User & Care Guide
Guide d'utilisation et d'entretien
Guía de uso y cuidado
Design may vary by model number.
This user manual is to be only used
for electronic control 6,050 BTU and
8,000 BTU. - Some models may have
an additional letter after the model
number.
La configuration peut varier selon le
numéro de modèle.
Ce guide d'utilisation doit être utilisé
strictement avec les modèles à
commande électronique de 6,050 BTU
y 8,000 BTU. - Sur certains modèles, le
numéro de modèle peut être suivi d'une
lettre.
Room Air Conditioner
Climatiseur individuel
Aire acondicionado
de uso doméstico
El diseño puede variar conforme al
número de modelo
Este manual del usuario es únicamente
para utilizar los controles electrónicos
modelos 6,050 BTU y 8,000 BTU.
Algunos de los modelos pueden tener
una letra adicional después del número
de modelo.
ESAQ406P
ESAQ408P
Advertisement
Table of Contents
Related Manuals for Haier ESAQ406P
Summary of Contents for Haier ESAQ406P
- Page 1 Room Air Conditioner Climatiseur individuel Aire acondicionado de uso doméstico User & Care Guide ESAQ406P Guide d'utilisation et d'entretien ESAQ408P Guía de uso y cuidado Design may vary by model number. La configuration peut varier selon le El diseño puede variar conforme al numéro de modèle.
-
Page 3: Table Of Contents
Normal Sounds of an Air Conditioner ..................23 TROUBLESHOOTING ......................24 LIMITED WARRANTY .......................25 PRODUCT REGISTRATION Thank you for purchasing our Haier product. This easy-to-use manual will guide Model number you in getting the best use of your product. Remember to record the model and serial Serial number numbers. -
Page 4: Safety Information
IMPORTANT SAFETY PRECAUTIONS WARNING THE INFORMATION IN THIS USE & CARE GUIDE MUST BE FOLLOWED TO MINIMIZE THE RISK OF PERSONAL INJURY, FIRE, ELECTRIC SHOCK OR OTHER UNSAFE CONDITIONS. THE INSTRUCTIONS IN THIS USE & CARE GUIDE ARE NOT MEANT TO INCLUDE EVERY POSSIBLE CONDITION OR SITUATION THAT MAY OCCUR. - Page 5 IMPORTANT SAFETY PRECAUTIONS 8. This air conditioner contains R410a refrigerant and requires certified technicians to use the proper equipment, tools and safety standards that are approved for this refrigerant. Use only equipment certified for R410a refrigerant. In addition, under federal law, all refrigerant must be properly removed from the air conditioner prior to its disposal.
-
Page 6: Operational Safety & Warnings
1. This air conditioner contains no consumer serviceable parts. If you have problems or questions regarding the operation of your air conditioner always call Haier Customer Service: 1-877-337-3639. 2. Be sure that the air conditioner is properly and securely installed in the window according to the installation instructions included in this Use &... -
Page 7: Installation Requirements
Drill and 1/8” bit Scissors Tape measure Pencil PARTS SUPPLIED: Check that all parts for your specific air conditioner are included in the parts package. NOTE: If parts are missing, call Haier Customer Service: 1-877-337-3639. IMAGE PART ESAQ406P ESAQ408P Top channel Foam seal... -
Page 8: Location Requirements
THE LOCATION SHOULD PROVIDE: • A grounded electrical outlet within 6 ft. (183 cm) of where the power supply cord exits the air conditioner, for models: ESAQ406P ESAQ408P NOTE: Do not use an extension cord, plug adapter, surge protector or multi-outlet adapter. -
Page 9: Electrical Requirements
ELECTRICAL REQUIREMENTS WARNING ELECTRICAL SAFETY and WARNINGS 1. DO NOT cut or remove the grounding prong on the attached power supply cord. Doing so may cause sparks or fire, and voids all warranties. For safety purposes the air conditioner must be properly grounded. - Page 10 If this power supply cord is damaged, it cannot be repaired and must be replaced with a cord from the product manufacturer. If the power supply cord is damaged call Haier Customer Service: 1-877-337-3639. PAGE 8...
- Page 11 It cannot be purchased at a retail store and must not be repaired by the user. If the power supply cord is damaged please call Haier Customer Service: 1-877-337-3639. • The power supply cord contains no user-serviceable parts.
-
Page 12: How To Install
(See Fig.7 & 8) 2. Using 3/8" self-tapping screws, attach the top channel to the top Fig. 8 of the air conditioner. (See Fig.8) Use four (4) 3/8" self-tapping screws for models: ESAQ406P & ESAQ408P PAGE 10 HOW TO INSTALL... - Page 13 PREPARING THE AIR CONDITIONER cont. INSTALL SIDE CURTAINS NOTE: Attach side curtains to the air conditioner before placing the unit in the window. 1. Place the tabbed side of the side curtain in the track on the right-hand side of the air conditioner cabinet. (See Fig.9) Fig.
-
Page 14: Preparing The Window
PREPARING THE WINDOW 1. Measure the width of the window opening. (See Fig.13) 2. Mark the center line on the inside of the windowsill with a pencil. (See Fig.14) WIDTH OF CENTER LINE WINDOW OPENING Fig. 13 Fig. 14 HEIGHT WIDTH WIDTH WIDTH... -
Page 15: Completing The Installation
COMPLETING THE INSTALLATION Fig. 17 ATTACH SIDE CURTAINS TO WINDOW 1. Pull the right-hand curtain and frame out until it fits flush to the side of the window frame. (See Fig.17) 2. Use a 1/8” drill bit to drill a starter hole through the top hole in the side curtain and into the window sash. -
Page 16: Using Your Air Conditioner
STARTING THE AIR CONDITIONER COOL HIGH QUIET SLEEP CLEAN FILTER °F/°C E-SAVE DEHUM AUTO POWER Temp. FILTER MODE SPEED TIMER RESET Time Operating your air conditioner properly helps you to obtain the best possible results. This section explains how to operate this air conditioner. IMPORTANT: •... - Page 17 STARTING THE AIR CONDITIONER cont. 1. Please put batteries into the remote control. 2. Press POWER once to turn on the air conditioner. NOTE: When the air conditioner is first plugged in, the LED display will show “88” for 3 seconds. After the air conditioner is turned on for the first time, the display will show the temperature 72 F and the fan is automatically set to Quiet speed and the Mode indicator will show ENERGY SAVE.
- Page 18 STARTING THE AIR CONDITIONER cont. COOL HIGH QUIET SLEEP CLEAN FILTER °F/°C E-SAVE DEHUM AUTO POWER Temp. FILTER MODE SPEED TIMER RESET Time SPEED 1. Press SPEED until you see the indicator light come on next to the desired setting. 2.
- Page 19 STARTING THE AIR CONDITIONER cont. TO CLEAR TIMER PROGRAM: NOTE: Air conditioner can be either on or off. Press TIMER until Timer indicator light turns off. TO VIEW OR CHANGE THE REMAINING TIME (IN HOURS): TIMER OFF 1. Press the TEMP/TIME arrow button to increase or decrease the time.
-
Page 20: Using The Remote Control
STARTING THE AIR CONDITIONER cont. FILTER RESET This feature automatically notifies you that the air filter must be cleaned. The indicator light will come on after 240 hours of operation. Clean the air filter (refer to Care and Cleaning), place it back in the front panel, and press the Filter Reset button. - Page 21 USING THE REMOTE CONTROL cont. To set the air conditioner to turn on between 1 hour and 24 hours: 1. Press the TIMER ON/OFF button. Timer ON indicator light on the air conditioner control panel will illuminate. 2. Press the TIMER UP or TIMER DOWN arrow button to change the delay time from 1 hour to 24 hours.
-
Page 22: Changing The Air Direction
CHANGING THE AIR DIRECTION ESAQ406P & ESAQ408P 4-Way Air Flow: The air directional louvers let you control the direction of the airflow. The airflow can be directed up-down and left to right. (See Fig.23) Fig. 23 PAGE 20 USING YOUR AIR CONDITIONER... -
Page 23: Caring For Your Air Conditioner
CLEANING THE AIR FILTER The air filter is removable for easy cleaning. A clean air filter helps remove dust, lint, and particles from the air for optimal cooling and operating efficiency. The Filter Reset light will turn on to notify you that the air filter must be cleaned. The light goes on after the air conditioner has been operating for 240 hours. -
Page 24: Cleaning The Front Panel
3. Air-dry the front panel completely. 4. Plug the power supply cord in the outlet and turn on the air conditioner. In the event that the filter is damaged and needs replacing, call Haier Customer Service: 1-877-337-3639 CUSTOMER SERVICE... -
Page 25: Normal Sounds Of An Air Conditioner
NORMAL SOUNDS OF AN AIR CONDITIONER NORMAL SOUNDS Your new air conditioner is designed to give you many years of dependable service. This section tells you how to clean and care for your air conditioner properly. While your air conditioner is operating, it is normal to hear the following sounds: SOUNDS REASON Air movement... -
Page 26: Troubleshooting
TROUBLESHOOTING POSSIBLE POSSIBLE CAUSE REMEDY PROBLEM Air Conditioner Power supply cord is not plugged Plug unit into a mating grounded outlet. does not start or into an outlet. operate Power supply cord has tripped. Press and release RESET button on the power supply cord. -
Page 27: Limited Warranty
THIS LIMITED WARRANTY IS GIVEN IN LIEU WHAT WILL BE DONE OF ALL OTHER WARRANTIES, EXPRESS OR Haier America will repair or replace any mechanical, IMPLIED, INCLUDING THE WARRANTIES OF electrical part or the compressor, which proves MERCHANTABILITY AND FITNESS FOR A defective in normal household use for a period of PARTICULAR PURPOSE. - Page 28 Model # ESAQ406P, ESAQ408P Haier America Issued Date: December 2014 Wayne, NJ 07470 ©2015 Haier America Trading, LLC.
