RETAIN THESE INSTRUCTIONS
FOR FUTURE REFERENCE
VEUILLEZ GARDER CE MANUEL
POUR RÉFÉRENCE FUTURE.
A French manual is available upon request. Order P/N 850,031CF
Ce manuel d'installation est disponible en francais, simplement en
faire la demande. Numéro de la pièce 850,031CF.
INSTALLATION
INSTRUCTIONS
42" Indoor / Outdoor Wood Burning Fireplaces
P/N 850,031M REV. B 04/2006
This installation manual will enable you to obtain a safe, effi cient and de-
pendable installation of your fi replace system. Please read and understand
these instructions before beginning your installation.
Do not alter or modify the fi replace or its components under any circum-
stances. Any modifi cation or alteration of the fi replace system, including
but not limited to the fi replace, chimney components and accessories,
may void the warranty, listings and approvals of this system and could
result in an unsafe and potentially dangerous installation.
IMPORTANT! TO ASSURE PROPER ALIGNMENT OF GLASS
DOORS: INSTALL THIS FIREPLACE IN A SQUARE AND PLUMB
CONDITION, USING SHIMS AS NECESSARY AT SIDES AND/OR
BOTTOM.
NOTE: This fi replace has been listed and approved for use outdoors or
indoors.
CAUTION! THIS FIREPLACE IS EQUIPPED TO BE READILY IN-
STALLED OUTDOORS. IF INSTALLED INDOORS, YOU MUST
INSTALL THE COMBUSTION AIR COVER PROVIDED WITH THE
INSTALLATION KIT OR PURCHASE THE OPTIONAL OUTSIDE AIR
KIT GATE OAKG-OD. SEE INSTRUCTIONS INSIDE THIS MANUAL
FOR FURTHER DETAILS.
IMPORTANT! POUR ASSURER L'ALIGNEMENT APPROPRIÉ DES
PORTES DE VERRE : INSTALLEZ CE FOYER SUR UNE SURFACE
PLANE ET METTRE À NIVEAU EN UTILISANT DES CALES AU
BESOIN SUR LES CÔTÉS OU EN DESSOUS.
ATTENTION! CETTE CHEMINÉE A ÉTÉ ÉNUMÉRÉE ET APPROU-
VÉE POUR ÊTRE AISÉMENT INSTALLÉE À L'INTÉRIEUR OU
DEHORS. S'INSTALLÉ À L'INTÉRIEUR, VOUS DEVEZ INSTALLER
LA COUVERTURE D'AIR DE COMBUSTION ÉQUIPÉE DE KIT
OTL Report No.
D'INSTALLATION OU ACHETER LA PORTE EXTÉRIEURE FAC-
116-F-37-2
ULTATIVE OAKG-OD DE KIT D'AIR. VOIR LES INSTRUCTIONS À
L'INTÉRIEUR DE CE MANUEL POUR D'AUTRES DÉTAILS.
®
MERIT
PLUS SERIES
MODEL
MP-42OD
Advertisement
Table of Contents
Related Manuals for Lennox MP-42OD
Summary of Contents for Lennox MP-42OD
- Page 1 42" Indoor / Outdoor Wood Burning Fireplaces P/N 850,031M REV. B 04/2006 MODEL MP-42OD This installation manual will enable you to obtain a safe, effi cient and de- pendable installation of your fi replace system. Please read and understand these instructions before beginning your installation.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Safety Rules ...Page 2 Tools and Building Supplies ...Page 2 Precautions ...Page 2 Introduction ...Page 3 Clearances/Height Requirements ...Page 4 Chimney System ...Page 4 Assembly Outline ...Page 4 Location of Fireplace ...Page 5 Clearances ...Page 5 Assembly Steps ...Page 6 Preinstallation Notes ...Page 6 Waterproofi... -
Page 3: Introduction
Note: These fi replace systems are not diffi cult to install. However, in the interest of safety, it is recommended that the installer be a qualifi ed or certifi ed “tradesman” familiar with commonly accepted fi replace installation and safety tech- niques as well as prevailing local codes. -
Page 4: Clearances/Height Requirements
WARNING Failure to use manufacture provided parts, variations in techniques and construction materials or practices other than those described in this manual may create a fi re hazard and void the limited warranty. AVERTISSEMENT L’échec d’utiliser la fabrication les parties fournies, les varia- tions dans les techniques et le matériel de construction ou les pratiques autre que ceux-là... -
Page 5: Location Of Fireplace
Damper Damper Open Closed Lintel Combustion Air Actuator (when installed) Figure 3 Chase Enclosure - Indoor Installation Insulate Joists Same As Ceiling Draft Stops Firestop CTDT Termination Note: Non- Combustible Chase Flashing Must Be Used To Cover Chase Opening Optional Insulation In Outside Walls Of... -
Page 6: Assembly Steps
ASSEMBLY STEPS Note: The following steps represent the normal sequence of installation. Each installation is unique, however, and might require a different sequence. 1. Position fi rebox prior to framing or into prepared framing. 2. (Outdoor Installations) Waterproof the fi replace. See Waterproofi ng The Fireplace on Page 6. - Page 7 Assemble the Air Gate and Arm as shown. Air Gate Assembly Air Gate Arm Air Gate Assembly Air Gate Arm When assembled onto appliance, the notch here must be positioned as shown Figure 9- Outside Air Kit Gate IMPORTANT! IF THE AIR GATE IS INSTALLED UPSIDE DOWN (WITH THE NOTCH POSI- TIONED ON THE UPPER HALF) IT WILL NOT WORK PROPERLY.
- Page 8 Outside Air Kit Installation (provided) These appliances are equipped with a com- bustion air inlet collar so that it is possible to duct combustion air from the outdoors to the fi rebox. To accomplish an outside air hook- up, use only the Outside Air Kit provided with these appliances.
-
Page 9: Fireplace & Framing Specifi Cations
FIREPLACE SPECIFICATIONS - MODEL MP-42OD Product Reference Information Cat. Model Ship. Ship. Weight Volume H1934 MP-42OD 188 lb. 24 cu. ft. Framing Dimensions 46-1/2" 1181 mm 43-1/2" 1105 mm 60-1/2" 1537 mm 33" 828 mm 17-1/2" 445 mm 76-1/4" 1937 mm 38-1/8"... -
Page 10: Installing The Fireplace
Framing Ceiling Frame the opening for the ceiling as speci- fi ced here. Note: Faming Dimensions in Canada & USA are different because installations in USA require 1" Clearance to pipe. Installations in Canada require 2" Clearance to pipe. Framing Dimensions for Ceiling Flue Type FTF8 Vertical (USA) - Page 11 Note: Install the hearth extension only as il- lustrated (see Figures 21 & 22). The safety strips should extend from front of the fi replace at least 1 1/2" and should extend to be at least fl ush with the sides. In the event a wooden support is used to elevate the fi...
-
Page 12: Installing The Chimney System
3. Cut or frame a hole through the outside wall for the installation of the air inlet hood. A 6-1/2" diameter hole is required. Feed the loose end of the fl exible duct through the hole and attach to the collar on the air inlet hood using two (2) screws from the kit's hardware package. -
Page 13: Offset Through Floor/Ceiling
CHIMNEY 30° OFFSET THROUGH FLOOR OR CEILING It may be necessary to assemble the chimney at 30° when passing through the fl oor or ceiling area. Use the F8FS30 fi restop spacer as shown in Figures 31 & 32. Support the chimney at fl oor or ceiling penetration with a FTF8 stabilizer if distance of chimney below ceiling is 10' or more. - Page 14 Figure 37 FTF8-S4 Stabilizer Note: Do not apply excessive pressure to any subsequent chimney sections following the stabilizer when installing. Ensure each subse- quent chimney section is securely attached by testing as noted in Step 4. Step 6. Select the proper Security Chimneys roof fl...
-
Page 15: Ten Foot Rule Summary
Less Than 10' Figure 43 Note: It is recommended that all exterior ex- posed metal fi replace components; such as terminations, fl ashings, storm collars and/or fl ue be painted with a premium quality, high temperature, rust preventative paint designed for metal. -
Page 16: Offset Calculations
The offset and return elbows may be attached together, or a section or sections of chimney may be used between, but do not exceed 20' in total length between elbows. If sections of pipe exceed 10' between elbows, a chimney stabilizer must be used at the midpoint (Figure 45). -
Page 17: Installing Offsets
Return Elbow Max. Stabilizer 10' Max. Offset Elbow Figure 45 Figure 46 Joints Chimney Section No. 8 x 1/2" SMS Figure 47 Underside Of Chimney Figure 48 FTF8-E30 Return Elbow* Chimney Section (S) FTF8-30 Offset Elbow* *Part of Offset/Return Package Model FTF8-ES30 Figure 49 NOTE: DIAGRAMS &... -
Page 18: Offset Elevation Chart
FTF8-ES30 Offset Height Offset/Return (Inches) (Inches) Elbow Table 4 Offset Elevation Chart Number of FTF8 Chimney Sections FTF8-S4 Stabilizer 12" 18" 36" NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE. 48" Figure 50 Note: The return elbow assembly performs the same function as a stabilizer. -
Page 19: Vent Free Appliances
Vent Free Appliances This unit has been tested and approved to ANSI/IAS/AGA Z21.11.2 for use with unvented gas appliances for INDOOR INSTALLATIONS ONLY and complies with the standard for Fac- tory-Built fi replaces, UL 127, when installed with unvented gas log sets. Special instructions with regards to mantel installations must be taken into consideration when installing such appliances. -
Page 20: Cold Climate Insulation
ATTENTION Certaines portes de verre recou- vrent le revêtement noir en métal du foyer. SI la façade du foyer a été recouverte avec des matériaux non-combustibles, il se pourrait qu’il n’y ait pas suffi sament de dégagement pour installer les portes de verre de votre choix. - Page 21 Wall Shield Required Where Less Than 12" 24" 30" Methods of Determining Hearth Extension and Wall Shield Equivalents - To determine the thickness required for the alternate material when either the "k" value or "r" value is known, use either the k formula or r formula.
-
Page 22: Finish Requirements
Calculating Minimum Thickness if Multiple Materials are Used At times it is important to know what combination of materials are acceptable for use as fl oor protection. The “R values” are used to determine acceptable combinations of materials because “R values” are additive where r and k values are not. -
Page 23: Installation Components
INSTALLATION COMPONENTS The following items are available for use in the installation of this appliance. Firestop Spacer (30°) 63L30 F8FS30 Firestop Spacer (30°) 63L32 F8FS30-2 Firestop Spacer (45°) (Canadian) 63L33 FFS-45C Offset/ Return Package (30°) 63L22 FTF8-ES30 45° Offset/Return Package (Canadian) 63L69 FTF8-ES45C... - Page 24 Indoor Installations Only Contains: 3 FTF8-36 1 F8FS 1 F8F6 1 FTF8-CTD Indoor Installations Only Chimney Pack (conventional) Convenience Pack - Residential 63L70 Chase Termination (Round) H0203 FTF8-CTDTM Ref. Form #750,016M Chase Termination (Square) 63L51 Ref. Form #750,077M 8” Open Top Termination (clay top termination) (For open top shrouds) 96L20 Ref.
