Sony TRINITRON KV-SW292M50 Service Manual page 47

D3 BOARD VOLTAGE LIST (not used for these models)
Ref Pin No. Voltage[v]
IC2800 I 15.0
G 0
O 8.9
IC2801 1 4.4
2 4.4
3 4.4
4 0
5 *
6 1.4
7 7.9
8 8.9
Q2800 B -0.4
C 0.3
E 0
VM BOARD VOLTAGE LIST
Ref Pin No. Voltage[v]
Q5901 B 2.6
C 8.8
E 1.9
Q5902 B 135.8
C (100.8)[83.3]
E 135.9
Q5903 B 2.6
C 4.6
E 1.9
Q5904 B 4.6
C 0
E 5.0
Q5905 B 5.5
C 8.8
E 5.0
H4 BOARD VOLTAGE LIST
Ref Pin No. Voltage[v]
IC1900 VCC 3.3
GND 0
OUT 2.9
H5 BOARD VOLTAGE LIST (not used for these models)
Ref Pin No. Voltage[v]
Q3901 B 0
C 3.3
E (0.3)[0.1]
Q3902 B 3.3
C 2.0
E 1.9
Ref Pin No. Voltage[v]
Q2801 B 0.3
C (2.3)[2.6]
E 0
Q2802 B 1.5
C 14.5
E 0.9
Q2803 B 14.0
C 1.5
E 14.5
Q2804 B 1.7
C 14.0
E 1.2
Ref Pin No. Voltage[v]
Q5906 B (0.5)[0.3]
C (100.8)[83.4]
E 0
Q5912 B 2.5
C 8.1
E 1.8
Q5913 B 8.1
C 2.5
E 8.8
Q5914 B 2.6
C 8.8
E 1.9
– 51 –
KV-SW292M50/M61/M80/N60
RM-GA002
