Installer: leave this guide with homeowner.
Register your product online at www.broan.ca/register.
Easy installation in both
new construction and retrofit
© 2014 Broan-NuTone LLC
„
RB80C
RB110C
ULTRA Pro
TM
| Ventilation Fan
with ULTRAQuick
TM
INSTALLATION GUIDE
