LENNOX HEARTH PRODUCTS
SAVE THESE INSTRUCTIONS
FOR FUTURE REFERENCE
INSTALLATION AND
OPERATION INSTRUCTIONS
Merit
™
36" Electric Fireplace
P/N 775,172M REV. G 04/2007
MODEL:
MPE-36R
This manual will enable you to obtain a safe, efficient and dependable
installation and operation of your electric fireplace. Please read and
understand these instructions before beginning your installation.
Do not alter or modify this fireplace or its components under any circum-
stances. Any modification or alteration of the fireplace system, including
but not limited to the fireplace and accessories, may void the warranty,
listings and approvals of this system and could result in an unsafe and
potentially dangerous installation.
IMPORTANT! IF OPTIONAL GLASS DOORS ARE PURCHASED, TO
ASSURE PROPER ALIGNMENT, INSTALL THIS FIREPLACE IN A
SqUARE AND PLUMb CONDITION, USING SHIMS AS NECESSARy
AT SIDES. THIS APPLIANCE IS MOUNTED ON RUbbER FEET TO
ENSURE ADEqUATE AIR CIRCULATION bENEATH FIREPLACE.
DO NOT bLOCK AIRFLOW AT THE bOTTOM AIR INTAKES.
INSTALLER: DO NOT DISCARD THIS MANUAL
PLEASE LEAVE FOR THE HOMEOWNER
FOR yOUR SAFETy
DO NOT STORE OR USE GASOLINE OR OTHER FLAMMAbLE
VAPORS AND LIqUIDS IN THE VICINITy OF THIS OR ANy OTHER
APPLIANCE.
Lennox™ electric fireplaces are designed for use as a decora-
tive appliance and/or as a supplemental heater. They are not
intended for continuous use as a primary heat source.
A French manual is available upon request. Order P/N 775,172CF
Ce manuel d'installation est disponible en francais, simplement en
faire la demande. Numéro de la pièce 775,172CF.
®
C
US
PLUS SerieS
Report # C1482763
