Wells WG2424G Parts List
Countertop gas griddles
Hide thumbs
Also See for WG2424G:
- Owner's manual (45 pages) ,
- Operation manual (19 pages) ,
- Owner's manual (47 pages)
Table of Contents
Advertisement
Quick Links
Download this manual
See also:
Operating Manual
Description
Parts List ............................................................ 2
General Information .............................................. 3
Models:
WG2424G .................................................... 4
WG2436G .................................................... 6
WG3036G .................................................... 8
WG3048G .................................................... 10
PL121
p/n
Rev. B
2 ERIK CIRCLE, P. O. Box 280 Verdi, NV 89439
PARTS LIST
COUNTERTOP GAS GRIDDLES
MODELS:
WG2424G, WG2436G
WG3036G, WG3048G
CONTENTS
PRINTED IN UNITED STATES OF AMERICA
WELLS BLOOMFIELD, LLC
telephone: 775-689-5703
fax: 775-689-5976
www.wellsbloomfield.com
PL121
121
page
08
0310 cps
Advertisement
Table of Contents
Related Manuals for Wells WG2424G
Summary of Contents for Wells WG2424G
-
Page 1: Parts List
MODELS: WG2424G, WG2436G WG3036G, WG3048G CONTENTS Description page Parts List ……………………………….………………….. 2 General Information ……………...…………….………… 3 Models: WG2424G ……………………………………………. 4 WG2436G ……………………………………………. 6 WG3036G ……………………………………………. 8 WG3048G ……………………………………………. 10 PRINTED IN UNITED STATES OF AMERICA PL121 Rev. B 0310 cps... - Page 2 55485 NUT 1/4-20 HEX SS 65302 BURNER, WG3036G, WG3048G 59039 INSULATION, THERMOBULB 59245 PLUG, HEX 1/8 NPT BRASS 65303 BURNER, WG2424G, WG2436G 59331 GREASE CHUTE 60680 NUT, 10-32 HEX KEPS SS (pk10) 65307 GAS VALVE 59173 GREASE DRAWER ASSY COMPLETE...
-
Page 3: Gas Valve
WIRING Note: each gas system is wired individually. This diagram depicts a single system comprised of a single gas valve, thermopile & thermostat. THERMOPILE GAS VALVE THERMOSTAT TH/TP CONTROL KNOB CONFIGURATION For all models, control knob p/n 62321 is marked in degrees Fahrenheit from 200ºF to 450ºF. When the thermostat is OFF, the flat of the control shaft is positioned on the bottom. -
Page 4: Models Wg2424G
COUNTERTOP GAS GRIDDLE MODEL WG2424G GAS & BURNER SYSTEMS NATURAL GAS & PROPANE (LP) 59007 (NAT) 59284 (LP) 65318 65314 60680 (pk 10) 65303 2 places 68817 59245 2 places 65315 65313 2 places 51718 (pk 10) 65352 (LP) orifice only... - Page 5 COUNTERTOP GAS GRIDDLE MODEL WG2424G CABINET NATURAL GAS & PROPANE (LP) 68527A 59039 2 places 59331 65951 2 places 55485 (pk 100) 55485 65272 (pk 100) 65278 53453 2 places 59173 53935 (pk 100) 20563 4 places 53948 51973 65271...
-
Page 6: Wg2436G
COUNTERTOP GAS GRIDDLE MODEL WG2436G GAS & BURNER SYSTEMS NATURAL GAS & PROPANE (LP) 59007 (NAT) 59284 (LP) 65318 65314 60680 (pk10) 65303 3 places 59245 65361 3 places 3 places 65313 65315 65317 51718 (pk 10) 65408 (NAT) 65316 59335 (pk 2) (LP) 65321 3 places... - Page 7 COUNTERTOP GAS GRIDDLE MODEL WG2436G CABINET NATURAL GAS & PROPANE (LP) 68258 ASSEMBLY 59039 3 places 65951 3 places 59331 55485 (pk100) 55485 (pk100) 65292 65278 53453 2 places 59173 53935 (pk100) 53948 51973 20563 4 places 60083 65297...
-
Page 8: Wg3036G
COUNTERTOP GAS GRIDDLE MODEL WG3036G GAS & BURNER SYSTEMS NATURAL GAS & PROPANE (LP) 59007 (NAT) 59284 (LP) 65318 60680 (pk10) 65302 65314 3 places 65361 59245 3 places 3 places 65313 65317 65315 51718 (pk10) 65316 65408 (NAT) 59335 (pk 2) (LP) 3 places 65321 3 places... - Page 9 COUNTERTOP GAS GRIDDLE MODEL WG3036G CABINET NATURAL GAS & PROPANE (LP) 59039 3 places 65952 59331 3 places 55485 (pk100) 55485 (pk100) 65292 65278 53453 2 places 59173 53935 (pk100) 53948 51973 65297 60083...
-
Page 10: Wg3048G
COUNTERTOP GAS GRIDDLE MODEL WG3048G GAS & BURNER SYSTEMS NATURAL GAS & PROPANE (LP) 59007 (NAT) 59284 (LP) 65318 65314 65302 4 places 65315 60680 (pk 10) 65317 65361 4 places 65316 65319 51718 59245 (pk10) 65313 4 places 65352 (LP) orifice only 4 places 65457... - Page 11 COUNTERTOP GAS GRIDDLE MODEL WG3048G CABINET NATURAL GAS & PROPANE (LP) 59039 4 places 55952 4 places 59331 55485 (pk100) 55485 (pk100) 65375 65278 53453 2 places 59173 53948 53935 (pk100) 51973 65373 60083...
-
Page 12: Customer Satisfaction
Commercial Food Equipment Service Association Wells Bloomfield proudly supports CFESA Commercial Food Equipment Service Association SERVICE TRAINING - QUALITY SERVICE SERVICE TRAINING - QUALITY SERVICE Genuine Parts Protect - YOU - All - Ways CUSTOMER SATISFACTION CUSTOMER SATISFACTION WELLS BLOOMFIELD, LLC 2 ERIK CIRCLE, P.
