- Page 1 IOVU-430S Panel PC MODEL: IOVU-430S 4.3" Touch Panel PC, Samsung S3C2416 400 MHz CPU, Fast Ethernet, USB, microSD, CAN Bus, RS-232/422/485, RoHS Compliant, IP 64 Compliant Front Panel User Manual Page i Rev. 1.10 – November 27, 2014...
- Page 2 IOVU-430S Panel PC Revision Date Version Changes November 27, 2014 1.10 Updated for R11 version: - Changed miniSD slot to microSD slot - Updated Section 3.5.1: Wireless Connection Setup September 4, 2012 1.01 Minor change August 20, 2012 1.00 Initial release...
- Page 3 IOVU-430S Panel PC Copyright COPYRIGHT NOTICE The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer. In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.
-
Page 4: Table Of Contents
IOVU-430S Panel PC Table of Contents 1 INTRODUCTION......................1 1.1 O ........................2 VERVIEW 1.2 M ....................3 ODEL ARIATIONS 1.3 B ........................3 ENEFITS 1.4 F ........................3 EATURES 1.5 F ......................4 RONT ANEL 1.6 C ....................5... - Page 5 IOVU-430S Panel PC 3.5 S ........................ 24 OFTWARE 3.5.1 Wireless Connection Setup................25 A CERTIFICATIONS ....................29 A.1 R HS C ....................30 OMPLIANT A.2 IP 64 C ................30 OMPLIANT RONT ANEL B SAFETY PRECAUTIONS ..................31 B.1 S .....................
- Page 6 List of Figures Figure 1-1: IOVU-430S........................2 Figure 1-2: Front Panel ........................4 Figure 1-3: IOVU-430S Peripheral Connectors ................5 Figure 1-4: IOVU-430S Physical Dimensions (millimeters) ............6 Figure 1-5: Power Input Connector....................7 Figure 3-1: microSD Card Installation ..................15 Figure 3-2: IOVU-430S Peripheral Connectors ................16 Figure 3-3: Power Terminal Block....................17...
- Page 7 IOVU-430S Panel PC List of Tables Table 1-1: IOVU-430S Specifications ....................3 Table 1-2: Technical Specifications....................9 Table 2-1: Package List Contents ....................12 Table 2-2: Optional Items......................13 Table 3-1: External Interface Connectors...................16 Table 3-2: 12 V–36 V Power Connector Pinouts................17 Table 3-3: GPIO and CAN Bus Connector Pinouts ..............18 Table 3-4: RS-232/422/485 Pinouts .....................20...
-
Page 9: Introduction
IOVU-430S Panel PC Chapter Introduction Page 1... -
Page 10: Overview
1.1 Overview Figure 1-1: IOVU-430S The IOVU-430S Panel PC comes with a 4.3" touch panel screen. It is powered by a Samsung ARM9 S3C2416 400 MHz processor and has 128 MB of DDR SDRAM and 128 MB of NAND flash. -
Page 11: Model Variations
IOVU-430S Panel PC 1.2 Model Variations The IOVU-430S is available in the following model variations. Model No. Touch Panel Type Wi-Fi IOVU-430S-CE6/ST/-R11 4-wire resistive type IOVU-430S-CE6/ST/WL/-R11 4-wire resistive type 802.11b/g Table 1-1: IOVU-430S Specifications 1.3 Benefits Some of the IOVU-430S benefits include: ... -
Page 12: Front Panel
IOVU-430S Panel PC 1.5 Front Panel The IOVU-430S front panel (Figure 1-2) comprises a 4.3" TFT WQVGA color touch screen LCD in an ABS+PC plastic frame. Figure 1-2: Front Panel Page 4... -
Page 13: Connector Panel
1.6 Connector Panel The external peripheral interface connectors are located on the bottom and side panels of the IOVU-430S . The peripheral interface connectors are shown in Figure 1-3. Figure 1-3: IOVU-430S Peripheral Connectors External peripheral interface connectors on the IOVU-430S include: ... -
Page 14: Dimensions
IOVU-430S Panel PC 1.7 Dimensions The physical dimensions of the IOVU-430S are shown in Figure 1-4 and listed below: Width: 145 mm Height: 104 mm Depth: 34 mm Figure 1-4: IOVU-430S Physical Dimensions (millimeters) Page 6... -
Page 15: Power Supply And Battery
Dispose of used batteries according to the instructions. The IOVU-430S has a terminal block connector on the bottom panel for DC power input. Please see Section 3.3.1 for the connector pinouts. -
Page 16: Technical Specifications
IOVU-430S Panel PC 1.9 Technical Specifications The IOVU-430S technical specifications are listed in Table 1-2. System Specifications Samsung ARM9 S3C2416 400 MHz processor 128 MB DDR SDRAM Memory 128 MB NAND flash One microSD card slot Storage Windows Embedded CE 6.0 preinstalled in NAND flash... -
Page 17: Certifications
Net Weight IP 64 compliant front panel Ingress Protection Table 1-2: Technical Specifications 1.10 Certifications All IOVU-430S series models comply with the following international standards: RoHS IP 64 compliant front panel For a more detailed description of these standards, please refer to Appendix A. -
Page 18: Unpacking
IOVU-430S Panel PC Chapter Unpacking Page 10... -
Page 19: Anti-Static Precautions
Follow the anti-static precautions outlined in Section 2.1. Make sure the packing box is facing upwards so the IOVU-430S does not fall out of the box. Make sure all the components shown in Section 2.3 are present. -
Page 20: Unpacking Checklist
If some of the components listed in the checklist below are missing, please do not proceed with the installation. Contact the IEI reseller or vendor you purchased the IOVU-430S from or contact an IEI sales representative directly. To contact an IEI sales representative, please send an email to sales@ieiworld.com. -
Page 21: Optional Items
IOVU-430S Panel PC 2.4 Optional Items Item and Part Number Image 12V DC 60W power adapter with terminal block connector, 90-264V AC input (P/N: 63000-FSP060DBAB1555-RS) Table 2-2: Optional Items Page 13... -
Page 22: Installation
IOVU-430S Panel PC Chapter Installation Page 14... -
Page 23: Installation Precautions
Electric shock and personal injury might occur if the rear panel of the IOVU-430S is opened while the power cord is still connected to an electrical outlet. -
Page 24: External Peripheral Interface Connectors
IOVU-430S Panel PC 3.3 External Peripheral Interface Connectors Table 3-1 lists the external interface connectors on the IOVU-430S. Detailed descriptions of the connectors can be found following the table. Connector Type 12 V–36 V DC terminal block Terminal Block CAN bus... -
Page 25: 36 V Dc Terminal Block
Figure 3-3: Power Terminal Block 3.3.2 GPIO and CAN Bus Connector The IOVU-430S has a GPIO (pins 1-7) and CAN bus connector (pins 8-10). The GPIO can be used to connect to external devices or peripherals. The CAN bus connector connects to a Controller-Area Network (CAN). -
Page 26: Rs-232/422/485 Serial Port
This section outlines the usage and setup of the serial port on the bottom I/O panel. 3.3.3.1 Connecting the Serial Port The IOVU-430S has one female DB-9 connector on the external peripheral interface panel for connections to serial devices. Follow the steps below to connect a serial device to the IOVU-430S. -
Page 27: Rs-232/422/485 Selection
IOVU-430S Panel PC Figure 3-5: Serial Device Connector Secure the connector. Secure the serial device connector to the external Step 2: interface by tightening the two retention screws on either side of the connector. Step 0: 3.3.3.2 RS-232/422/485 Selection To select RS-232/422/485 mode, please follow the directions below. -
Page 28: Pinouts
IOVU-430S Panel PC Select COM1 mode setting. Select the desired mode setting for Serial Port Step 2: COM1 in the drop down menu (Figure 3-6). RS-232 RS-422 RS-485 Click the Set button. Click the Set button to apply the mode setting change. -
Page 29: Usb Host Connector
The external USB Series "A" receptacle connector provides easier and quicker access to external USB devices. To connect USB devices to the IOVU-430S, insert the USB Series "A" plug of a device into the USB Series "A" receptacle on the external peripheral interface. -
Page 30: Figure 3-9: Lan Connection
IOVU-430S Panel PC Figure 3-9: LAN Connection Insert the LAN cable RJ-45 connector. Once aligned, gently insert the LAN Step 2: cable RJ-45 connector into the on-board RJ-45 connector. Step 0: The Ethernet connector pinouts are shown below. DESCRIPTION TPT+... -
Page 31: In-Wall Mounting
Standards Association (VESA) compliant. IEI provides an in-wall cage to mount the IOVU-430S into a wall. To mount the IOVU-430S in a wall, please follow the steps below. Insert the four monitor mounting screws into the four screw holes on the real... -
Page 32: Software
For information about configuring the operating system, adding remote management tools or additional software and drivers, refer to the user manuals on IEI IOVU Utility CD that came with the IOVU-430S. The IOVU includes the following software:... -
Page 33: Wireless Connection Setup
Built-in .NET Compact Framework support with related SDK Thin Client Technology, Microsoft RDP (Remote Desktop Protocol), to enable IOVU-430S to access Microsoft Windows® based applications installed on Microsoft Terminal Service server. Free pre-installed utilities for configuring and diagnosing your IOVU-430S. -
Page 34: Figure 3-15: Laird Connection Manager-Scan
IOVU-430S Panel PC Figure 3-15: Laird Connection Manager–Scan The Admin Login window appears (Figure 3-16). Leave the password field Step 4: blank and click OK. (Note: the network password will be entered later.) Figure 3-16: Laird Connection Manager–Admin Login Click Yes in Figure 3-17 to create a new network profile. -
Page 35: Figure 3-18: Laird Connection Manager-Manage Profiles
IOVU-430S Panel PC Figure 3-18: Laird Connection Manager–Manage Profiles Scroll down to the bottom and click Passphrase. Enter the password for the Step 7: network in the Value field. Click the Commit button to connect the network. Click OK to close the window. See Figure 3-19. -
Page 36: Figure 3-20: Laird Connection Manager-Select Network
IOVU-430S Panel PC Figure 3-20: Laird Connection Manager–Select Network When the network is successfully connected, the icon in the notification area (as Step 9: shown in Figure 3-21) appears. Figure 3-21: Network Connected Page 28... -
Page 37: A Certifications
IOVU-430S Panel PC Appendix Certifications Page 29... -
Page 38: Rohs Compliant
A.2 IP 64 Compliant Front Panel The front panel on the IOVU-430S models in the IOVU series have an ingress protection rating (IP) of 64 IP 64. The front panel is protected from dust particles and splashing water. -
Page 39: B Safety Precautions
IOVU-430S Panel PC Appendix Safety Precautions Page 31... -
Page 40: Safety Precautions
Do not apply voltage levels that exceed the specified voltage range. Doing so may cause fire and/or an electrical shock. Electric shocks can occur if the IOVU-430S chassis is opened when the IOVU-430S is running. Do not drop or insert any objects into the ventilation openings of the IOVU-430S. -
Page 41: Anti-Static Precautions
When maintaining or cleaning the IOVU-430S, please follow the guidelines below. B.2.1 Maintenance and Cleaning Prior to cleaning any part or component of the IOVU-430S please read the details below. Except for the LCD panel, never spray or squirt liquids directly onto any other ... -
Page 42: Cleaning Tools
Some components in the IOVU-430S may only be cleaned using a product specifically designed for the purpose. In such case, the product will be explicitly mentioned in the cleaning tips. Below is a list of items to use when cleaning the IOVU-430S. ... -
Page 43: Fcc Precautions
IOVU-430S Panel PC B.4 FCC Precautions WARNING: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This... -
Page 44: C Hazardous Materials Disclosure
IOVU-430S Panel PC Appendix Hazardous Materials Disclosure Page 36... -
Page 45: Hazardous Materials Disclosure Table For Ipb Products Certified As Rohs Compliant Under 2002/95/Ec Without Mercury
IOVU-430S Panel PC C.1 Hazardous Materials Disclosure Table for IPB Products Certified as RoHS Compliant Under 2002/95/EC Without Mercury The details provided in this appendix are to ensure that the product is compliant with the Peoples Republic of China (China) RoHS standards. The table below acknowledges the presences of small quantities of certain materials in the product, and is applicable to China RoHS only. - Page 46 IOVU-430S Panel PC Part Name Toxic or Hazardous Substances and Elements Lead Mercury Cadmium Hexavalent Polybrominated Polybrominated (Pb) (Hg) (Cd) Chromium Biphenyls Diphenyl (CR(VI)) (PBB) Ethers (PBDE) Housing Display Printed Circuit Board Metal Fasteners Cable Assembly Fan Assembly Power Supply...
- Page 47 IOVU-430S Panel PC 此附件旨在确保本产品符合中国 RoHS 标准。以下表格标示此产品中某有毒物质的含量符 合中国 RoHS 标准规定的限量要求。 本产品上会附有”环境友好使用期限”的标签，此期限是估算这些物质”不会有泄漏或突变”的 年限。本产品可能包含有较短的环境友好使用期限的可替换元件，像是电池或灯管，这些元 件将会单独标示出来。 部件名称 有毒有害物质或元素 铅 汞 镉 六价铬 多溴联苯 多溴二苯 醚 (Pb) (Hg) (Cd) (CR(VI)) (PBB) (PBDE) 壳体 显示 印刷电路板 金属螺帽 电缆组装 风扇组装 电力供应组装 电池 O: 表示该有毒有害物质在该部件所有物质材料中的含量均在 SJ/T11363-2006 标准规定的限量要求以下。 X: 表示该有毒有害物质至少在该部件的某一均质材料中的含量超出 SJ/T11363-2006 标准规定的限量要求。...
