Socket 479) Pentium® M / Celeron ® M / ULV Celeron®...
  • Page 148 PPC-5190 Flat Panel PC Model PPC-5350GS Wall/Panel/Arm Dimension (WxDxH) mm 410 x 309 x 110 Weight 8/12kg Front Panel Protection IP 65 compliant Touch Screen Resistive Type 5-wire with RS-232 Interface Table A-5: PPC-53 Series Panel PC Solutions Page 148...

  • Page 149: Binterface Connectors

    PPC-5190 Flat Panel PC Appendix Interface Connectors Page 149...

  • Page 150: Floppy Disk Drive Connector

    PPC-5190 Flat Panel PC The PPC-5190 flat panel PC POS-8520 motherboard comes with a number of peripheral interface connectors and configuration jumpers listed in Chapter 2. The pinouts for these connectors are listed below. B.1 Floppy Disk Drive Connector POS-8520 board is equipped with a 34-pin daisy-chain driver connector cable. Description Description GROUND...

  • Page 151: Pcie - Ide Disk Drive Connector

    PPC-5190 Flat Panel PC B.2 PCIe - IDE Disk Drive Connector Four IDE (Integrated Device Electronics) hard disk drives can be attached to the POS-8520 IDE controller. IDE1, IDE2: Primary, Secondary IDE Connector Description Description RESET# DATA 7 DATA 8 DATA 6 DATA 9 DATA 5...

  • Page 152: Parallel Port

    PPC-5190 Flat Panel PC B.3 Parallel Port This port is usually connected to printer. The POS-8520 includes one on-board parallel port, accessed through 25-pin D-type female connector LPT1. LPT1: (LPT1 DB-25 Female) Parallel Port Connector Description Description STROBE# DATA 0 DATA 1 DATA 2 DATA 3...

  • Page 153: Serial Ports

    PPC-5190 Flat Panel PC B.4 Serial Ports The POS-8520 offers six high speed NS16C550 compatible UARTs with Read/Receive 16 byte FIFO serial port (COM1/COM2/COM3/COM4/COM5/COM6) COM1: Serial Port 2x5 pin header Connector Description Description CN20A: Serial Port DB-9 Male Connector (COM1) Description DATA CARRIER DETECT (DCD) RECEIVE DATA (RXD)
  • Page 154 PPC-5190 Flat Panel PC RS-232 Mode Description Description RS-422 Mode Description Description TXD- TXD+ Voltage RS-485 Mode Description Description RTX- RTX+ Voltage CN20B: Serial Port DB-9 Male Connector (COM2) COM2 supports three modes: RS-232, RS-422 and RS-485 (via DB-9 Connector). Page 154...
  • Page 155 PPC-5190 Flat Panel PC RS-232 Mode Description Description RS-422 Mode Description Description TXD- TXD+ Voltage RS-485 Mode Description Description RTX- RTX+ Voltage Page 155...
  • Page 156 PPC-5190 Flat Panel PC COM3: Serial Port 2x5 Pin Header Connector Description Description COM4: Serial Port 2x5 Pin Header Connector Description Description Page 156...
  • Page 157 PPC-5190 Flat Panel PC CN22: Serial Port DB-9 Male Connector (COM4) Description DATA CARRIER DETECT (DCD) RECEIVE DATA (RXD) TRANSMIT DATA (TXD) DATA TERMINAL READY (DTR) GROUND (GND) DATA SET READY (DSR) REQUEST TO SEND (RTS) CLEAR TO SEND (CTS) RING INDICATOR (RI) COM5: Serial Port 2x5 Pin Header Connector Description...

  • Page 158: Keyboard / Mouse Connector

    PPC-5190 Flat Panel PC B.5 Keyboard / Mouse Connector The POS-8520 provides one keyboard and one mouse box header connector, as well as external PS/2 keyboard and mouse connectors. CN23A (Purple): Extended Keyboard 6-pin Mini Din Connector Description KB DATA KB CLOCK CN23B (Green): Extended Mouse 6-pin Mini Din Connector Description...

  • Page 159: External Switches And Indicators

    PPC-5190 Flat Panel PC CN15: PS/2 Mouse 5-pin Header Connector Description MS CLOCK MS DATA B.6 External Switches and Indicators CN8: Multi Panel Description Description SPEAKER POWER-VCC KEYLOCK RESET SW IDE LED - IDE LED+ ATX POWER CONTROL ATX POWER BUTTON ATX 5VSB ATX 5VSB Page 159...

  • Page 160: Usb Port Connector

    PPC-5190 Flat Panel PC B.7 USB Port Connector The POS-8520 has eight built-in USB ports for the future I/O bus expansion. CN26, CN27, CN28: 8-PIN Header USB Connectors Description USBD0- USBD0+ CN25: 2 External USB Connectors Description USBD0- USBD0+ Page 160...

  • Page 161: I Rda Infrared Interface Port

    PPC-5190 Flat Panel PC B.8 IrDA Infrared Interface Port The POS-8520 has a built-in IrDA port that supports Serial Infrared (SIR) or Amplitude Shift Keyed IR (ASKIR) interfaces. To use the IrDA port, configure the FIR or ASKIR model in the Peripheral Setup COM2 in BIOS. Then the normal RS-232 COM2 will be disabled.

  • Page 162: Vga Connector

    PPC-5190 Flat Panel PC B.9 VGA Connector The POS-8520 provides one DB-15 female connector and one built-in 10-pin VGA box header connector that can be connected directly to a monochrome CRT monitor as well as high resolution color CRT monitor. VGA1: DB-15 Female VGA Connector Description Description...

  • Page 163: Lan Rj45 Connector

    PPC-5190 Flat Panel PC B.10 LAN RJ45 Connector The POS-8520 is equipped with two Gigabit Ethernet Controller RTL8110SC chipsets and two GbE LAN RJ-45 connectors. CN31: Dual LAN RJ45 Connector Description Description TX+ (or MDX0+) N/C (or MDX2-) TX- (or MDX0-) RX- (or MDX1-) RX+ (or MDX1+) N/C (or MDX3+)

  • Page 164: Inverter (Lcd Backlight) Connector

    PPC-5190 Flat Panel PC FAN2: System Fan Connector Description +12V Fan Sensor FAN3: System Fan Connector Description +12V Fan Sensor B.12 Inverter (LCD Backlight) Connector CN12: Inverter (LCD Backlight) Connector Description Description +12V ENABKL Page 164...

  • Page 165: Lcd Panel Lvds Interface Connector

    PPC-5190 Flat Panel PC B.13 LCD Panel LVDS Interface Connector The POS-8520 provides up to 48-bit color TFT LCD. CN30: DF13-30DP-1.25 LVDS Interface Connector Description Description CLK1P CLK1M CLK2P CLK2M LCD_VDD LCD_VDD LCD_VDD LCD_VDD B.14 Audio Connectors CN7: Audio CD IN (2.54mm) Description Description CD IN_L...

  • Page 166: Digital Input / Output

    PPC-5190 Flat Panel PC CN2: Audio LINE OUT (2.54mm) Description Description LINEOUT_L LINE OUT_R CN24: Audio Jack Color Description MIC IN BLUE LINE IN GREEN SPEAK OUT B.15 Digital Input / Output CN6: Digital Input / Output Description Description Output 3 Output 2 Output 1 Output 0...

  • Page 167: Compact Flash Type Ii Storage Card Socket

    PPC-5190 Flat Panel PC B.16 Compact Flash TYPE II Storage Card Socket The POS-8520 configures Compact Flash TYPE II Storage Card in IDE Mode. CF1: Compact Flash TYPE II Socket PIN Assignment Description Description GROUND CARD DETECT1 CS1# CS3# GROUND IOR# IOW# OBLIGATORY TO PULL HIGH...

  • Page 168: Atx Power Connector

    PPC-5190 Flat Panel PC B.17 ATX Power Connector PW2 is a 20-pin ATX power supply connector with the following pin assignments. PW2: ATX Power Supply Connector Description Description 3.3V 3.3V -12V 3.3V PS-ON Power good 5VSB +12V B.18 ATX 12V Power Connector This connector supports ATX power.

  • Page 169: Internal Switches And Indicators

    PPC-5190 Flat Panel PC NOTE: The power from PW1 should support at least a 6.5A current for the P4 CPU. If the power output is too low, the CPU may not function normally. Be sure the power from the power supply is sufficient, and don’t share this power with other devices, such as hard disk etc.
  • Page 170 PPC-5190 Flat Panel PC THIS PAGE IS INTENTIONALLY LEFT BLANK Page 170...

  • Page 171: Bios Configuration Options

    PPC-5190 Flat Panel PC Appendix BIOS Configuration Options Page 171...

  • Page 172: Bios C O

    PPC-5190 Flat Panel PC C.1 BIOS Configuration Options Below is a list of BIOS configuration options described in Chapter 5. System Overview ....................84 System Time [xx:xx:xx] ..................85 System Date [xx/xx/xx] ..................85 Max CUPID Value Limit [Disabled] ...............88 Hyper Threading Technology [Disabled] ............88 IDE Configuration [P-ATA Only]................89 S-ATA Running Enhanced Mode [Yes]..............90 P-ATA Channel Selection [Both] ................90...
  • Page 173 PPC-5190 Flat Panel PC Parallel Port Address [378] ...................99 Parallel Port Mode [Normal]................100 Parallel Port IRQ [IRQ7]..................101 Digital I/O Address [280h] .................. 101 Serial Port3 Address [3E8]................. 101 Serial Port3 IRQ [11] ................... 102 Serial Port4 Address [2E8]................. 102 Serial Port4 IRQ [10] ...................
  • Page 174 PPC-5190 Flat Panel PC Plug & Play O/S [No]................... 115 PCI Latency Timer [64] ..................116 Allocate IRQ to PCI VGA [Yes] ................116 Palette Snooping [Disabled] ................117 PCI IDE BusMaster [Disabled] ................117 OffBoard PCI/ISA IDE Card [Auto] ..............117 IRQ# [Available]....................
  • Page 175 PPC-5190 Flat Panel PC Resume on Ring/LAN [Disabled]............... 135 Resume on PME# [Disabled] ................135 Resume On RTC Alarm [Disabled]..............136 RTC Alarm Date (Days) ..................136 System Time......................136 Save Changes and Exit ..................138 Discard Changes and Exit ................. 138 Discard Changes....................
  • Page 176 PPC-5190 Flat Panel PC THIS PAGE IS INTENTIONALLY LEFT BLANK Page 176...

  • Page 177: Dsoftware Drivers

    PPC-5190 Flat Panel PC Appendix Software Drivers Page 177...

  • Page 178: Introduction

    PPC-5190 Flat Panel PC D.1 Introduction The touch panel controller enables analog resistive touch panels for four-wire, five-wire & eight-wire models. The controller directly communicates with the PC system through the touch panel communications interface. The controller design is superior in sensitivity, accuracy, and friendly operation.
  • Page 179 PPC-5190 Flat Panel PC Figure C-1: Driver CD Pop Up Screen Step 3: Select the operating system installed on the system from the menu on the left side of the screen. NOTE: The following description is for driver installation using a Windows 2000 OS.
  • Page 180 PPC-5190 Flat Panel PC Figure C-2: Install Shield Wizard Preparation Step 5: After the Install Shield Wizard is ready, a welcome screen appears (Figure C-3). Figure C-3: Welcome Screen Step 6: To continue the installation process click N Step 7: An Install PS/2 interface driver screen appears (Figure C-4).
  • Page 181 PPC-5190 Flat Panel PC Figure C-4: Install PS/2 Interface Driver Step 8: Four point calibration options are then selected. Four point calibrations can be done every time a user boots up, during the next time the system boots or never. Select when a four-point calibration should be done.
  • Page 182 PPC-5190 Flat Panel PC Figure C-5: Install PS/2 Interface Driver Step 9: The user is then prompted to ensure the touch monitor or the USB for the touch controller is plugged into the system (Figure C-6). Once the touch controller is plugged into the system, click OK.
  • Page 183 PPC-5190 Flat Panel PC Figure C-7: Controller Installation Directory Step 11: The user is then prompted to select a file directory in which the program icons are saved (Figure C-8). The default folder is “TouchKit.” If a different folder must be used, select a folder from the list shown.
  • Page 184 PPC-5190 Flat Panel PC Figure C-8: Program Icon Directory Step 12: The program then starts installing (Figure C-9). Figure C-9: Installing Page 184...

  • Page 185: Touch Panel Driver Configuration

    PPC-5190 Flat Panel PC Step 13: Once the program is finished installing, the user is prompted to restart the computer now or to restart the computer later (Figure C-10). Select when the computer should be restarted and click F to complete the driver installation INISH procedure.
  • Page 186 PPC-5190 Flat Panel PC THIS PAGE IS INTENTIONALLY LEFT BLANK Page 186...

  • Page 187: Index

    PPC-5190 Flat Panel PC Index Page 187...
  • Page 188 PPC-5190 Flat Panel PC embedded system solutions ....140 Applications ..........20 Ethernet Connection ........66 Arm Mounting ..........65 External Peripheral Device Connectors..42 ATX 12V Power Connector......168 External Switches and Indicators.... 159 ATX Power Connector ......168 Audio Connectors ........165 Audio Port Connection.......67 Fan Connector ........
  • Page 189 PPC-5190 Flat Panel PC PCI E-IDE Disk Drive Connector .... 151 Power Supply..........30 Keyboard / Mouse Connector....158 Preinstalled Components......44 Keyboard and Mouse Connection .....67 Preinstalled Hardware Components ..26 Keyboard and Mouse Power Setting ..52 PSU Module Replacement ......75 LAN RJ45 Connector.......163 Safety Precautions........3 LCD Panel Connection ......66 Serial ATA Connector ......

Table of Contents
