AKX-CH(RS)-CH8-[AKX-CH7]-EN
AKX-CH7/AKX-CH7-4BAM/AKX-CH7-2WSS
DIRECTED SMARTSTART & ADS-HRN(RS)-SM01 (OPTIONAL)
notice
The manufacturer will accept no responsability for any electrical
damage resulting from improper installation of this product, be that either
damage to the vehicle itself or to the installed device. This device must be in-
stalled by a certified technician. Please review the Installation Guide carefully
before beginning any work.
U.S. Patent No. 8,856,780
Automotive Data Solutions Inc. © 2014
instaLL guiDe
Document numbeR
18803
Revision Date
20141209
FiRmwaRe
AKX-CH(RS)-CH8-[AKX-CH7]
haRDwaRe
accessoRies
ADS-USB (REQUIRED)
COMPATIBLE RF-KIT (OPTIONAL)
beFoRe instaLLation
1- Connect module to computer
2- Login to Weblink account
3- Flash firmware to module (module is not preloaded with firmware)
4- Use accessories accordingly (accessories are sold separately)
www.autokinetix.com
