Troubleshooting - Accessory Power ReVIVE Refresh Instruction Manual

Battery Charging (cont'd)
Battery Status LCD
CHG
This symbol indicates that the batteries are properly receiving power from the Refresh Charger
This symbol indicates that there is an issue with one or more of the inserted batteries. Please
ERROR
re-insert batteries one by one to ensure there is no problem. If ERROR continues to appear then
your battery is either short-circuited, non-rechargeable or defective.

Troubleshooting

Is the green light on?
No
Yes
Yes
No
CHG
ERROR
Do you see a battery?
Symbol? ERROR or CHG?
No
CHG
What does this mean?
ReVIVE Refesh Charger is
not connected to power,
or you have not inserted
a battery.
The battery is charging.
The battery is almost fully
charged.
The battery is full and
done charging. The power
to the battery has been
shut-off .
fig. 3
