3. In a mixed delegate situation (BKGD along with one or more KEY layers) the T-Bar is lit it
medium blue, and conforms to the BKGD behavior described above.
4. If one or more KEY layers are delegated without BKGD, the T-Bar color is purple. When the
KEY layer (or, for multi-KEY selections, the first KEY layer) is fully displayed, T-Bar lighting is at
its brightest. Removing the layer dims the illumination.
5. The T-bar is always lit in orange for M/E's in Effect mode.

3.4.2 MAIN TRANSITION

1. Just as you would expect, the illumination of this T-Bar uses red-green coloration, standard
color coding for Program and Preview rows.
2. As for M/Es, described earlier, DSK-only delegate operations result in the T-Bar being lit in
purple.
3. Mixed mode (BKGD plus DSK delegates) likewise result in blue illumination after the fashion
of the M/E T-Bar behavior previously described.
