LED AND BUTTON FUNCTIONS

The LabelTac 4 PRO has one button and one 3-color LED indicator. By indicating the
LED with different color and pressing the button, the printer can perform several func-
tions, including feed labels, pause printing, selecting and claibrating the medai sensor,
resetting the printer, and more. Please refer to the button operation and LED function
charts below.
LED Color
Green (Solid)
Green (Flash)
Amber
Red (Solid)
Red (Flashing)
BUTTON FUNCTIONS:
a) While powered on & not printing: Feeds material
b) While printing: Pauses the current print job. Pressing again will resume.
c) While the printer is powered off- if the button is held, and released during different
LED cycles, the printer will perform different functions as detailed in the chart below.
Power-On Utility Functions
1) Ribbon sensor calibration and
Gap/Black Mark sensor calibration
2) Gap/Black Mark sensor calibra-
tion + self test and enter dump
mode
3) Printer Initialization
4) Set Black Mark sensor as media
sensor and calibrate the Black Mark
sensor
5) Set Gap sensor as Media Sensor
and calibrate the Gap sensor
Please call us at (866) 777-1360 with any questions regarding Black Mark, Gap Sen-
sor, or any other Power-On utilities.
This illuminates that the power is on and the device is ready to
use
This illuminates that the system is downloading data from the
PC to memory, or that the printer is paused
This illuminates that the system is clearing data from the printer
This illuminates printer head open or a cutter error
This illuminates a printing error, such as head open, paper jam,
ribbon empty, or memory error
Release button during the following flashing pattern:
Amber
(5 Blinks)
release
11
Description
(equal size to the last label printed)
Amber Green
Red
(5 Blinks) (5 Blinks)
release
release
Green/ Red/
Amber Amber
(5 Blinks) (5 Blinks)
release
release
