Fakir DOPPIO Instruction Manual page 8

1. Inlet grill
2. Outlet grill
3. Power selector
4. Temperature selector
(thermostat)
5. Removable foot
Model: Doppio Fan Heater
Electrical Information:
230V AC 50 Hz
Life Time: 10 year
Power: Stage 1: 1000W
Stage 2: 2000W
Insulation Class: II
Degree of protection: IPX1
USAGE
The power switch (3) allows you to
switch and adjust the desired power:
0 Off
Cold Air
1000W
I
II 2000W
3
To set the thermostat (4)
proceed as follows:
1) Turn the temperature selector
clockwise until the end of the race.
2) Upon reaching into the desired
temperature, turn the dial slowly
temperature clockwise until the fan
heater shutdown.
3) At this point the control automatically
keep the temperature level on the set.
ATTENTION: The product is not
stable! Insert the removable foot on
the proper space depending by the
position you prefer (horizontal or
vertical position). To remove the foot
hold tight the tongue and pull the foot.
8
4
1
2
5
