KV-SW292M50/M61/M80/N60
ITEM INFORMATION
No. OPB1
Item
KV-SW292M50
(India)
KV-SW292M50
(Thailand)
KV-SW292M61
KV-SW292M80
KV-SW292N60
No. OPB2
Item
KV-SW292M50
(India)
KV-SW292M50
(Thailand)
KV-SW292M61
KV-SW292M80
KV-SW292N60
Party Mode
FM Radio
Component
Composite
SECAM
Color decoding
RM-GA002
Speed Search Home
Theatre
0 1
0 1
0 1
0 1
1 1
SPEED SEARCH (Time of speed search)
Home Theatre
Wide Screen
TV System Selection (M,B/G, I, D/K)
Party FM Component
Mode Radio
0 0
0 0
0 1
0 0
0 1
Party Mode Function
FM Radio Function
(Component [YCbCr] Terminals) 0 = not available,
(No. of Composite Terminals)
(SECAM Color System)
(Color Crystal Selection)
Wide M
Screen
0 0 1
0 0 1
0 0 1
0 0 1
0 0 0
00 = disabled (original cycle speed)
01 = 4 time speed from the original
10 = 6 time speed from the original
11 = 8 time speed from the original
Composite (SCART)
1 1 0
1 1 0
1 1 0
1 1 0
1 1 0
0 = not available,
0 = not available,
00 = 1 composite terminal
01 = 2 composite terminals
10 = 3 composite terminals
11 = 4 composite terminals
(BX1L FULL only)
0 = disabled,
00 = PAL/NTSC (Multi)
01 = NTSC (3.58MHz)
10 = PAL/NTSC (4.43MHz)
11 = PAL/NTSC (Tri-Norma)
– 26 –
B/G I
1 1
1 1
1 1
1 1
0 0
1 = Home Theatre mode available
1 = Wide Screen model
0 = disabled, 1 = enabled
SECAM Color Decording
1 0
1 0
1 0
1 0
1 0
1 = available
1 = available
1 = available
1 = enabled
D/K DEC
1 79
1 79
1 79
1 79
0 192
DEC
0 52
0 52
0 116
0 52
0 116
