E-line PRO4 Series User Manaul

Tribrid dvr
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Tribrid DVR User's Manaul
PRO4 & ECO4 Series
3
yr
PTZ
HD-CVI
1080p
IP NETWORK
Control
CCTV
Motion
TRIDVR
Resolution
Activated
Warranty
Recording
eLineTechnology.com
800.683.6835

Advertisement

Table of Contents
loading

Related Manuals for E-line PRO4 Series

Summary of Contents for E-line PRO4 Series

  • Page 1 Tribrid DVR User’s Manaul PRO4 & ECO4 Series HD-CVI 1080p IP NETWORK Control CCTV Motion TRIDVR Resolution Activated Warranty Recording eLineTechnology.com 800.683.6835...

  • Page 2: Table Of Contents

    Table of Contents FEATURES AND SPECIFICATIONS ............1 Overview ..........................1 Features ..........................1 Specifications ........................2 ELI-ECO4-CVI-16 ......................6 ELI-PRO4-CVI-16 Series ....................15 OVERVIEW AND CONTROLS ............... 10 Front Panel ........................10 ELI-ECO4-CVI-16 ........................12 ELI-PRO4-CVI-16 Series ....................Rear Panel ........................16 ELI-ECO4-CVI-16..................
  • Page 3 Virtual Keyboard & Front Panel..................29 2.6.1 Virtual Keyboard ......................29 2.6.2 Front Panel ........................29 INSTALLATION AND CONNECTIONS ..........30 Check Unpacked DVR ..................... 30 About Front Panel and Real Panel ................. 30 HDD Installation ....................... 30 ELI-ECO4-CVI-16 ......................ELI-PRO4-CVI-16 Series ....................
  • Page 4 OVERVIEW OF NAVIGATION AND CONTROLS ........38 Boot up and Shutdown ....................38 4.1.1 Boot up ......................... 38 4.1.2 Shutdown ........................38 4.1.3 Auto Resume after Power Failure ................38 4.1.4 Replace Button Battery ....................38 Startup Wizard ........................39 Manual Record .........................
  • Page 5 Main Menu ........................56 Operation .......................... 56 4.8.1 Search .......................... 56 4.8.2 Backup .......................... 64 4.8.3 Shut Down ........................66 Information ........................66 4.9.1 System Info ........................66 4.9.2 Event..........................70 4.9.3 Network ........................71 4.9.4 Log ..........................73 4.10 Setting ..........................
  • Page 6 WAN Login ........................157 Setup ..........................158 5.8.1 Camera ........................158 5.8.2 Network ........................165 5.8.3 Event........................... 181 5.8.4 Storage ........................189 5.8.5 Setting ........................193 Information ........................207 5.9.1 Version ........................207 5.9.2 Log ..........................207 5.9.3 Online User ........................ 208 5.10 Playback .........................
  • Page 7 Appendix B-3 Compatible Portable HDD list ................227 Appendix B-4 Compatible USB DVD List ................227 Appendix B-5 Compatible SATA DVD List ................227 Appendix B-6 Compatible SATA HDD List ................228 APPENDIX C COMPATIBLE CD/DVD BURNER LIST ......232 APPENDIX D COMPATIBLE DISPLAYER LIST ........
  • Page 8 Welcome Thank you for purchasing our HDCVI DVR! This user’s manual is designed to be a reference tool for the installation and operation of your system. Here you can find information about this series hybrid standalone DVR features and functions, as well as a detailed menu tree. Before installation and operation please read the following safeguards and warnings carefully!

  • Page 9: Important Safeguards And Warnings

    Important Safeguards and Warnings 1．Electrical safety All installation and operation here should conform to your local electrical safety codes. The product must be grounded to reduce the risk of electric shock. We assume no liability or responsibility for all the fires or electrical shock caused by improper handling or installation.

  • Page 10: Features And Specifications

    FEATURES AND SPECIFICATIONS 1.1 Overview The hybrid standalone series DVR is an excellent digital monitor product designed for security field. It adopts embedded Linux OS to maintain reliable operation. Popular H.264 compression algorithm and G.711 audio compression technology realize high quality, low bit stream. Unique frame by frame play function is suitable for detailed analysis.

  • Page 11: Specifications

    Support each channel real-time record independently, and at the same time it can support search, forward play, network monitor, record search, download and etc. Support various playback modes: slow play, fast play, backward play and frame by frame play. Support time title overlay so that you can view event accurate occurred time Support customized zoom function during the preview.
  • Page 12 ELI-ECO4-CVI-16 | ELI-ECO4-CVI-8 Specifications 8-ch Model Parameters 16-ch System Main Processor High-performance industrial embedded micro controller Embedded LINUX Video Video Encode H.264 Standard Encode 720P/960H/D1/HD1/2CIF/CIF/QCIF (for sub-stream only) Resolution Video Frame PAL:1~25f/s；NTSC：1~30f/s Rate Video Bit Rate 1536Kbps-4096Kbps， For 720P:default value is 2Mbps，max value is 4Mbps Stream Video stream/composite stream Type...

  • Page 13: Front Panel

    Model Parameters 16-ch Communication Network 1 RJ45 port, 1000Mbps Ethernet port Port Communication 1 RS232 port, 1 RS422 port, 1 RS485 port 3 USB ports (One at the front panel and two at the rear panel) Other Power AC90~264V 50+2% Hz (4/8-ch max 75W) ≤35W（exclude HDD）...
  • Page 14 ELI-PRO4-CVI-16 | ELI-PRO4-CVI-8 Series 1.3.4 8-Ch Series 16-Ch Series Parameter High-performance industrial embedded micro controller Main Processor System Embedded LINUX System Multiplex operations: Multiple-channel record, multiple-channel Resources playback and network operation simultaneously Interface User-friendly graphical user interface Input Devices USB mouse Arabic number, English character, donation and extension Chinese Input Method (optional)
  • Page 15 Support monitor tour functions such as alarm, motion detection, and Monitor Touring schedule auto control. Real-time monitor： 1080P 1920*1080 Playback： 1/16-ch: 720P 1280×720, 1080P 1920*1080, 960H 960 × 576/960 × 480, Resolution 704×576/704×480, HD1 352×576/352×480, (PAL/NTSC) 2CIF 704×288/704×240, 352×288/ 352×240, QCIF 176×144/176×120 Support...
  • Page 16 playback Storage Mode Support channel record quota setup Recording 1 to 120 minutes single record duration (Default setup is 60 minutes) Length Playback Repeat Way When hard disk is full, system can overwrite previous video file. Record Search Various search engines such as time, type and channel. Playback Mode Various fast play, slow play speeds, manual frame by frame playback and reverse play mode.
  • Page 17 HDCVI Standalone DVR User’s Manual Motion Zone setup: support 396((PAL 22×18, NTSC 22×15)) detection zones. Motion Detection Various sensitivity levels. Detection and Alarm can activate record or external alarm or screen message Alarm prompt. Video Loss Alarm can activate external alarm or screen message prompt. External Alarm Support record activation function or activate external alarm or screen message in specified period.

  • Page 18: Eli-Eco4-Cvi-16

    2 Overview and Controls This section provides information about front panel and rear panel. When you install this series DVR for the first time, please refer to this part first. 2.1 Front Panel ELI-ECO4-CVI-16/8 2.1.2 Series The front panel is shown as in Figure 2-2. Figure 2-2 Please refer to the following sheet for front panel button information.
  • Page 19 Backspace function: in numeral control or text control, press it for 1.5seconds to delete the previous character before the cursor. In motion detection setup, working with Fn and direction keys to realize setup. In text mode, click it to switch between numeral, English character(small/capitalized) and etc.
  • Page 20 ELI-PRO4-CVI-16/8 Series This series products’ front panel is shown as below. See Figure 2-2. Figure 2-2 Please refer to the following sheet for front panel button information. Name Icon Function Power button, press this button for three seconds to boot up or ...
  • Page 21 Go to previous menu, or cancel current operation. When playback, click it to restore real-time monitor mode. Confirm current operation Enter ENTER Go to default button Go to menu One-window monitor mode, click this button to display assistant function: PTZ control and image color. Backspace function: in numeral control or text control, press it for 1.5 seconds to delete the previous character before the cursor.

  • Page 22: Eli-Eco4-Cvi-16

    2.2 Rear Panel ELI-ECO4-CVI-16 - Rear Panel 2.2.2 Series This series products’ rear panel is shown as below. See Figure 2-5. The following figure is based on the 16-channel general 4-HDD 720P 1.5U series product. Figure 2-5 Please refer to the following sheet for detailed information. Icon Name Note...
  • Page 23 Icon Name Note CTRL 12V Control power output Controller 12V power output. It is to control the on-off alarm relay output. VIDEO OUT Video output port Connect video output devices such as TV. AUDIO OUT Audio output port. It is to Audio output port output the analog audio signal to the devices such as the...
  • Page 24 Icon Name Note eSATA eSATA port External SATA port. It can connect to the device of the SATA port. Please jump the HDD when there is peripheral connected HDD. USB2.0 port USB2.0 port. Connect mouse, USB storage device, USB burner and etc. Power socket Power socket When connect the Ethernet port, please use crossover cable to connect the PC and use...
  • Page 25 ELI-PRO4-CVI-16 Series The 16-channel series products’ rear panel is shown as below. See Figure 2-6. Icon Name Function Video output port Connect to output devices VIDEO OUT such as TV. Audio output port Connect to sound box and AUDIO OUT etc to output audio signal.
  • Page 26 Icon Name Note 1～16 Alarm input port 1～16  There are four groups. The first group is from port 1 to port 4, the second group is from port 5 to port 8, the third group is from 9 to 12, and the fourth group is from 13 to 16.
  • Page 27 Icon Name Function Video output port Connect to output devices VIDEO OUT such as TV. Audio output port Connect to sound box and AUDIO OUT etc to output audio signal. Bidirectional talk input Input bidirectioanl talk analog MIC IN port signal from microphone, pick Bidirectional talk output Output...

  • Page 28: Eli-Eco4-Cvi-16

    2.3 Connection Sample Figure 2-7 ELI-ECO4-CVI-16/8 2.3.2 Series Please refer to the following figure for detailed information. See Figure 2-8. The following interface is based on the 16-channel 4-HDD general 720P 1.5U series product.

  • Page 29: Eli-Pro4-Cvi-16 Series

    ELI-PRO4-CVI-16/8 Series 2.3.4 Please refer to Figure 2-10 for connection sample. The following figure is based on 32-channel premium general 2.4 Remote Control The remote control interface is shown as in Figure 2-11. Please note remote control is not our standard accessory and it is not included in the accessory bag.
  • Page 30 Figure 2-10 Serial Number Name Function Power button Click it to boot up or shut down the device. Address Click it to input device number, so that you can control it. Forward Various forward speeds normal speed playback. Slow play Multiple slow play speeds or normal playback.

  • Page 31: Mouse Control

    click this button to realize normal playback. In reverse playback click this button to pause playback. Esc. Go back to previous menu or cancel current operation (close upper interface or control) Record Start or stop record manually In record interface, working with the direction buttons to select the record channel.

  • Page 32: Front Panel

    When you have selected one menu item, left click mouse to view menu content. Implement the control operation. Modify checkbox or motion detection status. Click combo box to pop up drop down list In input box, you can select input methods. Left click the corresponding button on the panel you can input numeral/English character (small/capitalized).

  • Page 33: Virtual Keyboard & Front Panel

    Right click In real-time monitor mode, pops up shortcut menu: one-window, mouse four-window, nine-window and sixteen-window, Pan/Tilt/Zoom, color setting, search, record, alarm input, alarm output, main menu. Among which, Pan/Tilt/Zoom and color setting applies for current selected channel. If you are in multiple-window mode, system automatically switches to the corresponding channel.

  • Page 34: Installation And Connections

    3 Installation and Connections Note: All the installation and operations here should conform to your local electric safety rules. 3.1 Check Unpacked DVR When you receive the DVR from the forwarding agent, please check whether there is any visible damage. The protective materials used for the package of the DVR can protect most accidental clashes during transportation.

  • Page 35: Eli-Pro4-Cvi-16 Series

    ELI-PRO4-CVI-16 Series 3.2.4 This series DVR max supports 8 SATA HDDs. Please use HDD of 7200rpm or higher. 1. Loosen the screws of the 2. Remove the HDD upper 3. Now you can see the bottom upper cover. bracket bracket 4.

  • Page 36: Connecting Power Supply

     If there are more accessories connected in the rack, please take precaution measures in case the rack power is overload. 3.4 Connecting Power Supply Please check input voltage and device power button match or not. We recommend you use UPS to guarantee steady operation, DVR life span, and other peripheral equipments operation such as cameras.

  • Page 37: Connecting Audio Input & Output, Bidirectional Audio

    Using TV as video output device is not a reliable substitution method. You also need to reduce the working hour and control the interference from power supply and other devices. The low quality TV may result in device damage. 3.6 Connecting Audio Input & Output, Bidirectional Audio 3.6.1 Audio Input BNC port is adopted for audio input port.

  • Page 38: Alarm Input And Output Details

    c. For too long signal wires, 120Ω should be parallel connected between A, B lines on the far end to reduce reflection and guarantee the signal quality. d. “485 A, B” of DVR cannot parallel connect with “485 port” of other device. e.

  • Page 39: Alarm Input Port

    Earth cable. 485 A/B 485 communication port. They are used to control devices such as decoder. 120Ω should be parallel connected between A, B lines if there are too many PTZ decoders. T+,T-,R+,R- They are four-wire full-duplex RS485 port T+ T-: output wire R+ R-: input wire 3.7.2 Alarm Input Port Please refer to the following sheet for more information.

  • Page 40: Other Interfaces

    Maximum switch currency Insulation Between touches with same 1000VAC 1minute polarity Between touches with different 1000VAC 1minute polarity Between touch and winding 1000VAC 1minute Between touches with same Surge voltage 1500V (10×160us) polarity Length of open 3ms max time Length of close 3ms max time Longevity...

  • Page 41: Overview Of Navigation And Controls

    4 Overview of Navigation and Controls 4.1 Boot up and Shutdown 4.1.1 Boot up Before the boot up, please make sure:  The rated input voltage matches the device power on-off button. Please make sure the power wire connection is OK. Then click the power on-off button. ...

  • Page 42: Startup Wizard

    4.2 Startup Wizard After device successfully booted up, it goes to startup wizard. Click Cancel/Next button, you can see system goes to login interface. Tips Check the box Startup button here, system goes to startup wizard again when it boots up the next time.
  • Page 43 Note: For security reason, please modify password after you first login. Within 30 minutes, three times login failure will result in system alarm and five times login failure will result in account lock! Click OK button, you can go to General interface. See Figure 4-3. For detailed information, please refer to chapter 4.10.5.1.
  • Page 44 Figure 4-4 Click Next button, you can go to Schedule interface. See Figure 4-5. For detailed information, please refer to chapter 4.10.4.1.1. Figure 4-5 Click Finish button, system pops up a dialogue box. Click the OK button, the startup...

  • Page 45: Manual Record

    wizard is complete. See Figure 4-6. Figure 4-6 4.3 Manual Record 4.3.1 Live Viewing After you logged in, the system is in live viewing mode. You can see system date, time, channel name and window No. If you want to change system date and time, you can refer to general settings (Main Menu->Setting->System->General).
  • Page 46  Right now, system does not support slow playback and backward playback function.  Support digital zoom function.  Support real-time backup function. You can follow the contents listed below for the operation instruction. Preview control interface Move you mouse to the top centre of the video of current channel, you can see system pops up the preview control interface.

  • Page 47: Right-Click Menu

     Put the middle button at the centre of the zone you want to zoom in, and move the mouse, you can view an interface shown as in Figure 4-10. Figure 4-10 Right click mouse to cancel zoom and go back to the original interface. Manual record function It is to backup the video of current channel to the USB device.

  • Page 48: Window Switch

    After you go to the corresponding interface, right click mouse to go back to the upper-level. Figure 4-11 4.4.1 Window Switch System supports 1/4/8/9-window. You can select from the dropdown list. See Figure 4-12.  Window split mode: You can select window amount and then select channels. ...
  • Page 49 Here you can control PTZ direction, speed, zoom, focus, iris, preset, tour, scan, pattern aux function, light and wiper, rotation and etc. Speed is to control PTZ movement speed. The value ranges from 1 to 8.The speed 8 is faster than speed 1. You can use the remote control to click the small keyboard to set. You can click of the zoom, focus and iris to zoom in/out, definition and brightness.
  • Page 50 Figure 4-15 Please refer to the following sheet for detailed information. Please note the above interface may vary due to different protocols. The button is grey and can not be selected once the current function is null. Right click mouse or click the ESC button at the front panel to go back to the Figure 4-13.
  • Page 51 Figure 4-16 Preset Setup In Figure 4-16, click preset button and use eight direction arrows to adjust camera to the proper position. The interface is shown as in Figure 4-17. Click Set button and then input preset number. Click Set button to save current preset. Figure 4-17 Tour Setup In Figure 4-16, click tour button.
  • Page 52 Figure 4-18 Pattern Setup In Figure 4-16, click Pattern button and input pattern number. Click Begin button to start direction operation. Or you can go back to Figure 4-13 to operate zoom/focus/iris/direction operation. In Figure 4-16, click End button. Figure 4-19 Scan Setup In Figure 4-16, click Scan button.
  • Page 53 Figure 4-20 4.4.2.2 Call PTZ Function Call Preset In Figure 4-15, input preset value and then click to call a preset. Click again to stop call. Call Pattern In Figure 4-15, input pattern value and then click to call a pattern. Click again to stop call.

  • Page 54: Color

    Click , system goes to the following interface. The options here are defined by the protocol. The aux number is corresponding to the aux on-off button of the decoder. See Figure 4-21. Figure 4-21 4.4.3 Color Here you can set hue, brightness, contrast, saturation, gain, white level, color mode and etc.
  • Page 55 Please refer to the following sheet for detailed information. Item Note Period There are two periods in one day. You can set different sharpness, brightness, and contrast setup for different periods. Effective Time Check the box here to enable this function and then set period time.

  • Page 56: Search

    Item Note the video brightness if the value is high. But the video noise may become too clear. Color mode It includes several modes such as standard, color, bright, gentle. Select a color mode, the sharpness, brightness, contrast automatically switch corresponding setup.

  • Page 57: Tour

    Click , system pops up the favorites schemes. Click one item, you can view saved favorite channel split mode and channel number. See Figure 4-24. Please note, right now the favorite scheme name after the window split mode. Figure 4-24 4.5.4 Tour Click button to enable tour, the icon becomes...

  • Page 58: Remote Device

    Figure 4-25 4.5.10 Remote Device Click , system goes to an interface for you to view remote device information. Please refer to chapter 4.10.1.1. 4.5.11 Network Click , system goes to the network interface. It is to set network IP address, default gateway and etc.

  • Page 59: Main Menu

    and chapter 4.10.5.10 for detailed information. Figure 4-26 4.7 Main Menu The main menu interface is shown as below. See Figure 4-27. Figure 4-27 4.8 Operation 4.8.1 Search...
  • Page 60 Click search button in the main menu, search interface is shown as below. See Figure 4-28. Usually there are three file types:  R: Regular recording file.  A: External alarm recording file.  M: Motion detection recording file Figure 4-28 Please refer to the following sheet for more information.
  • Page 61  The blue highlighted date means there is picture or file. Otherwise, there is no picture or file. Calendar  In any play mode, click the date you want to see, you can see the corresponding record file trace in the time bar. ...
  • Page 62 In normal play mode, left click the button, the file begins backward play. Click it again to pause current play. In backward play mode, click ►/ to restore normal play. In playback mode, click it to play the next or the previous section. You can click continuously when you are watching the files from the same channel.
  • Page 63 the file.  Select the file(s) you want to backup from the file list. You can check from the list. Then click the backup button, now you can see the backup menu. System supports customized path setup. After select or create new folder, click the Start button to begin the backup operation.
  • Page 64 play when playback When the system is in full-screen playback mode, left click the mouse in the Digital screen. Drag your mouse in the screen to select a section and then left click zoom mouse to realize digital zoom. You can right click mouse to exit. Manually switch During the file playback process, you can switch to other channel via the...
  • Page 65 Select records from one day, click the list, you can go to the file list interface. You can input time at the top right corner to search records by time. See image on the left side of the Figure 4-30 For example, input time 11:00.00 and then click Search button you can view all the record files after 11:00.00 (The records includes current time.).
  • Page 66  Playback Mark During 1-window playback mode, click mark file list button in Figure 4-28, you can go to mark file list interface. Double click one mark file, you can begin playback from the mark time.  Play before mark time Here you can set to begin playback from previous N seconds of the mark time.

  • Page 67: Backup

     After you go to the mark management interface, system needs to pause current playback. System resume playback after you exit mark management interface.  If the mark file you want to playback has been removed, system begin playbacking from the first file in the list. 4.8.2 Backup DVR support CD-RW, DVD burner, USB device backup, network download and eSATA.
  • Page 68 Figure 4-34 √ before channel name. You can use Fn or cancel System only backup files with a button to delete √ after file serial number. Click Start button, system begins copy. At the same time, the backup button becomes stop button.

  • Page 69: Shut Down

    When the system completes backup, you can see a dialogue box prompting successful backup.  File format: Click the file format; you can see there are two options: DAV/ASF. The file name format usually is: Channel number+Record type+Time. In the file name, the YDM format is Y+M+D+H+M+S.
  • Page 70 Figure 4-37 4.9.1.1 HDD Information Here is to list hard disk type, total space, free space, video start time and status. See Figure 4-38.  SATA: 1-2 here means system max supports 2 HDDS. ○ means current HDD is normal. X means there is error. - means there is no HDD. If disk is damaged, system shows as “?”.
  • Page 71 Figure 4-38 Double click one HDD information; you can see the HDD SMART information. See Figure 4-39. Figure 4-39 4.9.1.2 Record Info...
  • Page 72 It is to view record start time and end time. See Figure 4-40. Figure 4-40 4.9.1.3 BPS Here is for you to view current video data stream (KB/s) and occupied hard disk storage (MB/h). See Figure 4-41.

  • Page 73: Event

    Figure 4-41 4.9.1.4 Version Here is for you to view some version information such as version number, built date, serial number and etc. See Figure 4-42. Figure 4-42 4.9.2 Event...

  • Page 74: Network

    It is to display device status and channel status. See Figure 4-43. Figure 4-43 4.9.3 Network 4.9.3.1 Online Users Here is for you to manage online users. See Figure 4-44. You can disconnect one user or block one user if you have proper system right. Max disconnection setup is 65535 seconds.
  • Page 75 4.9.3.2 Network Load Network load is shown as in Figure 4-45. Here you can view the follow statistics of the device network adapter. Here you can view information of all connected network adapters. The connection status is shown as offline if connection is disconnected. Click one network adapter, you can view the flow statistics such as send rate and receive rate at the top panel.

  • Page 76: Log

    can save the packets to the specified path. The file is named after “Network adapter name+time”. You can use software such as Wireshark to open the packets on the PC for the professional engineer to solve complicated problems. Figure 4-46 4.9.4 Log 4.9.4.1 Local Log Here is for you to view system log file.
  • Page 77  Details: Click the Details button or double click the log item, you can view the detailed information. See Figure 4-48. Here you can use rolling bar to view information, or you can use Page up/Page down to view other log information. Figure 4-47 Select an item on the list and then click the Details button or double click the log item, you can view the detailed information such as log time, log type, log user, IP address and etc.

  • Page 78: Setting

    Figure 4-48 4.10 Setting 4.10.1 Camera 4.10.1.1 Remote Device (For digital channel only) 4.10.1.1.1 Remote Device In the main menu, from Camera ->Remote, you can go to an interface shown as in Figure 4-49. Here you can add/delete remote device and view its corresponding information. ...
  • Page 79  Delete: Please select one device in the Added device list and then click remove.  Status: means connection is OK and means connection failed.  Delete；Select a device on the Added device list, click Delete button, system disconnect device first and then remove its name from the list. ...
  • Page 80 Figure 4-50 4.10.1.1.2 Channel Status Here you can view the IPC status of the corresponding channel such as motion detect, video loss, tampering, alarm and etc. See Figure 4-51.  IPC status: : Front-end does not support. : Front-end supports. There is alarm event from current front-end.
  • Page 81 It is to view channel, IP address, manufacturer, type, system version, SN, video input, audio input, and etc. See Figure 4-52. Figure 4-52 4.10.1.2 Image For analog channel, the camera interface is shown as in Figure 4-53. For digital channel, the camera interface is shown as in Figure 4-54. ...
  • Page 82 dark section may lack brightness while the bright section m ay over exposure .The recommended value ranges from 40 to 60.  Sharpness: The value here is to adjust the edge of the video. The value ranges from 0 to 100. The larger the value is, the clear the edge is and vice versa. Please note there is noise if the value here is too high.
  • Page 83 Figure 4-53 Figure 4-54 4.10.1.3 Encode...
  • Page 84 It is to set video bit stream, picture bit stream, video overlay parameter and etc. 4.10.1.3.1 Video Video setting includes the following items. See Figure 4-55.  Channel: Select the channel you want.  Type: Please select from the dropdown list. There are three options: regular/motion detect/alarm.
  • Page 85 4.10.1.3.2 Snapshot Here you can set snapshot mode, picture size, quality and frequency. See Figure 4-56.  Snapshot mode: There are two modes: regular and trigger. If you set timing mode, you need to set snapshot frequency. If you set trigger snapshot, you need to set snapshot activation operation.
  • Page 86  Copy：After you complete the setup, you can click Copy button to copy current setup to other channel(s). You can see an interface is shown as in Figure 4-58. You can see current channel number is grey. Please check the number to select the channel or you can check the box ALL.
  • Page 87 Please note for digital channel, you can only modify the channel name of the connected network camera. Figure 4-59 4.10.1.3.5 Channel Type It is to set channel type. Each channel supports analog standard definition connections/analog HD connection/network camera connection (Slight function difference may be found).

  • Page 88: Network

    Figure 4-60 4.10.2 Network 4.10.2.1 TCP/IP The single network adapter interface is shown as in Figure 4-61 and the dual network adapters interface is shown as in Figure 4-62  Network Mode : Includes multiple access, fault tolerance, and load balancing ...
  • Page 89 these two cards are both offline. Please note these two cards shall be in the same LAN.  Default Network Card: Please select eth0/eth1/bond0(optional) after enable multiple-access function  Main Network Card: Please select eth0/eth1 (optional).after enable multiple access function. Note: Some series support the above three configurations and supports functions as multiple-access, fault-tolerance and load balancing.
  • Page 90  LAN download: System can process the downloaded data first if you enable this function. The download speed is 1.5X or 2.0X of the normal speed. After completing all the setups please click save button, system goes back to the previous menu.
  • Page 91 4.10.2.2 Connection The connection setup interface is shown as in Figure 4-63.  Max connection: system support maximal 128 users. 0 means there is no connection limit.  TCP port: Default value is 37777.  UDP port: Default value is 37778. ...
  • Page 92 Figure 4-64  WIFI working status: Here you can view current connection status. Please note:  After successful connection, you can see WIFI connection icon at the top right corner of the preview interface.  When the hotspot verification type is WEP, system displays as AUTO since the device can not detect its encryption type.
  • Page 93  Network type: There are various network types for different 3G network modules. You can select according to your requirements.  APN: It is the wireless connection server. It is to set you access the wireless network via which method. ...
  • Page 94 After rebooting, DVR will connect to internet automatically. The IP in the PPPoE is the DVR dynamic value. You can access this IP to visit the unit. Figure 4-66 4.10.2.6 DDNS Setup DDNS setup interface is shown as in Figure 4-67. You need a PC of fixed IP in the internet and there is the DDNS software running in this PC.
  • Page 95 Figure 4-67 Please note NNDS type includes: CN99 DDNS, NO-IP DDNS, Quick DDNS, Dyndns DDNS and sysdns DDNS. All the DDNS can be valid at the same time, you can select as you requirement. Private DDNS function shall work with special DDNS server and special Professional Surveillance Software (PSS).
  • Page 96  Domain name：There are two modes: Default domain name and customized domain name. Except default domain name registration, you can also use customized domain name (You can input your self-defined domain name.) After successful registration, you can use domain name to login installed of the device IP. ...
  • Page 97  Default: Click it to restore default setup. In this case, the trusted sites and blocked sites are both null. Note:  If you enabled trusted sites, only the IP in the trusted sites list can access the device.  If you enabled blocked sites, the IP in the blocked sites can not access the device.
  • Page 98  Title: Please input email subject here. System support English character and Arabic number. Max 32-digit.  Receiver: Please input receiver email address here. System max supports 3 email boxes. System automatically filters same addresses if you input one receiver repeatedly.
  • Page 99 FTP service. Please install Ser-U FTP SERVER first. From “start” -> “program” -> Serv-U FTP Server -> Serv-U Administator. Now you can set user password and FTP folder. Please note you need to grant write right to FTP upload user. See Figure 4-71. Figure 4-71 You can use a PC or FTP login tool to test setup is right or not.
  • Page 100 uploads the set length and auto ignore the left section. When interval value is 0, system uploads all corresponding files. After completed channel and weekday setup, you can set two periods for one each channel. Click the Test button, you can see the corresponding dialogue box to see the FTP connection is OK or not.
  • Page 101  Default: UPNP default port setting is the HTTP, TCP and UDP of the DVR.  Add to the list: Click it to add the mapping relationship.  Delete: Click it to remove one mapping item. Double click one item; you can change the corresponding mapping information. See Figure 4-75.
  • Page 102 4.10.2.11 SNMP SNMP is an abbreviation of Simple Network Management Protocol. It provides the basic network management frame of the network management system. The SNMP widely used in many environments. It is used in many network device, software and system. You can set in the following interface.
  • Page 103 4.10.2.12 Multicast Multicast setup interface is shown as in Figure 4-77. Figure 4-77 Here you can set a multiple cast group. Please refer to the following sheet for detailed information.  IP multiple cast group address -224.0.0.0-239.255.255.255 -“D” address space ...
  • Page 104 Except the above mentioned addresses of special meaning, you can use other addresses. For example: Multiple cast IP: 235.8.8.36 Multiple cast PORT: 3666. After you logged in the Web, the Web can automatically get multiple cast address and add it to the multiple cast groups. You can enable real-time monitor function to view the view. Please note multiple cast function applies to special series only.
  • Page 105 in the mapping port number. The device ID here shall be the same with the ID you input in Figure 4-78. Click Add button to complete the setup. 4) Now you can boot up the proxy server. When you see the network status is Y, it means your registration is OK.

  • Page 106: Event

    Figure 4-80 4.10.3 Event 4.10.3.1 Detect In the main menu, from Setting->Event->Detect, you can see motion detect interface. See Figure 4-81.There is three detection types: motion detection, video loss, tampering.  The video loss has no detection region and sensitivity setup and tampering has no detection region setup.
  • Page 107  Enable: Check the box here to enable motion detect function.  Region: Click select button, the interface is shown as in Figure 4-82. Here you can set motion detection zone. There are four zones for you to set. Please select a zone first and then left drag the mouse to select a zone.
  • Page 108  Record channel: System auto activates motion detection channel(s) to record once an alarm occurs. Please make sure you have set MD record in Schedule interface(Main Menu->Setting->Schedule) and schedule record in manual record interface(Main Menu->Advanced->Manual Record)  PTZ activation: Here you can set PTZ movement when an alarm occurs. Such as go to preset, tour &pattern when there is an alarm.
  • Page 109 Figure 4-81 Figure 4-82 Figure 4-83...
  • Page 110 Figure 4-84 Figure 4-85 Motion detect here only has relationship with the sensitivity and region setup. It has no relationship with other setups. 4.10.3.1.2 Video Loss In Figure 4-81, select video loss from the type list. You can see the interface is shown as in Figure 4-86.This function allows you to be informed when video loss phenomenon occurred.
  • Page 111 Please refer to chapter 4.10.3.1.1 motion detection for detailed information. Figure 4-86 4.10.3.1.3 Tampering When someone viciously masks the lens, or the output video is in one-color due to the environments light change, the system can alert you to guarantee video continuity. Tampering interface is shown as in Figure 4-87.
  • Page 112 Figure 4-87 4.10.3.2 Alarm Before operation, please make sure you have properly connected alarm devices such as buzzer. In the main menu, from Setting->Event->Alarm, you can see alarm setup interface. For analog channel, the interface is shown as in Figure 4-88 and Figure 4-89 . For digital channel, there are four alarm types.
  • Page 113  PTZ activation: Here you can set PTZ movement when alarm occurs. Such as go to preset, tour& pattern when there is an alarm. Click “select” button, you can see an interface is shown as in Figure 4-92.  Period: Click set button, you can see an interface is shown as in Figure 4-93. There are two ways for you to set periods.
  • Page 114  Snapshot: System can snapshot corresponding channel when an alarm occurs. Please note the activation snapshot has the higher priority than schedule snapshot. If you have enabled these two types at the same time, system can activate the activation snapshot when alarm occurs, and otherwise system just operates the schedule snapshot.
  • Page 115 Figure 4-89 . Figure 4-90...
  • Page 116 Figure 4-91 Figure 4-92...
  • Page 117 Figure 4-93 Figure 4-94 4.10.3.3 Abnormality There are two types: HDD/Network.  HDD: HDD error, no disk, no space. See Figure 4-95 and Figure 4-96.  Network: Disconnection, IP conflict, MAC conflict. See Figure 4-97.  Alarm output: Please select alarm activation output port (multiple choices). ...
  • Page 118  Latch: Here you can set corresponding delaying time. The value ranges from 1s-300s. System automatically delays specified seconds in turning off alarm and activated output after external alarm cancelled.  Show message: system can pop up the message in the local screen to alert you when alarm occurs.
  • Page 119 Figure 4-96 Figure 4-97...

  • Page 120: Storage

    4.10.3.4 Alarm Output Here is for you to set proper alarm output such as schedule, manual. Please highlight icon to select the corresponding alarm output. After all the setups please click OK button, system goes back to the previous menu. See Figure 4-98.
  • Page 121  : Click it to delete a record type from one period.  Record Type: Please check the box to select corresponding record type. There are four types: Regular/MD (motion detect)/Alarm/MD&Alarm.  Week day: There are eight options: ranges from Saturday to Sunday and all. ...
  • Page 122 Figure 4-101 Please highlight icon to select the corresponding function. After completing all the setups please click save button, system goes back to the previous menu. There are color bars for your reference. Green color stands for regular recording, yellow color stands for motion detection and red color stands for alarm recording. The white means the MD and alarm record is valid.
  • Page 123 Figure 4-103 4.10.4.1.1.1 Quick Setup Copy function allows you to copy one channel setup to another. After setting in channel 1, click Copy button, you can go to interface Figure 4-104. You can see current channel name is grey such as channel 1. Now you can select the channel you wan to paste such as channel 5/6/7.
  • Page 124 record video. Note About redundancy setup:  If current channel is not recording, current setup gets activated when the channel begin recording the next time.  If current channel is recording now, current setup will get activated right away, the current file will be packet and form a file, then system begins recording as you have just set.
  • Page 125 Figure 4-106 Figure 4-107 4.10.4.1.2.2 Trigger Snapshot...
  • Page 126 Please follow the steps listed below to enable the activation snapshot function. After you enabled this function, system can snapshot when the corresponding alarm occurred.  In main menu, from Setting->Camera->Encode->Snapshot interface, here you can input snapshot mode as trigger, size, quality and frequency. See Figure 4-108. ...
  • Page 127 Figure 4-109 Figure 4-110 4.10.4.1.2.3 Priority Please note the activation snapshot has the higher priority than schedule snapshot. If...
  • Page 128 you have enabled these two types at the same time, system can activate the activation snapshot when alarm occurs, and otherwise system just operates the schedule snapshot. 4.10.4.1.2.4 Image FTP In the main menu, from Setting->Network->FTP, you can set FTP server information. Please enable FTP function and then click save button.
  • Page 129 Figure 4-112 4.10.4.3 Record 4.10.4.3.1 Record Control Note: You need to have proper rights to implement the following operations. Please make sure the HDD has been properly installed. There are three ways for you to go to manual record menu. ...
  • Page 130 Figure 4-113 4.10.4.3.2 Snapshot Operation Check the corresponding box to enable/disable schedule snapshot function. See Figure 4-114. Figure 4-114 Tips You can check All button after the corresponding status to enable/disable all-channel...
  • Page 131 snapshot function. 4.10.4.4 HDD Detect The HDD detect function is to detect HDD current status so that you can clearly understand the HDD performance and replace the malfunction HDD. There are two detect types:  Quick detect is to detect via the universal system files. System can quickly complete the HDD scan.
  • Page 132 Figure 4-116 4.10.4.4.2 Detect Report After the detect operation, you can go to the detect report to view corresponding information. The detect report interface is shown as below. See Figure 4-117. Figure 4-117...
  • Page 133 Click the item you can see the detailed information such as detect result. See Figure 4-118. Figure 4-118 4.10.5 System 4.10.5.1 General 4.10.5.1.1 Device General setting includes the following items. See Figure 4-119.  Device ID: Please input a corresponding device name here. ...
  • Page 134  Auto logout: Here is for you to set auto logout interval once login user remains inactive for a specified time. Value ranges from 0 to 60 minutes.  IPC Time Sync: You can input an interval here to synchronize the DVR time and IPC time.
  • Page 135 Figure 4-120 4.10.5.1.3 Holiday Holiday setup interface is shown as in Figure 4-121. Click Add new holiday button, you can input new holiday information. See Figure 4-122. Here you can set holiday name, repeat mode and start/end time. Note  When you enable Holiday settings and schedule setup at the same time, holiday setting has the priority.
  • Page 136 Figure 4-121 Figure 4-122 4.10.5.2 Display 4.10.5.2.1 Display Display setup interface is shown as below. See Figure 4-123.
  • Page 137  Transparency: Here is for you to adjust transparency. The value ranges from 128 to 255.  Channel name: Here is for you to modify channel name. System max support 25-digit (The value may vary due to different series). Please note all your modification here only applies to DVR local end.
  • Page 138 Figure 4-124 4.10.5.2.3 Tour Here you can activate tour function. Click Setup button, you can see an interface shown as in Figure 4-125  Enable tour: Highlight box here to enable this function.  Interval: System supports 1/8/-window tour. Input proper interval value here. The value ranges from 5-120 seconds.
  • Page 139  On the navigation bar, click to enable/disable tour function. Figure 4-125 4.10.5.2.4 Zero-channel Encoding Click zero-channel encoding button, you can go to the following interface. See Figure 4-127. Here you can enable and set zero-channel encoding function so that you can view several video sources at one channel.
  • Page 140 Figure 4-126 4.10.5.2.5 Favorites Click Favorites button you can go to the following interface. See Figure 4-127. It is for you to set and save favorites preview setup. You can select different window display modes and then select corresponding channel(s). Please note for one mode, one channel can only be selected once.
  • Page 141  Default: it is to restore factory default setup. Figure 4-127 4.10.5.3 RS232 RS232 interface is shown as below. There are five items. See Figure 4-128.  Function: There are various devices for you to select. Console is for you to use the COM or mini-end software to upgrade or debug the program.
  • Page 142 Figure 4-128 4.10.5.4 PTZ The pan/tilt/zoom setup includes the following items. Please select channel first. See Figure 4-129.  PTZ type: There are two options: local/remote. Please select remote if you are connecting to the network PTZ.  Control mode: You can select control mode from the dropdown list. There are two options: Serial/HDCVI.
  • Page 143 Figure 4-129 For digital channel, the interface is shown as below. See Figure 4-130. Figure 4-130 4.10.5.5 ATM/POS...
  • Page 144 The ATM/POS function is for financial areas. It includes Sniffer, information analysis and title overlay function. The Sniffer mode includes COM and network. 4.10.5.5.1 COM Type The COM interface is shown as below. See Figure 4-131.  Protocol: Please select from the dropdown list. ...
  • Page 145 Figure 4-132 Without the protocol For the ATM/POS without the protocol, the interface is shown as in Figure 4-133. Source IP refers to host IP address that sends out information (usually it is the device host.) Destination IP refers to other systems that receive information. Usually you do not need to set source port and target port.
  • Page 146 Figure 4-133 4.10.5.6 Account Here is for you to implement account management. See Figure 4-134 and Figure 4-135. Here you can:  Add new user  Modify user  Add group  Modify group  Modify password. For account management please note: ...
  • Page 147 rights such as monitor for this user so that you can view some channel view without login.  One user should belong to one group. User right can not exceed group right.  About reusable function: this function allows multiple users use the same account to login.
  • Page 148 Figure 4-135 4.10.5.6.1 Add/Modify Group Click add group button, the interface is shown as below. See Figure 4-136. Here you can input group name and then input some memo information if necessary. There are total 98 rights such as control panel, shut down, real-time monitor, playback, record, record file backup, PTZ, user account, system information view, alarm input/output setup, system setup, log view, clear log, upgrade system, control device and etc.
  • Page 149 Figure 4-136 4.10.5.6.2 Add/Modify User Click add user button, the interface is shown as in Figure 4-137. Please input the user name, password, select the group it belongs to from the dropdown list. Then you can check the corresponding rights for current user. For convenient user management, usually we recommend the general user right is lower than the admin account.
  • Page 150 user. If you leave this item in blank, any MAC address user can share this user account to login. Please note system needs to check the validity of MAC. Only the 12-digit 0-f format address can pass the validity verification. System only saves small character even you input capitalized one.
  • Page 151  Format: Click Format button, system pops up a dialogue box for you to confirm current operation. System begins format process after you click the OK button. Note:  System can not open config backup interface again if there is backup operation in the process.
  • Page 152 System menu color, language, time display mode, video format, IP address, user account will not maintain previous setup after default operation! Figure 4-140 4.10.5.10 Update Here is for you to view hardware features, software version, built date, release SN information and etc. You can also update system here. See Figure 4-141. ...
  • Page 153 Figure 4-141...

  • Page 154: Web Operation

    5 WEB OPERATION Slightly difference may be found in the interface due to different series. 5.1 Network Connection Before web client operation, please check the following items:  Network connection is right  DVR and PC network setup is right. Please refer to network setup(main menu->Setting->Network) ...

  • Page 155: Lan Mode

    Figure 5-2 5.3 LAN Mode For the LAN mode, after you logged in, you can see the main window. See Figure 5-3. Figure 5-3 This main window can be divided into the following sections.  ）, setup (chapter 5.8), Section 1: there are five function buttons: Live（chapter search (chapter 5.10), alarm (chapter 5.11), and logout (chapter 5.12).
  • Page 156  Section 2: There are channel number and one button: Start all. Start all button is to enable/disable all-channel real-time monitor. Click it the button becomes yellow. See Figure 5-4. Figure 5-4 Please refer to Figure 5-5 for main stream and extra stream switch information. Figure 5-5 ...

  • Page 157: Real-Time Monitor

    Figure 5-8  Section 6: From the left to the right ,you can see video quality/fluency/ full screen/1-window/4-window/6-window/8-window/9-window/13-window/16-window/20- window/25-window/36-window.. You can set video fluency and real-time feature priority.  Section 7: PTZ operation panel. Please refer to chapter 5.5 for detailed information. ...
  • Page 158 Figure 5-10  1: Digital zoom: Click this button and then left drag the mouse in the zone to zoom in. right click mouse system restores original status.  2: Local record. When you click local record button, the system begins recording and this button becomes highlighted.

  • Page 159: Image/Relay-Out

    Parameter Function You can turn on or turn off the light/wiper. Light and wiper 3D Intelligent Positioning You can click this icon to display or hide the PTZ control platform. Figure 5-11 5.6 Image/Relay-out Select one monitor channel video and then click Image button in section 8, the interface is shown as Figure 5-12.

  • Page 160: Wan Login

    Figure 5-13 5.7 WAN Login In WAN mode, after you logged in, the interface is shown as below. See Figure 5-14. Figure 5-14 Please refer to the following contents for LAN and WAN login difference. 1) In the WAN mode, system opens the main stream of the first channel to monitor by default.

  • Page 161: Setup

    Important  For multiple-channel monitor mode, system adopts extra stream to monitor by default. You can not modify manually. All channels are trying to synchronize. Please note the synchronization effect still depends on your network environments.  For bandwidth consideration, system can not support monitor and playback at the same time.
  • Page 162 Please refer to the following sheet for log parameter information. Parameter Function Click Device search button, you can view the searched device Device search information on the list. It includes device IP address, port, device name, manufacturer and type. Select a device in the list and then click Add button, system can connect the device automatically and add it to the Added device list.
  • Page 163 Figure 5-17 The digital channel is shown as in Figure 5-18. Figure 5-18 Please refer to the following sheet for detailed information. Parameter Function Channel Please select a channel from the dropdown list. Period It divides one day (24 hours) to two periods. You can set different hue, brightness, and contrast for different periods.
  • Page 164 input the value here, the bright section and the dark section of the video will be adjusted accordingly. You can use this function when the whole video is too dark or too bright. Please note the video may become hazy if the value is too high. The value ranges from 0 to 100.The recommended value ranges from 40 to 60.
  • Page 165 Figure 5-19 Please refer to the following sheet for detailed information. Parameter Function Channel Please select a channel from the dropdown list. Video enable Check the box here to enable extra stream video. This item is enabled by default. Code stream It includes main stream, motion stream and alarm stream.
  • Page 166  Bit Rate Main stream: You can set bit rate here to change video quality. The large the bit rate is , the better the quality is. Please refer to recommend bit rate for the detailed information.  Extra stream: In CBR, the bit rate here is the max value. In dynamic video, system needs to low frame rate or video quality to guarantee the value.
  • Page 167 Click it; you can copy current channel setup to other channel(s). Copy 5.8.1.3.3 Video Overlay The video overlay interface is shown as in Figure 5-21. Figure 5-21 Please refer to the following sheet for detailed information. Parameter Function Cover-area Check Preview or Monitor first. Click Set button, you can privacy mask the specified video in the preview or monitor video.

  • Page 168: Network

    Please click the Save button to save current setup. Figure 5-22 5.8.1.4 Channel Name Here you can set channel name. See Figure 5-23. Please note this function is for analog channel only. The digital channel name here is read-only. Figure 5-23 5.8.2 Network 5.8.2.1 TCP/IP The single-Ethernet port interface is shown as in Figure 5-24.
  • Page 169 Figure 5-25 Please refer to the following sheet for detailed information. Parameter Function Mode There are two modes: static mode and the DHCP mode.  The IP/submask/gateway are null when you select the DHCP mode to auto search the IP. ...
  • Page 170 Figure 5-26 Please refer to the following sheet for detailed information. Parameter Function Max connection It is the max Web connection for the same device. The value ranges from 1 to 120. The default setup is 120. TCP port The default value is 37777. You can input the actual port number if necessary.
  • Page 171 Figure 5-28 Please check the box to enable WIFI function and then click the Search SSID button. Now you can view all the wireless network information in the following list. Double click a name to connect to it. Click Refresh button, you can view latest connection status. 5.8.2.5 3G 5.8.2.5.1 CDMA/GPRS The CDMA/GPRS interface is shown as in Figure 5-29.
  • Page 172 Pulse interval It is to set time to end 3G connection after you close extra stream monitor. For example, if you input 60 here, system ends 3G connection after you close extra stream monitor 60 seconds. Important  If the pulse interval is 0, then system does not end 3G connection after you close the extra stream monitor.
  • Page 173 5.8.2.7 DDNS The DDNS interface is shown as in Figure 5-32. The DDNS is to set to connect the various servers so that you can access the system via the server. Please go to the corresponding service website to apply a domain name and then access the system via the domain.
  • Page 174 Before you use Quick DDNS, you need to enable this service and set proper server address, port value and domain name.  Server address：www.quickddns.com  Port number：80  Domain name：There are two modes: Default domain name and customized domain name. Except default domain name registration, you can also use customized domain name (You can input your self-defined domain name.) After successful registration, you can use domain name to login installed of the device IP.
  • Page 175 Figure 5-34 Please refer to the following sheet for detailed information. Parameter Function Please check the box here to enable email function. Enable Input server address and then enable this function. SMTP Server Port Default value is 25. You can modify it if necessary. Anonymity For the server supports the anonymity function.
  • Page 176 Parameter Function Please check the box here to enable this function. Health mail enable This function allows the system to send out the test email to Update period check the connection is OK or not. (interval) Please check the box to enable this function and then set the corresponding interval.
  • Page 177 Figure 5-36 5.8.2.12 SNMP The SNMP interface is shown as in Figure 5-37. The SNMP allows the communication between the network management work station software and the proxy of the managed device. It is reserved for the 3 party to develop. Figure 5-37 Please refer to the following sheet for detailed information.
  • Page 178 Parameter Function and one group of the managers. Please make sure the device and the proxy are the same. The read community will read/write/access all the objects the SNMP supported in the specified name. The default setup is write. The destination address of the Trap information from the proxy Trap address program of the device.
  • Page 179 5.8.2.15 Alarm Centre The alarm centre interface is shown as below. See Figure 5-40. This interface is reserved for you to develop. System can upload alarm signal to the alarm centre when local alarm occurs. Before you use alarm centre, please set server IP, port and etc. When an alarm occurs, system can send out data as the protocol defined, so the client-end can get the data.
  • Page 180 Figure 5-42 You can see the corresponding prompt. See Figure 5-43. Now the server certificate is successfully created. Figure 5-43 5.8.2.16.2 Download root certificate In Figure 5-41, click button, system pops up a dialogue box. See Figure 5-44. Figure 5-44 Click Open button, you can go to the following interface.
  • Page 181 Figure 5-45 Click Install certificate button, you can go to certificate wizard. See Figure 5-46. Figure 5-46 Click Next button to continue. Now you can select a location for the certificate. See Figure 5-47.
  • Page 182 Figure 5-47 Click Next button, you can see the certificate import process is complete. See Figure 5-48. Figure 5-48 Click Finish button, you can see system pops up a security warning dialogue box. See Figure 5-49.
  • Page 183 Figure 5-49 Click Yes button, system pops up the following dialogue box, you can see the certificate download is complete. See Figure 5-50. Figure 5-50 5.8.2.16.3 View and set HTTPS port From Setup->Network->Connection, you can see the following interface. See Figure 5-51. You can see HTTPS default value is 443.

  • Page 184: Event

    5.8.3 Event 5.8.3.1 Video detect 5.8.3.1.1 Motion Detect The motion detect interface is shown as in Figure 5-52. Figure 5-52 Figure 5-53...
  • Page 185 Figure 5-54 Figure 5-55 Please refer to the following sheet for detailed information. Parameter Function Enable You need to check the box to enable motion detection function. Please select a channel from the dropdown list. Period Motion detection function becomes activated in the specified periods.
  • Page 186 Parameter Function Here you can set motion detection zone. There are four zones for you to set. Please select a zone first and then left drag the mouse to select a zone. The corresponding color zone displays different detection zone. You can click Fn button to switch between the arm mode and disarm mode.
  • Page 187 Figure 5-56 5.8.3.1.3 Tampering The tampering interface is shown as in Figure 5-57. After analysis video, system can generate a tampering alarm when the detected moving signal reached the sensitivity you set here. For detailed setups, please refer to chapter 5.8.3.1.1 motion detect for detailed information.
  • Page 188 Before operation, please make sure you have properly connected alarm devices such as buzzer. The input mode includes local alarm and network alarm. 5.8.3.2.1 Local Alarm The local alarm interface is shown as in Figure 5-58. It refers to alarm from the local device.
  • Page 189 Figure 5-60 Please refer to the following sheet for detailed information. Parameter Function Enable You need to check the box to enable this function. Please select a channel from the dropdown list. Period This function becomes activated in the specified periods. There are six periods in one day.
  • Page 190 Parameter Function Send Email If you enabled this function, System can send out an email to alert you when an alarm occurs. Tour You need to check the box here to enable this function. System begins 1-wiindow or multiple-window tour display among the channel(s) you set to record when an alarm occurs.
  • Page 191 Figure 5-62 Figure 5-63 Please refer to the following sheet for detailed information. Parameter Function Event The abnormal events include: No disk, disk error, disk no space, net Type disconnection, IP conflict and MAC conflict. You can set one or more items here. Less than: You can set the minimum percentage value here (For disk not space only).

  • Page 192: Storage

    Parameter Function Latch The alarm output can delay for the specified time after an alarm stops. The value ranges from 1s to 300s. Show System can pop up a message to alarm you in the local host screen if message you enabled this function.
  • Page 193  Yellow color stands for the motion detect record/snapshot..  Red color stands for the alarm record/snapshot.  Blue color stands for MD&alarm record/snapshot. Figure 5-65 Figure 5-66 Figure 5-67...
  • Page 194 Please refer to the following sheet for detailed information. Parameter Function Channel Please select a channel from the dropdown list. Pre-record Please input pre-record time here. The value ranges from 0 to 30. Redundancy Check the box here to enable redundancy function. Please note this function is null if there is only one HDD.
  • Page 195 5.8.4.2 HDD Manage The interface is shown as in Figure 5-69. Here you can see HDD information. You can also operate the read-only, read-write, redundancy (if there are more than on HDD) and format operation. Figure 5-69 5.8.4.3 Manual Record The interface is shown as in Figure 5-70.

  • Page 196: Setting

    System enables auto record function as you set in record schedule Schedule setup (general, motion detect and alarm). It has the highest priority. Manual Enable corresponding channel to record no matter what period applied in the record setup. Stop current channel record no matter what period applied in the Stop record setup.
  • Page 197 Here is for you to select working mode when hard disk is full. There HDD full are two options: stop recording or rewrite. If current working HDD is overwritten or the current HDD is full while the next HDD is no empty, then system stops recording, If the current HDD is full and then next HDD is not empty, then system overwrites the previous files.
  • Page 198 You can set the time server address. NTP server It is to set the time server port. Port It is to set the sync periods between the device and the time server. Interval 5.8.5.1.3 Holiday Setup Holiday setup interface is shown as in Figure 5-73. Here you can click Add box to add a new holiday and then click Save button to save.
  • Page 199 Check the box here, you can view system time and channel Time number on the monitor video. title/channel title Check the box; you can optimize the margin of the preview video. Image enhance 5.8.5.2.2 TV Adjust Note This function is for some series product only. It is to set TV output region.
  • Page 200 Please refer to the following sheet for detailed information. Parameter Function Check the box here to enable tour function. Enable tour Here is for you to adjust transparency. The value ranges from 5 to Interval 120s. The default setup is 5s. Here you can set window mode and channel group.
  • Page 201 Figure 5-78 Please refer to the following sheet for detailed information. Parameter Function Select the corresponding dome protocol. Protocol Default setup is console. Select the baud rate. Baud Rate Default setup is 115200. Data Bit The value ranges from 5 to 8. Default setup is 8.
  • Page 202 Figure 5-79 Figure 5-80 Please refer to the following sheet for detailed information. Parameter Function Select speed dome connected channel. Channel There are two types: local/remote. Please select local mode if you are PTZ type connect RS485 cable to connect to the Speed dome (PTZ). Please select remote mode if you are connecting to the network PTZ camera.
  • Page 203 Parameter Function Data Bit Default setup is 8. Please set according to the speed dome dial switch setup. Default setup is 1. Please set according to the speed dome dial switch Stop bit setup. Parity Default setup is none. Please set according to the speed dome dial switch setup.
  • Page 204 Figure 5-82 Without the protocol For the ATM/POS without the protocol, the interface is shown as in Figure 5-83. Source IP refers to host IP address that sends out information (usually it is the device host.) Destination IP refers to other systems that receive information. Usually you do not need to set source port and target port.
  • Page 205 5.8.5.6 Account Note:  For the character in the following user name or the user group name, system max supports 6-digits. The space in the front or at the end of the string is null. The valid string includes: character, number, and underline. ...
  • Page 206 Figure 5-85 Modify user It is to modify the user property, belonging group, password and rights. See Figure 5-86. Modify password It is to modify the user password. You need to input the old password and then input the new password twice to confirm the new setup. Please click the OK button to save. Please note, the password ranges from 1-digit to 6-digit.
  • Page 207 Figure 5-86 5.8.5.6.2 Group The group management interface can add/remove group, modify group password and etc. The interface is shown as in Figure 5-87. Figure 5-87 Add group: It is to add group and set its corresponding rights. See Figure 5-88. Please input the group name and then check the box to select the corresponding rights.
  • Page 208 includes: shutdown/reboot device, live view, record control, PTZ control and etc. Figure 5-88 Modify group Click the modify group button, you can see an interface is shown as in Figure 5-89. Here you can modify group information such as remarks and rights. Figure 5-89...
  • Page 209 5.8.5.7 Auto maintain The auto maintain interface is shown as in Figure 5-90. Here you can select auto reboot and auto delete old files interval from the dropdown list. If you want to use the auto delete old files function, you need to set the file period. Click Manual reboot button, you can restart device manually.

  • Page 210: Information

    5.8.5.10 Upgrade The upgrade interface is shown as in Figure 5-93. Please select the upgrade file and then click the update button to begin update. Please note the file name shall be as *.bin. During the upgrade process, do not unplug the power cable, network cable, or shutdown the device.

  • Page 211: Online User

    Figure 5-95 Please refer to the following sheet for log parameter information. Parameter Function Log types include: system operation, configuration operation, data Type operation, event operation, record operation, user management, log clear. Set the start time of the requested log. Start time Set the end time of the requested log.

  • Page 212: Playback

    Figure 5-96 5.10 Playback Click Playback button, you can see an interface is shown as in Figure 5-97. Please set record type, record date, window display mode and channel name. You can click the date on the right pane to select the date. The green highlighted date is system current date and the blue highlighted date means it has record files.
  • Page 213 Figure 5-98 Select a file you want to play and then click Play button, system can begin playback. You can select to playback in full-screen. Please note for one channel, system can not playback and download at the same time. You can use the playback control bar to implement various operations such as play, pause, stop, slow play, fast play and etc.
  • Page 214 Select the file(s) you want to download and then click download button, you can see an interface shown as in Figure 5-100. The Download button becomes Stop button and there is a process bar for your reference. Please go to you default file saved path to view the files.

  • Page 215: Alarm

    Figure 5-102 Watermark Watermark interface is shown as In Figure 5-101. Please select a file and then click Verify button to see the file has been tampered with or not Figure 5-103 5.11 Alarm Click alarm function, you can see an interface is shown as Figure 5-104. Here you can set device alarm type and alarm sound setup (Please make sure you have enabled audio function of corresponding alarm events.).

  • Page 216: Log Out

    Figure 5-104 Please refer to the following sheet for detailed information. Type Parameter Function Alarm Video loss System alarms when video loss occurs. Type Motion detection System alarms when motion detection alarm occurs. Tampering System alarms when camera is viciously masking. Disk full System alarms when disk is full.

  • Page 217: Un-Install Web Control

    Figure 5-105 5.13 Un-install Web Control You can use web un-install tool “uninstall web.bat” to un-install web control. Please note, before you un-installation, please close all web pages, otherwise the un-installation might result in error.

  • Page 218: Professional Surveillance System

    6 Professional Surveillance System Besides Web, you can use our Professional Surveillance Software (PSS) to login the device. For detailed information, please refer to PSS user’s manual.
  • Page 219 7 FAQ 1. DVR can not boot up properly. There are following possibilities:  Input power is not correct.  Power connection is not correct.  Power switch button is damaged.  Program upgrade is wrong.  HDD malfunction or something wrong with HDD ribbon. ...
  • Page 220  DVR and monitor resistance is not compatible.  Video transmission is too long or degrading is too huge.  DVR color or brightness setup is not correct. 6. Can not search local records. There are following possibilities:  HDD ribbon is damaged. ...
  • Page 221  PTZ decoder setup, connection or installation is not correct.  Cable connection is not correct.  PTZ setup is not correct.  PTZ decoder and DVR protocol is not compatible.  PTZ decoder and DVR address is not compatible. ...
  • Page 222  MAC address conflict.  PC or DVR network card is not good. 16. Burn error /USB back error. There are following possibilities:  Burner and DVR are in the same data cable.  System uses too much CPU resources. Please stop record first and then begin backup.
  • Page 223  Camera quality is too low. Lens is dirty. Camera is installed against the light. Camera aperture setup is not correct.  HDD capacity is not enough.  HDD is damaged. 22. Can not playback the downloaded file. There are following possibilities: ...
  • Page 224 There are following possibilities:  Check the camera is online or not.  Check IP channel setup is right or not (such as IP address, user name, password, connection protocol, port number.).  The camera has set the whitelist (Only the specified devices can connect to the camera).
  • Page 225  Check DNS setup is right or not. Default Google DNS server is 8.8.8.8, 8.8.5.5. You can use different DNS provided by your ISP. 34. I can not use the P2P function on my cell phone or the WEB. There are following possibilities: ...
  • Page 226  Please use the brush to clean the board, socket connector and the chassis regularly.  The device shall be soundly earthed in case there is audio/video disturbance. Keep the device away from the static voltage or induced voltage.  Please unplug the power cable before you remove the audio/video signal cable, RS232 or RS485 cable.

  • Page 227: Appendix A Hdd Capacity Calculation

    Appendix A HDD Capacity Calculation Calculate total capacity needed by each DVR according to video recording (video recording type and video file storage time). Step 1: According to Formula (1) to calculate storage capacity that is the capacity of each channel needed for each hour, unit Mbyte. ...
  • Page 228 448K 196M 512K 225M 640K 281M 768K 337M 896K 393M 1024K 450M 1280K 562M 1536K 675M 1792K 787M 2048K 900M...

  • Page 229: Appendix B Compatible Backup Devices

    Appendix B Compatible backup devices Appendix B-1 Compatible USB list Manu factor Model Capacity Sandisk Cruzer Micro 512M Sandisk Cruzer Micro Sandisk Cruzer Micro Sandisk Cruzer Freedom 256M Sandisk Cruzer Freedom 512M Sandisk Cruzer Freedom Sandisk Cruzer Freedom DataTraveler Ⅱ Kingston DataTraveler Ⅱ...

  • Page 230: Appendix B-2 Compatible Sd Card List

    Kingston Data Traveler 32GB Aigo L8315 16GB Sandisk 16GB Kingston Data Traveler Locker+ 32GB Netac U228 Appendix B-2 Compatible SD Card list Brand Standard Capacity Card type Transcend SDHC6 16GB Kingston SDHC4 Kingston Kingston Sandisk SDHC2 Small Sandisk Small Appendix B-3 Compatible Portable HDD list Brand Model Capacity...

  • Page 231: Appendix B-6 Compatible Sata Hdd List

    Samsung TS-H653 Ver.F Samsung SH-224BB/CHXH SONY DRU-V200S SONY DRU-845S SONY AW-G170S Pioneer DVR-217CH Appendix B-6 Compatible SATA HDD List NOTE: Please upgrade the DVR firmware to latest version to ensure the accuracy of the table below. Here we recommend HDD of 500G to 4T capacity. Port Manufacturer Series...
  • Page 232 Seagate Seagate Pipeline HD2 ST31000322CS SATA Seagate Seagate Pipeline HD2 ST1000VM002 SATA Seagate Seagate Pipeline HD2 ST1500VM002 SATA Seagate Seagate Pipeline HD2 ST2000VM002 SATA Seagate Seagate Pipeline HD2 ST2000VM003 SATA Seagate Seagate Constellation ST3500514NS 500G SATA Seagate Seagate Constellation ST31000524NS SATA Seagate Seagate Constellation...
  • Page 233 Westem Digital Cariar SE WD2500JS 250G SATA Westem Digital Cariar SE16 WD7500KS 750G SATA Westem Digital Cariar SE16 WD5000KS 500G SATA Westem Digital Cariar SE16 WD4000KD 400G SATA Westem Digital Cariar SE16 WD3200KS 320G SATA Westem Digital Cariar SE16 WD2500KS 250G SATA Westem Digital...
  • Page 234 Hitachi HitachiCinemaStar™ HCP725050GLA380 500G SATA 5K500 Hitachi HitachiCinemaStar™ HCT721050SLA360 500G SATA 7K1000.B Hitachi HitachiCinemaStar™ HCT721075SLA360 750G SATA 7K1000.B Hitachi HitachiCinemaStar™ HCT721010SLA360 SATA 7K1000.B Maxtor DiamondMax 20 STM3320820AS 320G SATA Maxtor DiamondMax 20 STM3250820AS 250G SATA...
  • Page 235 Appendix C Compatible CD/DVD Burner List NOTE: Please upgrade the DVR firmware to latest version to ensure the accuracy of the table below. And you can use the USB cable with the model recommended to set USB burner. Manufacturer Model Port Type Type Sony...

  • Page 236: Appendix D Compatible Displayer List

    Appendix D Compatible Displayer List Please refer to the following sheet form compatible displayer list. Brand Model Dimension (Unit: inch) BENQ（LCD） ET-0007-TA 19-inch (wide screen) DELL（LCD） E178FPc 17-inch BENQ（LCD） Q7T4 17-inch BENQ（LCD） Q7T3 17-inch HFNOVO（LCD） LXB-L17C 17-inch 22 寸(wide screen) SANGSUNG（LCD）...

  • Page 237: Appendix E Compatible Switcher

    Appendix E Compatible Switcher Brand Model network working mode D-LinK DES-1016D 10/100M self-adaptive D-LinK DES-1008D 10/100M self-adaptive Five network modes 1. AUTO 2. HALF-10M Ruijie RG-S1926S 3. FULL-10M 4 .HALF-100M 5. FULL-100M H3C-S1024 10/100M self-adaptive TP-LINK TL-SF1016 10/100M self-adaptive TP-LINK TL-SF1008+ 10/100M self-adaptive...

  • Page 238: Appendix F Compatible Wireless Mouse List

    Appendix F Compatible Wireless Mouse List Please refer to the following sheet for compatible SD card brand. Brand Model Rapoo 3500 Logitech M215 Shuangfeiyan Tianyao G7-630...

  • Page 239: Appendix G Earthing

    Appendix G Earthing 1. What is the surge? Surge is a short current or voltage change during a very short time. In the circuit, it lasts for microsecond. In a 220V circuit, the 5KV or 10KV voltage change during a very short time (about microseconds) can be called a surge.
  • Page 240  Signal lightning arrester: This device is mainly used in the PC network, communication system. The connection type is serial connection. Once you connected the signal lightning arrestor with the signal port, it can cut the channel of the thunderstorm to the device, and on the other hand, it can discharge the current to the ground to guarantee the device proper work.
  • Page 241 conductance of the ground conductor. In the high-frequency circuit, you need to use the multiple-point ground mode and each cable needs to connect to the ground. The length shall be less than the 1/20 of the signal wavelength. Mixed ground: The mix ground consists of the feature of the one-point ground and multiple-point ground.
  • Page 242  The thunder proof ground shall adopt the special ground cable from the monitor control room to the ground object. The ground cable adopts copper insulation cable or wire and its ground section shall be more than 20mm2.  The ground cable of the monitor system can not short circuit or mixed connected with the strong alternative current cable.
  • Page 243 For L (live cable) Turn the digital multimeter to 750V AC, use your one hand to hold the metal end, and then the other hand insert the pen to the L port of the socket. See the following figure. If the multimeter shows 120, then you can see current live cable connection is standard.

  • Page 245: Appendix H Toxic Or Hazardous Materials Or Elements

    Appendix H Toxic or Hazardous Materials or Elements Toxic or Hazardous Materials or Elements Component Name Cr VI PBDE Sheet ○ ○ ○ ○ ○ ○ Metal(Case) Plastic Parts ○ ○ ○ ○ ○ ○ （Panel） ○ ○ ○ ○ ○...
