- Page 1 P E A K B E A M S Y S T E MS , I N C . H i g h I n t e n s i t y X e n o n S e a r c h l i g h t O p e r a t i o n Ma n u a l P e a k B e a m S y s t e ms , I n c .
- Page 2 Peak Beam Systems, Inc. is a leader in the design and manufacture of high-powered Xenon searchlights for military, law enforcement and security applications since 1987. Peak Beam’s Maxa Beam Searchlights are deployed in more than sixty-five countries. Users include the U.S. Border Patrol, FBI, Secret Service, U.S. Marshals and all branches of the U.S.
-
Page 3: Table Of Contents
Input Power Requirements Troubleshooting Warranty and Repairs ....................20 Warranty Returns to the Factory For additional product support, please contact Peak Beam’s Technical Support Department and we will be happy to assist you: 1-610-353-8505 / techsupport@peakbeam.com. © 2024 Peak Beam Systems, Inc. -
Page 4: Overview
Overview Characteristics Maxa Beam Searchlights are high intensity illuminators that use an 85-watt Xenon short arc lamp and a precision electroformed reflector to provide the ultimate solution for long-range portable and remote-controllable illumination. All searchlights feature: • 12,000,000 Peak Beam CandlePower Output •... -
Page 5: Theory Of Operation
Theory of Operation The Maxa Beam Searchlight generates light by passing an arc of electricity between two electrodes in a quartz tube filled with Xenon gas. A plasma ball is formed and precisely positioned within an electroformed reflector. When the ignition button is pressed, a high voltage RF igniter produces up to 20,000 volts to ionize the Xenon gas within the lamp, allowing DC current to flow through the lamp. -
Page 6: Searchlight Operation
Searchlight Operation 1. Locate searchlight, battery and power cable. 2. Attach Searchlight to Battery by lining up the four feet of the searchlight over holes in top of battery (a). Lower the searchlight into the holes, then slide the searchlight towards the connector end of the battery (b) until searchlight locks in place. -
Page 7: Searchlight Programming
Searchlight Programming The Maxa Beam Searchlight’s factory default settings can be modified by inputting a series of programming sequences. For example, the right and left 4-way switch functions can be programmed to be either momentary or continuous high or strobe. The searchlight can also be programmed to start on continuous high or in strobe at a custom beam width to tailor the searchlight to a specific application. - Page 8 Enter start-up beam mode selector by holding down on/off switch, rocking LEFT, RIGHT. The current start-up beam mode will display. Continue to rock RIGHT to visually page through start-up mode options (in order: Normal, High, Strobe, Low, Normal, High, etc.). When desired start-up mode is displayed, release on/off switch. Note: When start-up mode is set to normal or high, the searchlight warms up in high beam for 3 seconds before transitioning to programmed start-up beam mode.
- Page 9 Hold down on/off switch, rock RIGHT, and release the on/off switch. Note: If start-up beam mode is set to high, the right switch function is locked to continuous and cannot be toggled to momentary. (F) Toggle Left Switch Function between Momentary and Continuous Hold down on/off switch, rock LEFT, and release the on/off switch.
-
Page 10: Rechargeable Battery Systems
Rechargeable Battery Systems Handheld Maxa Beam Searchlights are powered by rechargeable batteries that attach to the bottom of the searchlight. Maxa Beam Batteries are for use with Maxa Beam Searchlights only and should never be used with any other device. This Operation Manual covers the use of Peak Beam’s current Lithium Iron Phosphate (LiFePO ) batteries. - Page 11 Battery Safety Warnings: • Do not expose to fire or open flame. • Do not puncture, deform, incinerate or heat above 85°C (185°F). • Do not open or disassemble. Batteries are sealed in a waterproof case with no user-serviceable components. Do not attempt to use a battery that has a damaged case;...
- Page 12 Battery Charging: Warning: Never charge a COLD battery that is cooled below 32°F (0°C). Allow battery to return to room temperature first before connecting it to charger. Use only approved Peak Beam chargers. Improperly charging a battery may reduce service life and, in extreme cases, may cause the product to flame or leak. Charging with MBP-3200 Series Smart AC/DC LiFePO Chargers: 1.
-
Page 13: Searchlight Accessories
Searchlight Accessories Optical Filters: MBA-1500 Amber Smoke/Fog Filter MBA-1715 Semi-Covert Infrared Filter (715nm sharp cut-on) MBA-1850 Covert Infrared Filter (850nm sharp cut-on) MBA-1900 Fully Covert Infrared Filter (920nm sharp cut-on) MBA-3015 Collimating Lens Power Options: MBP-4000 100-240VAC Direct Drive Power Supply (-L/S) MBA-7110 12VDC Vehicle Adapter for Searchlight, 10 Foot Straight Cord... -
Page 14: Searchlight Maintenance
Searchlight Maintenance For best performance, clean the searchlight’s front lens with window cleaner or rubbing alcohol. Periodically spray down the body of the searchlight with fresh water, especially in marine environments where the housing is exposed to salt. Focusing the Lamp If the searchlight is dropped or receives a heavy impact from transportation or shipping, it may be necessary to refocus the lamp to maximize output. -
Page 15: Lamp And Lens Replacement
Lamp and Lens Replacement All Maxa Beam Searchlights have a field-replaceable Xenon short arc lamp and lens. The replacement instructions listed below are included as a general reference. For complete, detailed instructions on how to replace a searchlight’s lamp or lens, please see the Instruction Sheet that ships with each Replacement Kit. - Page 16 1. Before beginning maintenance, put on protective eyewear, a long-sleeved jacket and gloves. Disconnect searchlight from power. If searchlight was recently turned on, allow the searchlight cavity to cool completely before proceeding. 2. Use the 1/16” Hex Driver that is included with the Maxa Beam Searchlight to remove the three screws holding the lens in place.
- Page 17 3. To remove an intact lamp from the socket, grasp the metal end of the lamp and pull straight out. A slight side-to-side rocking motion may be necessary to gently unseat the lamp. To remove a lamp that is broken inside of the front cavity, tip the searchlight over a trashcan and gently shake to dislodge loose glass and metal fragments.
-
Page 18: Technical Details
Technical Details Remote Control Operation Wired Remote Control: All Maxa Beam Searchlights can be remotely controlled via a control connector on the searchlight housing. This remote control capability allows the operator to control the functions of the searchlight using a wired remote controller or to hard wire the searchlight directly into an auxiliary control panel. -
Page 19: Control Connector Pin-Outs
Control Connector Pin-Outs Standard 8-Pin Plastic Connector MBS-410, MBS-430-Y, MBS-430-W4-P Color Function 12VDC Out Blue Ground Orange On/Off Brown High/Normal Beam Black Focus Narrow Yellow Focus Wide Green Strobe/Low Beam Mode blank - not normally used RS-232 9-Pin Plastic Connector MBS-430-RSY, MBS-430-W4-RSP Color Function... -
Page 20: Input Power Requirements
Input Power Requirements Please contact Peak Beam Systems, Inc. for assistance sourcing an appropriate AC power supply for your searchlight: 1-610-353-8505 / techsupport@peakbeam.com. 10.0-13.5VDC Input Models MBS-410 Series, MBS-430-W4/-Y Series, MBPKG-E, MBPKG-E2 Parameter Value Unit Notes Operating Voltage 10.0-13.5 Volts Over Voltage/Reverse Polarity Protected to ±36V... -
Page 21: Troubleshooting
Troubleshooting Symptom Probable Cause Remedy Searchlights, All Low/dead battery OR Charge battery OR Searchlight ignites but then Insufficient Input Voltage check power source flashes repeatedly or turns If battery/power source are OK, off after 1-2 seconds Replace lamp bad lamp (also described as “searchlight stuck in strobe For Gen. -
Page 22: Warranty And Repairs
Warranty and Repairs Warranty Peak Beam Systems, Inc. warrants that for a period of 12 months from the date of purchase that its products (except as listed below) shall be free of defects in materials and workmanship under normal use and that Peak Beam Systems, Inc. shall, at its option, repair or replace any defective product upon the prepaid return of the product to its factory. - Page 23 Proud to be made in the U.S.A. Copyright © 2024 Peak Beam Systems, Inc.
