Wells G13 Installation Use & Care Parts Lists Wiring Diagrams

Electric countertop griddles
Hide thumbs Also See for G13:
Table of Contents

Advertisement

Quick Links

See also: Operating Manual
Model G19
IMPORTANT: DO NOT DISCARD THIS MANUAL
This manual is considered to be part of the appliance and is to be given to the OWNER or
MANAGER of the restaurant, or to the person responsible for TRAINING OPERATORS of
this appliance. Additional manuals are available from your WELLS DEALER.
THIS MANUAL MUST BE READ AND UNDERSTOOD BY ALL PERSONS USING OR
INSTALLING THIS APPLIANCE. Contact your WELLS DEALER if you have any
questions concerning installation, operation or maintenance of this equipment.
p/n 2M-
Rev. G
303339
WELLS BLOOMFIELD, LLC
10 Sunnen Dr., St. Louis, MO 63143
telephone: 314-678-6314
fax: 314-781-2714
www.wellsbloomfield.com
OWNERS MANUAL
ELECTRIC
COUNTERTOP
GRIDDLES
MODELS
G13, G19,
G23, G24,
G60
Includes
INSTALLATION
USE & CARE
PARTS LISTS

WIRING DIAGRAMS

M101
101
0409
13

Advertisement

Table of Contents
loading

Related Manuals for Wells G13

Summary of Contents for Wells G13

  • Page 1: Wiring Diagrams

    Additional manuals are available from your WELLS DEALER. THIS MANUAL MUST BE READ AND UNDERSTOOD BY ALL PERSONS USING OR INSTALLING THIS APPLIANCE. Contact your WELLS DEALER if you have any questions concerning installation, operation or maintenance of this equipment.

  • Page 2: Warranty

    Seller’s obligation under this warranty is limited to the warranted against defects in materials and workmanship repair of defects without charge by a Wells Bloomfield for a period of one year from the date of original installation factory authorized service agency or one of its sub-service or 18 months from the date of shipment from our factory, agencies.

  • Page 3: Table Of Contents

    PARTS & SERVICE CUSTOMER SERVICE DATA INTRODUCTION Thank You for purchasing this Wells Bloomfield appliance. Proper installation, professional operation and consistent maintenance of this appliance will ensure that it gives you the very best performance and a long, economical service life.

  • Page 4: Features & Operating Controls

    IL2108 Fig. 1 Countertop Griddle Features & Operating Controls G19 Shown - G13, G23, G24 and G60 are Similar Power is applied to the heating elements according to the control knob position and the actual temperature sensed at the thermobulb.

  • Page 5: Precautions & General Information

    PRECAUTIONS AND GENERAL INFORMATION DANGER: BURN HAZARD Contact with cooking surface cause severe burns. Always wear protective clothing and avoid contact with griddle surface. WARNING: ELECTRIC SHOCk HAZARD All servicing requiring access to non-insulated components must be performed by qualified service personnel. DO NOT open any access panel that requires the use of tools.

  • Page 6: Agency Listing Information

    AGENCY LISTING INFORMATION This appliance conforms to NSF Standard 4 for sanitation only if installed in accordance with the supplied Installation Instructions and STD 4 maintained according to the instructions in this manual. This appliance is Listed under UL File E6070 for 120V, 208V and E6070 240V.
  • Page 7 INSTALLATION (continued) WARNING: ELECTRIC SHOCk HAZARD All servicing requiring access to non-insulated electrical components must be performed by a factory authorized technician. DO NOT open any access panel which requires the use of tools. Failure to follow this warning can result in severe electrical shock. CAUTION: ELECTRICAL INSTALLATION RISk OF...

  • Page 8: Operation

    CAUTION: SEASONING STANDARD AND GROOVED GRIDDLES HOT SURFACE As manufactured, the steel surface of your Wells griddle has Exposed surfaces can be microscopic pores. It is important to fill these pores with oil in order very hot and may cause to provide a hard, non-stick cooking surface.
  • Page 9 OPERATION (continued) RECOMMENDED GRILLING TIMES AND TEMPERATURES NOTE: The times and temperatures PRODUCT TEMP ºF TIME in this chart are suggestions only. Sausage, link and patty 350º 3 minutes Your own experience with your own menu items will be Bacon 350º...

  • Page 10: Cleaning Instructions Standard And Grooved Griddles

    CLEANING INSTRUCTIONS - STANDARD AND GROOVED GRIDDLES Set temperature control to 220ºF. Allow PREPARATION CAUTION: griddle temperature to drop to 220ºF before BURN HAZARD proceeding. Daily Griddle will be hot during FREQUENCY portions of this cleaning Griddle Brick or Pumice Stone, Fiber Brush procedure.

  • Page 11: Chrome-Plated Griddles

    CLEANING INSTRUCTIONS - CHROME PLATED GRIDDLES Set temperature control to 220ºF. Allow PREPARATION CAUTION: griddle temperature to drop to 220ºF before BURN HAZARD proceeding. Daily Griddle will be hot during FREQUENCY portions of this cleaning 4” Razor-Style Scraper, Soft Bristle Brush procedure.

  • Page 12: Troubleshooting Suggestions

    Empty grease drawer. Install properly Griddle drips grease Contact Wells Authorized Service Damaged internal component Agency for repairs NOTE: There are no user serviceable components in the griddle. In all cases of damage or malfunction, contact your Authorized Wells Service Agency for repairs.

  • Page 13: Exploded View & Parts List

    EXPLODED VIEW & PARTS LIST FIELD CONVERSION FROM 3-PHASE TO SINGLE-PHASE Griddles are shipped from the factory wired for 3-phase power, 208 volt and 240 volt griddles are field convertible to single-phase. *NOTE: G60 has 2 separate electrical supplies CONTROL kNOB CONFIGURATION For all models, control knob p/n 2R-30259 is marked in degrees Fahrenheit from 200ºF to 450ºF.
  • Page 14 EXPLODED VIEW & PARTS LIST COUNTERTOP ELECTRIC GRIDDLE MODEL G13, PG13 - HEATING ELEMENTS 208/240V and 480V INSULATION PAD (2’X4’) 2H-36051 COVER, GREASE DRW G7-31995 NUT, 1/4-20 HEX NI 2C-31253 CLAMP, THERMO BULB CLIP, TIE-DOWN INSULATION G7-32028 G7-33474 TUBE, THERMO BULB 18”...
  • Page 15 EXPLODED VIEW & PARTS LIST COUNTERTOP ELECTRIC GRIDDLE MODEL G13, PG13 - CABINET & ELECTRICAL 208/240V and 480V SPLASHGUARD G-13 SPLASHGUARD, LEFT G7-35781 COMPLETE ASSY 5G-20632 SPLASHGUARD, REAR G7-34437 SPLASHGUARD, RIGHT G7-35780 GRIDDLE PLATE ASSY G13; DD-35663 PG13; DD37437 SHIELD, THERMO...
  • Page 16 EXPLODED VIEW: G19 COUNTERTOP ELECTRIC GRIDDLE MODEL G19 - HEATING ELEMENTS 208V, 240V, 380-415V and 480V GRIDDLE SHOWN INVERTED ELECTRIC GRIDDLE G19 (ref.) HEATING ELEMENTS 20060 208V 1ø 20062 240V 1ø IL1919, Rev. B...
  • Page 17 EXPLODED VIEW: G19 COUNTERTOP ELECTRIC GRIDDLE MODEL G19 - CABINET & ELECTRICAL 208V, 240V, 380-415V and 480V ELECTRIC GRIDDLE G19 IL1920, Rev C CABINET COMPONENTS...
  • Page 18 PARTS LIST: G19 208V, 240V, 380-415V and 480V G19 COUNTERTOP ELECTRIC GRIDDLE Fig No Part No Description Application 2C-31253 NUT 1/4-20 FINISHED HEX G7-31968 CLAMP ELEM CTR SMALL GRID G7-32038 CLAMP ELEM END LRG GRID G7-46169 CLAMP ELEM EU ROHS 380/415V 2N-30511UL ELEM 208V 3000W...
  • Page 19 EXPLODED VIEW & PARTS LIST: G23 COUNTERTOP ELECTRIC GRIDDLE MODEL G23 - HEATING ELEMENTS 208V, 240V and 480V INSULATION PAD 2H-36051 (pk 2'x4') COVER, GREASE DRAWER G7-31995 CLIP, INSULATION G7-33474 (12 ea) CLAMP, THERMO G7-32028 (12 ea) CLAMP, PERIMETER TUBE, THERMO ELEMENT RIGHT 2A-31971 (4 ea) G7-32026...
  • Page 20 EXPLODED VIEW & PARTS LIST COUNTERTOP ELECTRIC GRIDDLE MODEL G23 - CABINET & ELECTRICAL 208V, 240V and 480V SPLASHGUARD, LEFT SPLASH GUARD ASSY, G-23 G7-35783 COMPLETE 5G-20635 SPLASHGUARD, REAR G7-34436 SPLASHGUARD, RIGHT G7-35782 GRIDDLE PLATE ASSY WS-55666, G23 G7-G23-PL-NGR, PG23 SHIELD, THERMO SLEEVING, 5/16 2A-31974 (4 ea)
  • Page 21 EXPLODED VIEW & PARTS LIST COUNTERTOP ELECTRIC GRIDDLE MODEL G24 - HEATING ELEMENTS 208V, 240V and 480V INSULATION PAD 2H-36051 (8 sf) (pk 2'x4') COVER, GREASE DRAWER G7-31995 CLIP, INSULATION NUT, 1/4-20 HEX G7-33474 (16 ea) 31253 (64 ea) (pk100) CLAMP, THERMO BULB GRIDDLE G7-32028 (12 ea) TUBE, THERMO 24"...
  • Page 22 EXPLODED VIEW & PARTS LIST COUNTERTOP ELECTRIC GRIDDLE MODEL G24 - CABINET & ELECTRICAL 208V, 240V and 480V SPLASH GUARD ASSY, G-24 SPLASHGUARD, LEFT G7-35783 COMPLETE 5G-20636 SPLASHGUARD, REAR G7-34439 SPLASHGUARD, RIGHT G7-35782 GRIDDLE PLATE ASSY (non-crome) DD-35667 FULL GRV PLATE ASSY G7-G24-NPL-FGR LEFT 18”...
  • Page 23 EXPLODED VIEW & PARTS LIST COUNTERTOP ELECTRIC GRIDDLE MODEL G60 - HEATING ELEMENTS 208V, 240V and 480V COVER, GREASE DRAWER (2 ea) G7-31995 INSULATION PAD 2H-36051 (12 sf) (pk 2'x4') CLIP, INSULATION G7-33474 (24 ea) CLAMP, THERMO G7-32028 (24 ea) CLAMP, PERIMETER TUBE, THERMO ELEMENT RIGHT...
  • Page 24 EXPLODED VIEW & PARTS LIST COUNTERTOP ELECTRIC GRIDDLE MODEL G60 - CABINET & ELECTRICAL 208V, 240V and 480V SPLASHGUARD, LEFT G7-35783 GRIDDLE PLATE ASSY SMOOTH; WS-55668 FULL GROOVE; G7-G60-NPL-FGR SPLASHGUARD ASSY COMPLETE 5G-20637 SLEEVING, 5/16 1O-32040 (8ft) THERMO, CONTROL 2T-30257 (8ea) SHIELD, THERMO 2A-31974 (8 ea) TRIM RING...

  • Page 25: Wiring Diagram

    WIRING DIAGRAM...
  • Page 26 WIRING DIAGRAM...
  • Page 27 WIRING DIAGRAM...
  • Page 28 WIRING DIAGRAM...
  • Page 29 WIRING DIAGRAM...
  • Page 30 NOTES...

  • Page 31: Parts & Service

    For factory authorized SPLASHGUARD, FITS G-13 DD-20632 service, or to order factory SPlASHGUARD, FITS G-19 5G-20634 authorized replacement parts, contact your Wells authorized SPlASHGUARD, FITS G-23 WS-20635 service agency, or call: SPLASHGUARD, FITS G-24 WS-20636 SPLASHGUARD, FITS G-60 WS-20637 Wells Bloomfield, LLC 10 Sunnen Dr.
  • Page 32 WELLS BLOOMFIELD, LLC 10 Sunnen Dr., St. Louis, MO 63143 telephone: 314-678-6314 fax: 314-781-2714 www.wellsbloomfield.com...
