CROSS-TRAINER 93X-0XXX-01
Customer Support Services
PARTS MANUAL
rev 30 Jul 2008

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 93X-0XXX-01 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Life Fitness 93X-0XXX-01

Summary of Contents for Life Fitness 93X-0XXX-01

  • Page 1 CROSS-TRAINER 93X-0XXX-01 Customer Support Services PARTS MANUAL rev 30 Jul 2008...

  • Page 2: Hardware Bag

    CROSS TRAINER 93X REFERENCES OPERATION MANUAL SERVICE MANUAL HARDWARE BAG PLUG IN OPTION 120/60 PLUG IN OPTION 240/50 UK PLUG IN OPTION 240v AUS PLUG IN OPTION 230/50 CONT C-SAFE KIT M051-00K62-A026 M051-00K62-A060 AK62-00152-0001 GK62-00002-0018 GK62-00002-0019 GK62-00002-0020 GK62-00002-0021 GK63-00002-0003 93X-0XXX-01 S/N XTB100000...

  • Page 3: Table Of Contents

    CROSS TRAINER 93X 93X-0XXX-01 CONTENTS S/N XTB100000 Page CONSOLE SUPPORT & DEADSHAFT COVERS ...4 HANDLEBARS AND BULLHORNS ...5 CONSOLE AND RELATED COMPONENTS...6 UPPER FRAME HARDWARE ...7 ROCKER ARMS AND PEDAL LEVERS ...8 CRANK COVER AND LOWER CAPS ...9 LOWER FRAME SHROUDS AND HARDWARE...10 PEDAL LEVER COMPONENTS ...11...

  • Page 4: Console Support & Deadshaft Covers

    Console Support Shroud 0K62-01023-0000 Right Inside Deadshaft Cover 0K62-01010-0000 Left Inside Deadshaft Cover 0K62-01011-0000 2-Front Inside Deadshaft Cover 0K62-01009-0000 Right Bullhorn Cover 0K62-01007-0001 Left Bullhorn Cover 0K62-01008-0001 2-Outside Front Deadshaft Cover 0K62-01013-0000 2-Outside Rear Deadshaft Cover 0K62-01012-0000 93X-0XXX-01 S/N XTB100000...

  • Page 5: Handlebars And Bullhorns

    *Right Bullhorn Assembly consists of: AK62-00057-0000 Bullhorn, 0K62-01136-0000 Grip and 0K62-01199-0000 Gasket Left Bullhorn Assembly consists of: AK62-00058-0000 Bullhorn, 0K62-01136-0000 Grip and 0K62-01199-0000 Gasket *Right Bullhorn Assembly AK62-00053-0000 Left Bullhorn Assembly AK62-00054-0000 Bullhorn Insert 0017-00009-1191 Left Handlebar AK62-00091-0000 93X-0XXX-01 S/N XTB100000...

  • Page 6: Console And Related Components

    0017-00101-1650 Polar PCB with Receiver AK39-00064-0000 Overlay/Bezel/Switch (see chart below) OVERLAY/BEZEL/SWITCH AK62-00190-0001 AK62-00190-0003 AK62-00190-0004 AK62-00190-0006 AK62-00190-0007 AK62-00190-0008 AK62-00190-0009 AK62-00190-0010 93X-0XXX-01 S/N XTB100000 Battery Door 0K62-01026-0000 Console Case with decal AK62-00142-0000 LANGUAGE Eng + Met Ger/Met Spn/Met Jap/Met Frn/Met Ital/Met Dut/Met...

  • Page 7: Upper Frame Hardware

    Cover Screws 0017-00101-1796 (2 per side) Bullhorn Mounting Screws (includes 4 screws) GK62-00002-0042 Items Not Shown: Accessory Tray 0K62-01022-0000 Mounting Screws (2) 0017-00101-1846 93X-0XXX-01 S/N XTB100000 Handlebar Mounting Screws 0017-00101-1791 (3 per side) Bullhorn Cover Screws 0017-00101-1854 Outside Deadshaft Cover Screws...

  • Page 8: Rocker Arms And Pedal Levers

    Rocker Arms (2) Hardened Spacers (2) Oilite Washers (2) Retaining Rings (2) Loctite 620 Alcohol pad LF Bug Medallion Assy. AK58-00245-0000 Rocker Arms AK62-00002-0070 Shaft Collar w/Screws 0K61-01259-0000 Right Pedal Lever Assembly AK62-00236-0000 Left Pedal Lever Assembly AK62-00235-0000 93X-0XXX-01 S/N XTB100000...

  • Page 9: Crank Cover And Lower Caps

    CROSS TRAINER 93X Crank Cover and Lower Caps Front frame Cap 0K62-01004-0000 Mounting Screws (Located on front sides of Ladder Frame Cover) 2- 0017-00101-1795 Stabilizer Caps 4 - 0K62-01003-0000 93X-0XXX-01 S/N XTB100000 Crank Cover 0K61-03100-0001 2 - Mounting screws 0017-00101-1837...

  • Page 10: Lower Frame Shrouds And Hardware

    0017-00101-1796 Ladder Frame Cover w/decal AK62-00106-0000 4 - Mounting screws 0017-00101-1795 Shroud Panel 0K62-01002-0003 Mounting Screws (2 per side) 0017-00101-1795 93X-0XXX-01 S/N XTB100001 Rear Shroud Assembly AK62-00223-0000 Mounting screws (2 per side) 0017-00101-1796 Wheel/Bracket Assy. AK62-00102-0000 Mounting Screws ( 3 per assy.)

  • Page 11: Pedal Lever Assembly Components

    0K47-01104-0000 Anti-Lift Roller 0K62-01191-0000 Note: If replacing the Tie Rod Assembly or Crank Extension for the first time, order kit GK62-00002-0015. Both sides must be replaced simultaneously in this situation. 93X-0XXX-01 S/N XTB100000 Washer 0017-00104-0479 0017-00103-0333 Crank Extension Mounting Bolt...

  • Page 12: Drive Module Components And Main Cable

    0K61-02302-0001 Crossover Shaft and Bearings Order Kit GK62-00002-0002 Resistor with harness assembly AK62-00171-0000 Battery 0017-00003-0685 Flexonic Belt J10 0K62-01135-0000 93X-0XXX-01 S/N XTB100000 Power Control Board B084-92218-D000 Reed Switch 118E-00001-0140 Alternator Flywheel Assembly AK61-00250-0002 Main Cable Connects to Power Control Board...

  • Page 13: Drive Module Hardware

    0017-00103-0332 Crankarm nut Retaining Ring 0017-00103-0334 0017-00100-0107 Crankarm mounting bolt 0017-00101-1849 UNLABELED PARTS PART NO. 0017-00003-0685 AK62-00106-0000 M051-00K62-A111 93X-0XXX-01 S/N XTB100000 Plastic Grommet (4) 0017-00042-0754 PCB Grommet (4) 0017-00042-0821 PCB Mounting screws 0017-00101-1838 Magnet mounting screw 0017-00101-1835 Crankshaft plate mounting screws...

  • Page 14: Cables

    CROSS TRAINER 93X Cables Power Control Cable AK62-00092-0000 Power Control Board B084-92218-D000 Console PCB A084-92220-A008 93X-0XXX-01 S/N XTB100000 Main Cable AK62-00093-0000...
