- Page 1 ALI-L19W ALI-L22W CCTV Monitor User Manual ALI-L19-22W_PM...
-
Page 2: Table Of Contents
Table Of Contents Information ..............................1 Important safeguards ..........................1 Introduction ..............................2 Features ..............................2 Assembling the monitor ..........................2 Assembling the monitor ..........................2 Disassembling the monitor ........................... 2 Connections ............................... 3 Front panel controls ..........................3 Control panel ............................... 3 Adjustment procedure ..........................4 OSD function ...............................5 VGA menu ..............................5... -
Page 3: Information
Information Important safeguards FCC compliance 1. Installation cautions: Class A: This equipment has been tested and • Do not block any ventilation openings. found to comply with the limits for a Class A digital • Always ensure that the monitor is located in device, pursuant to part 15 of the FCC Rules. -
Page 4: Introduction
Assembling the monitor used for a long period of time, if the power supply cable or plug/connector is damaged or if the monitor housing is damaged or The monitors are designed for use on a desktop. broken. The arm of the monitor stand is shipped pre- installed on the monitor. -
Page 5: Connections
2. ▲ (Up Arrow) Connections Primary Function: Select the input source. (19”,22”) Moves cursor to the up in the OSD window and increases the value of any selected menu. 3. ▼ (Down Arrow) Moves cursor to the down in the OSD window and decreases the value of any selected menu. -
Page 6: Adjustment Procedure
Adjustment procedure Perform the Auto tracking Adjust the Is the H.Size Clock control. proper? Perform the H - V Position. Is the noise displayed on the screen? Adjust the Phase until the screen is cleared. Is the noise displayed on the screen yet? -
Page 7: Osd Function
OSD function Adjust the contrast of image, the difference between light and dark areas on the screen. Configure the monitor using the onscreen display 3. Color Tone (OSD) menus and submenus. Changes are Choose a different preset color temperatures or immediately saved and implemented. -
Page 8: Sound (Optional)
Sound (optional) (Time setting) 1. Menu Language 1. Sound Mode Select language for OSD. Choose a different preset sound mode or your own customized sound. 2. Screen Format 2. Balance Select the aspect ratio. Adjust the sound balance of the left and right 3. -
Page 9: Lock
HDMI/CAM menu Lock Picture 1. Keypad Lock Turn keypad lock on or off (Advanced Setting) 2. Remote Control Lock(optional) Turn Remote Control lock on or off Motion (optional) 1. Picture Mode Select the picture mode. 2. Brightness 1. -
Page 10: Sound (Optional)
8-1 Noise Reduction When you select the user mode, adjust the treble sound. Reduce the noise in the picture due to poor reception or poor picture quality. 5. Equalizer 8-2 Back Light Provide an enhanced listening experience. 6. Auto Volume Adjust the back light to be brighter or darker. -
Page 11: Lock
7. Video Standard (cam mode only) 1. Motion Select the CVBS mode. Turn on or off motion. 2. Motion Duration 8. Time Setting Not used. 8-1 Time 3. Motion Logo Not used. Not used. 8-2 Sleep Timer 4. Flashing Logo Set sleep timer Not used. -
Page 12: Troubleshooting
Troubleshooting Symptom Check Clock Picture is jittery Adjust to set the screen position and adjust Clock value carefully until a noise is no longer displayed. No picture Check if the power switch and computer power switch are in the On position Check if the signal cable is correctly connected to the video card. -
Page 13: Specifications
Specifications Items ALI-L19W 18.5 in (47cm) Panel Screen size 0.300 x 0.300 mm Pixel pitch 170°/160° View angle (H/V) 1000:1 (typ) Contrast ratio 5 ms Response time 250 cd/m² (typ) Brightness 1366 x 768 @ 60Hz Recommended resolution Interface VGA in (15 Pin D-... - Page 14 Items ALI-L22W Panel Screen size 21.5 in (54.6cm) Pixel pitch 0.248 (H) x 0.248 (V) View angle (H/V) 170°/160° Contrast ratio 1000:1 (typ) Response time 5 ms Brightness 250 cd/m² (typ) Recommended 1920 x 1080 @ 60 Hz resolution Interface VGA in (15 Pin D-Sub) HDMI in...
-
Page 15: Factory Preset Timings (Vga Mode)
Factory preset timings (VGA mode) Horizontal Vertical Pixel Format Remark Freq.(KHz) Freq.(Hz) 720 x 400 31.469 70.087 All models 640 x 480 31.469 59.940 All models 640 x 480 37.861 72.809 All models 640 x 480 37.500 75.000 All models 800 x 600 37.870 60.317...
