Trinitron Color TV
Operating Instructions
• Before operating the unit, please read this manual thoroughly and retain
it for future reference.
Инструкция по эксплуатации
• Перед работой с устройством внимательно прочтайте инструкцию
и сохраните её для дальнейшего использования.
KV-SW29
KV-SW25
© 2004
Sony Corporation
2-342-359-11 (1)
GB
RU
M91

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FD Trinitron WEGA KV-SW25 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sony FD Trinitron WEGA KV-SW25

Summary of Contents for Sony FD Trinitron WEGA KV-SW25

  • Page 1 • Before operating the unit, please read this manual thoroughly and retain it for future reference. Инструкция по эксплуатации • Перед работой с устройством внимательно прочтайте инструкцию и сохраните её для дальнейшего использования. KV-SW29 KV-SW25 © 2004 Sony Corporation 2-342-359-11 (1)
  • Page 2 WARNING • Dangerously high voltages are present inside the TV. • TV operating voltage: 110 – 240 V AC. • Do not plug in the power cord until you have completed making all other connections; otherwise a minimum leakage current might flow through the antenna and other terminals to ground.
  • Page 3 TV set weight. Ensure that the TV stand surface is flat and its area is larger than the bottom area of the TV. Made in Malaysia. Sony Corporation 6-7-35 Kitashinagawa, Shinagawa-ku, Tokyo, 141-0001 Japan. Do not plug in too many appliances to the same power socket.

  • Page 4: Securing The Tv

    x Securing the TV To prevent the TV from falling, use the supplied screws, clamps and band to secure the TV. 3.8 mm screws Note • Use only the supplied screws. Use of other screws may damage the TV. 20 mm clamps Screw the band to the TV stand and to the provided hole at the rear of your TV.

  • Page 5: Table Of Contents

    Table of Contents Installation Getting Started ... 6 Setting up your TV (“Initial Setup”) ... 7 Overview of Controls TV front and rear panels ... 9 Using the remote control and basic functions ... 10 Advanced Operations Selecting the picture and sound modes ...

  • Page 6: Installation

    Installation x Getting Started Installation Step 1 Insert the batteries (supplied) into the remote. Note • Do not use old or different types of batteries together. Step 2 Connect the antenna cable (not supplied) to 8 (antenna input) at the rear of the TV. •...

  • Page 7: Setting Up Your Tv ("Initial Setup")

    x Setting up your TV (“Initial Setup”) When you turn on your TV for the first time, the “Начальная настройкa “ (“Initial Setup”) menu will appear. You may change the menu language, preset the TV channels automatically, change the order of TV channels that appear on the screen and adjust the picture position using the buttons on the TV front panel.
  • Page 8 continued The selected channel will appear on the screen. 2) Press 2+/– to select the new program number position for your selected channel, then press t. 3) Repeat steps b) 1) and 2) if you wish to change the order of the other channels.

  • Page 9: Overview Of Controls

    Overview of Controls TV front and rear panels AUTO PROG:Pr AUTO PROG:Press [MENU] for 5sec ess [MENU] for 5sec L(MONO) SOUND MENU PROG MODE (AUTO PROG) TV front panel L(MONO) Button/Terminal PROG +/– 2 +/– Menu operations 2 +/– MENU (AUTO PROG) SOUND MODE t1, t2...

  • Page 10: Using The Remote Control And Basic Functions

    Using the remote control and basic functions Button PROG +/– 2 +/– 0 – 9, - RESET Overview of Controls PROG MENU RESET Description Turn off temporarily or turn on the TV. Display the TV program. Jump to last program number that has been watched for at least five seconds.
  • Page 11 Button Description Select sound mode options. 5-Band Graphic Equalizer display will appear. Select picture mode options. Menu operations MENU Display or cancel the menu. Confirm selected items. V, v, B, b Select and adjust items. Timer operations Set TV to turn on automatically according to the (Wake Up Timer) desired period of time (max.

  • Page 12: Advanced Operations

    Advanced Operations Selecting the picture and sound modes You can select picture and sound modes and adjust the setting to your preference in the “Personal” option. PROG MENU RESET Selecting the sound mode Press (or SOUND MODE on the front panel) to select the desired sound mode. 5-Band Graphic Equalizer display will appear.

  • Page 13: Enjoying Stereo Or Bilingual Programs

    x Enjoying stereo or bilingual programs You can enjoy stereo sound or bilingual programs of NICAM and A2 stereo systems by using the A/B button. PROG MENU RESET Note • If the stereo sound is noisy when receiving a stereo program, select “Mono”. The sound becomes monaural but the noise is reduced.

  • Page 14: Viewing Teletext

    x Viewing Teletext Some TV stations broadcast an information service called Teletext which allows you to receive various information, such as stock market reports and news. You can use the buttons on the remote to view Teletext. PROG MENU RESET (red, green, yellow,...

  • Page 15: Menu Adjustment

    Menu Adjustment x Introducing the menu system The MENU button lets you open a menu and change the settings of your TV. The following is an overview of the menu system. Picture icon Sound icon Channel Setup icon Setup icon Menu level 1 Level 2 Level 1...
  • Page 16 continued Level 1 Level 2 “Channel Setup” “Auto Program” “Manual Program” “Program Label” “Program Block” “Program Sorting” “Setup” “Language” “Picture Position” “Wide Mode” “Video Label” “Color System” Menu Adjustment Level 3/Function Preset channels automatically. Preset channels manually. Label the program number. Block unwanted programs.
  • Page 17 How to use the menu PROG Press MENU to display the menu. MENU RESET Press V or v to select the desired item. Press confirm your selection and go to the next level. Other menu operations Adjust the setting value Move to the next/previous menu level Cancel the menu Tips...

  • Page 18: Changing The "Picture" Setting

    x Changing the “Picture” setting The “Picture” menu allows you to adjust the picture settings. Press MENU. Make sure the “Picture” icon ( selected, then press Press V or v to select the desired item (e.g., “Mode”), then press Select “Mode”...

  • Page 19: Changing The "Sound" Setting

    x Changing the “Sound” setting The “Sound” menu allows you to adjust the sound settings. Press MENU. Press V or v to select the “Sound” icon ( then press Press V or v to select the desired item (e.g., “Mode”), then press Select “Mode”...
  • Page 20 continued Adjusting the “Sound Adjustment” item under “Personal” mode The 5-Band Graphic Equalizer feature allows you to adjust sound frequency settings of “Personal” mode in the menu. Make sure that “Adjust” is selected, then press Selecting “Reset” will set your TV to the factory setting.

  • Page 21: Changing The "Channel Setup" Setting

    x Changing the “Channel Setup” setting The “Channel Setup” menu allows you to preset channels automatically, manually preset channels, label the program number, block unwanted programs and change the order of TV channels that appear on the screen. Press MENU. Press V or v to select the “Channel Setup”...

  • Page 22: Presetting Channels Manually

    continued Presetting channels manually After selecting “Manual Program”, select the program number to which you want to preset a channel. (1) Make sure “Program” is selected, then press (2) Press V or v until the program number you want to preset appears on the menu, then press Select the desired channel.

  • Page 23: Changing The "Setup" Setting

    x Changing the “Setup” setting The “Setup” menu allows you to change the menu language, adjust the picture position, change the picture size, label the connected equipment and select the color system. Press MENU. Press V or v to select the “Setup” icon ( then press Press V or v to select the desired item (e.g., “Language”), then press Select...

  • Page 24: Additional Information

    Additional Information x Connecting optional components Connecting to the video input terminal ( t ) TV front panel L(MONO) TV rear panel Note • If you connect a VCR to 8 (antenna input), preset the signal output from the VCR to the program number 0 on the TV (see page 22).

  • Page 25: Connecting To The Component Video Input Terminal

    Connecting to the component video input terminal ( TV rear panel Notes • If your DVD player can output interlace and progressive mode signals, select the interlace output when connecting to either 525i/60Hz or 625i/50Hz interlace signals. • Some DVD player terminals may be labeled differently: Connect To (on the DVD player) Y (green)

  • Page 26: Reset Function

    • Check the antenna cable and connection on the TV, VCR and at the wall. • Check the antenna setup. Contact a Sony dealer for advice. • Display the “Channel Setup” menu and select “Manual Program” to preset the channel again.
  • Page 27 • Do not use a hair dryer or other equipment near the TV. • Check the antenna setup. Contact a Sony dealer for advice. • Use a highly directional antenna. • Use the fine tuning (“Fine”) function.
  • Page 28 TV. • Check the antenna cable and connection on the TV, VCR and at the wall. • Check the antenna setup. Contact a Sony dealer for advice. — • Check the antenna cable and connection on the TV, VCR, and at the wall.
  • Page 29 This does not indicate a turned on. malfunction. Solutions • Count the number of times the 1 (standby) indicator flashes. Press ! (main power) to turn off your TV. Contact your nearest Sony service center. — — –– Additional Information Page –...

  • Page 30: Specifications

    (Headphone) Picture tube Tube size (cm) Screen size (cm) Dimensions (w/h/d, mm) Mass (kg) Design and specifications are subject to change without notice. Sony Corporation Additional Information KV-SW25M91 KV-SW29M91 Output: 1 Phono jacks; 1 Vp-p, 75 ohms Output: 1 Phono jacks;...
  • Page 31 ВНИМАНИЕ!
  • Page 32 Sony Corporation 6-7-35 Kitashinagawa, Shinagawa-ku, Tokyo, 141-0001 Japan.
  • Page 33 x Безопасная установка телевизора 20 мм 3,8 мм Винты Зажимы Крепежная лента или или Примечание...
  • Page 34 Содержание Установка Элементы управления Более сложные функции Настройка с помощью меню Дополнительная информация...
  • Page 36 V/v/B/b...
  • Page 37 Продолжение Советы 2 +/–...
  • Page 38 AUTO PROG:Pr AUTO PROG:Press [MENU] for 5sec ess [MENU] for 5sec L(MONO) SOUND MENU MODE (AUTO PROG) PROG L(MONO) PROG +/– MENU (AUTO PROG) SOUND MODE 8 7 6 AUTO PROG:Press [MENU] for 5sec SOUND MENU PROG MODE (AUTO PROG) qd qs...
  • Page 39 PROG +/– 0 – 9, - RESET PROG MENU RESET –...
  • Page 40 MENU V v B b...
  • Page 41 PROG MENU RESET 100 300 1k 3k 8k 100 300 1k 3k 8k 100 300 1k 3k 8k 100 300 1k 3k 8k...
  • Page 42 PROG MENU RESET NICAM NICAM NICAM NICAM...
  • Page 43 PROG MENU RESET...
  • Page 44 English...
  • Page 45 Продолжение...
  • Page 46 PROG MENU RESET V v B 2 +/–...
  • Page 47 V v B...
  • Page 49 Продолжение 100 300 1k...
  • Page 51 Продолжение V v B...
  • Page 52 V v B...
  • Page 53 Дополнительная информация x Подключение дополнительных компонентов Подключение к разъему входа видеосигнала ( t ) Передняя панель ТВ L(MONO) Задняя панель ТВ Примечаниe Подключение к разъему выхода сигнала монитора (T) Задняя панель ТВ Аудио/ видеокабель (не прилагается) Антенный кабель (не прилагается) Аудио/ видеокабель...
  • Page 54 Подключение к разъему входа компонентного видео- сигнала ( Задняя панель ТВ Примечания Подсоедините K…(на DVD-проигрывателе) Кабель компо- нентного видео (не прилагается) DVD- проигрыватель Аудиопкабель (не прилагается)
  • Page 55 RESET RESET...
  • Page 57 Продолжение – –...
  • Page 59 KV-SW29M91 KV-SW25M91 Sony Corporation...
