INSTRUCTION MANUAL
!
PLEASE READ CAREFULLY BEFORE USE
Additional Information on this product and answers to
frequently asked questions can be found at www.primos.com
© 2015 Primos
Hunting
®
601-879-9323
PHOTO MODES
Video Mode
Records Audio
HD VIDEO
HD TIME LAPSE
All Day Time Lapse
+ Photos
Doc Number
PROOF_001
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Primos Proof Camera Series 63054
Summary of Contents for Primos Proof Camera Series 63054
- Page 1 HD VIDEO HD TIME LAPSE PLEASE READ CAREFULLY BEFORE USE All Day Time Lapse + Photos Additional Information on this product and answers to frequently asked questions can be found at www.primos.com © 2015 Primos Hunting 601-879-9323 ® Doc Number...
- Page 2 - Do not lay product on moist ground or submerge in water (this unit is designed for upright outdoor use). - DO NOT OPEN CASE HOUSING. UNINSULATED, ‘DANGEROUS VOLTAGE’ WITHIN PRODUCTS ENCLOSURE. DO NOT REMOVE HOUSING COVER. THERE ARE NO USER - SERVICEABLE PARTS INSIDE, REFER SERVICING TO PRIMOS CUSTOMER SERVICE. ®...
- Page 3 Failure to follow may result in leaking or exploding batteries, damage to product, fire or personal injury. Do not handle damaged or leaking batteries. QUESTIONS?? Feel free to contact the Primos Customer Service Team with any comments, questions, problems or return requests. ®...
- Page 4 IT’S SIMPLE TO USE THIS CAMERA Install batteries. Install SD memory card. Slide to setup mode. Then simply set Slide switches to desired setting. the date & time. Then slide to ON.
-
Page 5: Table Of Contents
TABLE OF CONTENTS BEFORE OPERATION ............1 Needed To Operate . -
Page 6: Before Operation
BEFORE OPERATION INCLUDED PARTS 1. Proof Cam – (1) ® 2. 72” Tree Mounting Strap – (1) 3. Instruction Manual – (1) NEEDED TO OPERATE 1. Eight (8) “AA” Alkaline or Lithium 2. One or more SD Memory Cards (Camera will support up to 32GB SD or SDHC Cards) NOTE: If no SD Card is installed ‘Add SD’... -
Page 7: Select Sd Card Size
SELECT SD CARD SIZE These charts allow you to see the approximate capacity of 2GB, 4GB, 8GB, 16GB & 32GB SD Memory Cards. This will help you decide which size SD Cards might be appropriate based on your desired camera mode. Proof Cam SD Card Storage Capacity Mode... -
Page 8: Camera Operation
CAMERA OPERATION SETTING DATE & TIME A 3-way power switch is used to select the main operating modes: OFF, SETUP, and ON View Date or Time Slide switch to setup and with camera LCD screen ON, push ▲ or ▼arrows to display date or time setting in the camera. -
Page 9: Switch Settings [Mode, Settings & Delay]
SWITCH SETTINGS [MODE, SETTINGS & DELAY] 1. MODE SWITCH Decide Which Capture Mode To Use Photo Captures high (HI) or standard (LO) resolution photos with motion detection. Your camera’s photo capture resolution can be found in the Camera Specifications chart in the back of this manual. - Page 10 SWITCH SETTINGS [MODE, SETTINGS & DELAY] CONT. 2. SETTING SWITCH The sliding switches are color coded to match the SETTINGS with the corresponding MODE setting. Photo Burst Number of pictures taken each time motion is detected (triggering event) Video Length The length (seconds) of each video clip recorded each time motion is detected (triggering event) Time Lapse Interval The pre-set amount of time (minutes) you desire between each time lapse photo.
- Page 11 SWITCH SETTINGS [MODE, SETTINGS & DELAY] CONT. 3. DELAY SWITCH The pre-set amount of time you desire between photo & video recordings. The delay switch setting also applies to delay between photo recordings in Time Lapse + Photo mode. CAMERA IS READY TO USE! AFTER SETTING DATE &...
-
Page 12: Camera Features & Options
CAMERA FEATURES & OPTIONS THE OFF, ON, AND SETUP MODE The Proof Cam has three basic operational modes: • OFF mode: Power switch in the OFF position. • ON mode: Power switch in the ON position (LCD screen is off.) •... -
Page 13: Status Indication Lights
STATUS INDICATION LIGHTS RED LIGHT *** (on front of camera) Lights up when the camera detects motion. After you close camera door and are standing in front of the camera, visibility of this light is indication that your camera can sense you. TIP: Under setup mode, walk in front of the camera and look for the red light to illuminate when you are detected. -
Page 14: Battery Life
BATTERY LIFE Long battery life is one of the most important requirements for convenient and enjoyable game camera use. There are several variables that will determine the battery life including type of batteries, temperature outside, recording settings, frequency of camera activity, etc. Colder temperatures, more advanced settings, night photos and high photo frequency (low camera delay) will result in shorter battery life. -
Page 15: Formatting / Clearing Sd Memory Card
Formatting The SD Card Erases All images and Data. NOTE: Primos recommends formatting all SD media on a computer after media has been copied to the computer and no longer needed on the SD media. -
Page 16: Usb Port
VIEWING/RETRIEVING MEDIA Explore the methods for viewing recorded media on your camera SD Memory Card: 1. Remove SD Memory Card from slot in camera 2. Replace with separate, clean SD Card if you want camera to continue work. How To View Images/Videos 1. -
Page 17: Image Stamp
IMAGE STAMP Moon Phase Temp Date Day of the Week Time... -
Page 18: Camera Specifications
CAMERA SPECIFICATIONS Vendor Model #/Style # 63054 63055 63056 Camera Model Primos Proof Cam 01 HD -- Primos Proof Cam 02 HD -- Primos Proof Cam 03 HD -- 10MP Game Camera 12MP Game Camera 12MP Game Camera Shooting modes... - Page 19 Vendor Model #/Style # 63054 63055 63056 Trigger Time 0.7 Second 0.4 Second 0.4 Second Removable Memory up to 32 GB SD Card up to 32 GB SD Card up to 32 GB SD Card System requirements Windows 2000, XP, Vista, Windows 2000, XP, Vista, Windows 2000, XP, Vista, (Windows)
-
Page 20: Operating Tips
OPERATION TIPS Learning to use your PROOF ® Visiting www.primos.com and watching our Instructional Video Clips is the ‘easiest way’ to learn ‘how to use’ your PROOF Camera! ® Troubleshooting or Questions Before calling customer service, visit primos.zendesk.com to find troubleshooting tips, frequently asked questions and answers, as well as any updates. - Page 21 If the object is too close to camera, the LED light may reflect back causing over exposure. This is common, not a quality issue. Dark or Light Image Quality Primos takes pride in the quality of images captured by the Proof Cam. As daylight transitions ®...
- Page 22 ‘speed up’ or ‘slow down’ the video playback. To do this, with the video file open in playback mode: Right Click on Video --> Select Enchancements --> Select Play Speed Settings. If you want more advanced playback features, feel free to visit www.primos.com for other video player recommendations.
-
Page 23: Recommended Accessories
RECOMMENDED ACCESSORIES Other Accessories 1. Padlock for door latch to prevent tampering camera settings or memory 2. Locking Security Cable to run through case and around tree. Accepts 5/16” Master Lock Python ® ™ Adjustable Locking Cable is convenient and highly recommended. -
Page 24: Customer Service & Warranty
Terms: You must register your PROOF Cam and keep the “Proof of Purchase” to receive warranty protection. ® on your Camera. **Go online to www.primos.com/registration and complete the Online Registration. You have 1 month from date of purchase to register your PROOF Cam online. ®... - Page 25 ® content of these written materials or software, or for damages resulting from the use of the information contained therein. Primos reserves the right to alter the features and contents of this publication, ®...
- Page 26 Online Support Visit www.primos.com for instructional videos Please contact Primos Customer Service ® Team with any comments, questions, problems return requests. Call INSTRUCTION MANUAL (601) 879-9323 or email service@primos.com.
