USING THE VACUUM CLEANER
HEIGHT ADJUSTMENT LEVER
Height Adjustment Lever
The nozzle head can be
adjusted to four different
height settings.
RUG/FLOOR (TOOLS)SELECTOR
The RUG/FLOOR(TOOLS)selector should only be
adjusted while the vacuum cleaner is turned on
and in the upright position.
1
When cleaning a rug or carpet,first
turn the ON/OFF switch to the ON
position,and then set the RUG/
FLOOR(TOOLS)selector to the
RUG position.
2
When cleaning a bare floor or when using
one of the attachments,set the RUG/FLOOR
(TOOLS)selector to the FLOOR position.
Caution: Do not change the setting of the RUG/FLOOR(TOOLS)selector while the vacuum
cleaner is turned off.

EDGE CLEANING

This vacuum cleaner is equipped with an "edge cleaning" function for cleaning carpet edges
near baseboards and stationary furniture.
Caution:
Before using the height adj-
ustment lever, please make
sure the nozzle head is tilted
backward from the floor.
Nozzle Head
Set the height adjustment to the
appropriate carpet length.
Use the 3 (
setting.
TURN OFF BRUSH ROLL
WHEN USING TOOLS.
Rug/Floor (Tools)
SELECTOR
rd
)height
FLOOR
RUG
(TOOLS)
RUG
7
