Characteristics

The Maxa Beam 400 series handheld searchlights are lightweight, compact, high intensity illuminators
which use a field replaceable 75 Watt Xenon short arc lamp and a precision electroformed reflector to
provide the ultimate source for long range and wide angle portable illumination. The features of this system
include:
• Color rendition similar to daylight (6,000K)
• All functions controlled with one hand
• Only the lightweight searchlight needs to be hand carried
• Operational characteristics can be field programed
• Three levels of illumination intensity
• 1˚ to 40˚ electronic zoom focus
• Visible (white) and Infrared illumination capability
• 12 Volt DC operation
• Weather resistant
• Snap on rechargeable battery modules
• Rechargeable battery belt
• Up to 2 hours of operation on one battery
• Quick charger recharges batteries in 2 1/2 hours
• Multi Voltage charger operates on 12-36 VDC and 100-240 VAC
• Stationary power supply operates searchlight from 120 or 220 VAC
• Customizable strobe function
• Remote models (MBS-430/450) allow remote control of:
• Beam intensity
• Beam Size
• Flexible mounting options
• Strobe Function
• Programmable Function
The 400 series consists of three models of searchlight:
• MBS-410 handheld searchlight
• MBS-430 remote control only searchlight
• MBS-450 handheld searchlight with remote control capability

Applications

For over 10 years, users world wide, in locations ranging from the Sahara Desert to the AlCan Pipeline
have come to rely on the Maxa Beam Searchlight system for:
• Force Protection
• Perimeter Security
• Infrared Surveillance
• Night Vision System Enhancement
Maxa Beam Searchlight System
Operation Manual
Copyright © 2002 by Peak Beam Systems, Inc.
All Rights Reserved.
•
•
•
•
2
Search and Rescue
Television Lighting
Maritime Navigation
Still & Motion Picture Photography
