Specifications - Infinity CLASSIA C255ES Owner's Manual

S
PECIFICATIONS
Frequency Ranges:
Recommended
Amplifier Power Range:
(2.83V 1 meter)
Sensitivity :
@
Nominal Impedance:
Crossover Frequency:
Low-Frequency Drivers:
High-Frequency Drivers:
Dimensions (H x W xD):
Weight:
Features, specifications and appearance are subject to change without notice.
C255ES
60Hz – 30kHz (–3dB)
50Hz – 40kHz ( – 6dB)
10 – 150 Watts
87dB
8 Ohms
2.3kHz; 24dB/octave
Dual 5-1/4" (133mm) CMMD ®
Dual 1" (25mm) CMMD
11-3/4" x 13-1/4" x 6-1/2"
(298mm x 337mm x 165mm)
9.1 lb (4.1kg)
Declaration of Conformity
We, Harman Consumer Group, Inc.
2, route de Tours
72500 Château du Loir
France
declare in own responsibility that the product described in this owner's
manual is in compliance with technical standards:
EN 61000-6-3:2001
EN 61000-6-1:2001
Laurent Rault
Harman Consumer Group, Inc.
Château du Loir, France 11/07
INFINITY CLASSIA C255ES 7
