Systium Technologies 526EX Assembly Manual

Motherboard ready system 450w 80plus
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Assembly Guide
Model 526EX
450W 80PLUS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 526EX and is the answer not in the manual?

Questions and answers

Related Manuals for Systium Technologies 526EX

Summary of Contents for Systium Technologies 526EX

  • Page 1 Assembly Guide Model 526EX 450W 80PLUS...

  • Page 2: Declaration Of The Manufacturer Or Importer

    Systium Technologies makes no commitment to update nor to keep current the information contained in this document. No part of this document may be copied or reproduced in any form or by any means without prior written consent of Systium Technologies. † Third-party brands and trademarks are the property of their respective owners.

  • Page 3: Assembly Guide

    4fied technical Assembly Notes for Different Motherboards personnel only. All other areas and components of this The Model 526EX supports a number of different motherboards. A computer are considered user-accessible. number of the assembly step details are different for each specific motherboard.
  • Page 4 Refer to Figure 5. the computer system not meeting the product's EMC compliance. A 5.25" EMI shield is not supplied with the Model 526EX and must be ordered separately from Systium. Copyright © 2013, Systium® Technologies, LLC...

  • Page 5: Removing The Front Bezel

    NOTE of the I/O shield when pressing on the I/O shield. The Model 526EX system supports Motherboard with a variety of I/O bus slots. The instructions to install the adapters are the 4. Check that the I/O shield is fully inserted into the I/O same.
  • Page 6 MotherBoard Ready System • MODEL 526EX Removing the Bezel Filler Panels the shouldered 6-32 mounting screws supplied. Refer to Figure 10. To remove the peripheral filler panels push the mounting tabs toward each other to release the panel from the bezel. See Figure 8.
  • Page 7 Install Cover Lock Tab NOTE The Model 526EX utilizes a power supply with an Energy Hazard on FIGURE 15 the 12V circuit. Compliance with CE requires installation of the cover lock tab and a lock or the use of the 6-32 TORX screw to secure the top cover.

  • Page 8: Install The Top Cover

    MotherBoard Ready System • MODEL 526EX The Model 526EX utilizes a power supply with an Energy Hazard on FIGURE 17 the 12V circuit. Compliance with CE requires installation of the cover lock tab and a lock or the use of the 6-32 TORX screw supplied to secure the top cover.

  • Page 9: Power Up The System

    MotherBoard Ready System • MODEL 526EX Power up the System Connect the keyboard, mouse, monitor and any other required peripheral for the correct operation of the computer. Refer to the Model Guide for assistance in connecting the peripherals to the computer.

  • Page 10: Installing The Motherboard

    Refer to the Model 526 Assembly Guide for the suggested peripheral cable routing. HEATSINK INSTALLATION Install the CPU fan heatsink per instructions provided with the Intel Box set. Connect the heatsink fan power cable to the motherboard. Copyright © 2013, Systium® Technologies, LLC 526EX AIMB-567 AI Rev 1.0...
  • Page 11 HEATSINK INSTALLATION Install the CPU fan heatsink per instructions provided with the Intel Box set. Connect the heatsink fan power cable to the Copyright © 2013, Systium® Technologies, LLC 526EX AIMB-580 AI Rev 1.0...
  • Page 12 Refer to the Model 526E Assembly Guide for the suggested peripheral cable routing. HEATSINK INSTALLATION Install the CPU fan heatsink per instructions provided with the Intel Box set. Connect the heatsink fan power cable to the motherboard. Copyright © 2013, Systium® Technologies, LLC 526EX RX35Q AI Rev 1.0...
  • Page 13 Refer to the Model 526E Assembly Guide for the suggested peripheral cable routing. HEATSINK INSTALLATION Install the CPU fan heatsink per instructions provided with the Intel Box set. Connect the heatsink fan power cable to the motherboard. Copyright © 2013, Systium® Technologies, LLC 526EX RX45Q AI Rev 1.0...
  • Page 14 HEATSINK INSTALLATION Install the CPU fan heatsink per instructions provided with the Intel Box set. Connect the heat sink fan power cable to the motherboard. Copyright © 2013, Systium® Technologies, LLC 526EX RX67Q AI Rev 1.0...
  • Page 15 Refer to the Model 526E Assembly Guide for the suggested peripheral cable routing. HEATSINK INSTALLATION Install the CPU fan heatsink per instructions provided with the Intel Box set. Connect the heatsink fan power cable to the motherboard. Copyright © 2013, Systium® Technologies, LLC 526EX RX965QV AI Rev 1.0...
  • Page 16 Place the new heat sink mount on the motherboard. Attach the heat sink using the 4 built-in screws. Connect the heat sink fan power cable to the motherboard. Copyright © 2013, Systium® Technologies, LLC 526EX DH55TC AI Rev 1.0...
  • Page 17 Place the new heat sink mount on the motherboard. Attach the heat sink using the 4 built-in screws. Connect the heat sink fan power cable to the motherboard. Copyright © 2013, Systium® Technologies, LLC 526EX DQ67OW AI Rev 1.0...
  • Page 18 Place the new heat sink mount on the motherboard. Attach the heat sink using the 4 built-in screws. Connect the heat sink fan power cable to the motherboard Copyright © 2013, Systium® Technologies, LLC 526EX DQ67SW AI Rev 1.0...
  • Page 19 Place the new heat sink mount on the motherboard. Attach the heat sink using the 4 built-in screws. Connect the heat sink fan power cable to the motherboard. Copyright © 2013, Systium® Technologies, LLC 526EX DQ77MK AI Rev 1.0...
  • Page 20 Failure to have the insulator in place will result in the board not working. Connect Peripheral Cables FIGURE 1 Refer to the Model 526 Assembly Guide for the suggested peripheral cable routing. Copyright © 2013, Systium® Technologies, LLC 526EX BL330-BR AI Rev 1.0...
  • Page 21 Failure to have the insulator in place will result in the board not working. Connect Peripheral Cables FIGURE 1 Refer to the Model 526E Assembly Guide for the suggested peripheral cable routing. Copyright © 2013, Systium® Technologies, LLC 526EX EL330-DR AI Rev 1.0...
  • Page 22 CPU. • Insert the heat sink support bracket into the motherboard from the underside of the motherboard. • Connect the heat sink fan power cable to the motherboard. Copyright © 2013, Systium® Technologies, LLC 526EX MB330-CRM AI Rev 1.0...
  • Page 23 CPU. • Insert the heat sink support bracket into the motherboard from the underside of the motherboard. • Connect the heat sink fan power cable to the motherboard. Copyright © 2013, Systium® Technologies, LLC 526EX MB331-CRM AI Rev 1.0...
  • Page 24 Place the new heat sink mount on the motherboard. Attach the heat sink using the 4 built-in screws. Connect the heat sink fan power cable to the motherboard. Copyright © 2013, Systium® Technologies, LLC 526EX SB330-CRM AI Rev 1.0...
  • Page 25 Model 526EX regulatory compliance. One of the motherboards listed in the table below must be used with the Model 526EX. Use of any other motherboard will invalidate the Model 526EX regulatory compliance. The integrator must use the heat sink listed as required to ensure regulatory compliance. The table below was constructed using a CPU no greater than 95W TDP.
  • Page 26 Technical File is available upon request and signed NDA. The assembler/integrator assumes responsibility to maintain a CE compliant technical file on all Critical Components and on all Optional Components that were integrated into the Model 526EX to ensure compliance with the CE mark.
  • Page 27 REGULATORY INFORMATION A computer system, when correctly configured and assembled as instructed in this document, meets the following safety and EMC regulations. SAFETY COMPLIANCE UL 60950-1 Second Edition; CSA60950-1-07 Second Edition Amendment 1:2011 Information Technology Equipment - Safety - Part 1: General Requirements EN 60950- 1:2006/A11:2009/A1:2010/A12:2011;...
