Lennox MP-360D Homeowner's Care And Operation Instructions Manual
36" and 42" indoor/outdoor wood-burning fireplace
Hide thumbs
Also See for MP-360D:
- Homeowner's care and operation instructions manual (12 pages) ,
- Quick start manual (2 pages)
Table of Contents
Advertisement
MP-42OD
retain these instructions
For Future reFerence
VeuiLLeZ Garder ce manueL
pour rÉFÉrence Future.
US
MP-36OD
otL report no.
(mp-36od) #116-F-35-2
(mp-42od) #116-F-37-2
NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
homeowner's care and
operation instructions
MERIT
®
36" and 42" indoor/outdoor wood-Burning Fireplaces
p/n 875029m rev. B 10/2011
MODELS
MP-36OD
The information contained in this manual applies to all model fireplaces
identified on this page. This information will help you obtain safe and
dependable service from your Lennox fireplace system. Keep this docu-
ment in a safe place for future reference.
Before you start your first fire, read this Care and Operations Manual
carefully to be sure you understand your fireplace system completely.
Failure to follow these suggestions could result in hazardous operation
or fireplace malfunction, creating a serious potential for personal injury
and/or property damage.
If you have any questions regarding the safe use or operation of your
fireplace, contact your local Lennox distributor, or your contractor /
builder.
A French manual is available upon request. Order P/N 875029CF.
Ce manuel d'installation est disponible en francais, simplement en
faire la demande. Numéro de la pièce 875,029CF.
warninG: eXercise caution when operatinG iF in-
staLLed outdoors. do not Burn LarGe Fires. atmo-
spheric chanGes maY cause uneXpected Gusts oF wind.
FLames and ashes maY Be BLown out oF the FirepLace.
Keep the screen curtains cLosed at aLL times aFter
FeedinG the Fire.
aVertissement: eXercise Guarantee when operatinG
iF this appLiance is instaLLed outdoors. Broad c
not Burn Fires. atmospheric eXchanGes maY causes
uneXpected Gusts oF wind. FLames and ashes maY
Be BLown out oF the FirepLace. Keep the screen
curtains cLosed at aLL.
PLUS SERIES
MP-42OD
1
