- Page 1 PARALYSER 375 USER INSTRUCTIONS CYCL PS Proudly designed and engineered in Australia by Dynamco Pty Ltd.
- Page 2 CYCLOPS PARALYSER 375 User Instructions Congratulations on having one of the world's most advanced and unique Australian designed and engineered vehicle security systems, installed in your vehicle! The Cyclops Paralyser 375 has been tested to and meets Australian Standards 4601:1999.
-
Page 3: Arming And Disarming
ARMING AND DISARMING To arm or disarm the system, press the larger button on the remote control. Arming the system is accompanied by two flashes from the indicators and one flash for disarming. If the siren confirmation option is enabled the P375 will also “chirp” the siren twice for arming and once for disarming. PANIC If the larger button on the remote control is pressed and held down for more than two seconds the system will go into a panic mode. -
Page 4: Intrusion Detection
INTRUSION DETECTION The P375 is equipped with four zones of protection doors, bonnet, glass breakage & auxiliary. Each zone can be triggered a maximum of three times after arming. When a zone is triggered, the siren will sound for 30 seconds and the indicators will flash for one minute. - Page 5 This eliminates all false alarms. OPTIONS The PARALYSER 375 has a number of options than can be set or reset by means of the ignition switch and remote control. To change these options you need to do the following: Open and leave open the driver's door.
- Page 6 Disabled Enabled 15 Indicator disarm flash 1 second 10 seconds SPECIFICATIONS Manufactured by : Dynamco Pty Ltd. Model Number : Paralyser 375. Standards met : AS/NZS 4601:1999. Supply voltage : +12VDC. Current consumption : less than 10 mA (while armed).
-
Page 7: Battery Replacement
Insert new battery in identical fashion to the original and re-assemble remote. Replace screws and test remote control by pressing main button. For further information, please contact your local Cyclops service centre. Remote battery type 27a. - Page 8 OVERRIDE The system can be overridden by means of a Personal Identification Number (PIN). Every unit is supplied with its own PIN. It is important to make a note of this PIN or keep the card supplied with the unit in a safe p1ace as it also has the PIN detailed on it. ** Any digit marked '0', indicates 10 flashes.
-
Page 9: Problem Solving
PROBLEM SOLVING System won't activate when the door is opened - Make sure you have used the remote to set the system. It will not trigger if the system has auto armed. - Make certain the system is activated. LED should be flashing on the dashboard. - Make sure that the interior dome light has not been left in the permanently ON position. -
Page 10: Annual Inspection
ANNUAL INSPECTION Dynamco prides itself on the durability and integrity of its car security systems. We welcome users to contact a Cyclops service centre every twelve months for an annual inspection. (Please note a charge may be levied for this inspection) -
Page 11: Warranty
The product has been altered or tampered with in any way or the serial number altered, defaced or removed. The defect has been caused by negligence by the owner or their agent. The product has not been operated correctly, installed by an authorised Cyclops installer or has been subjected to misuse or undue wear and tear. -
Page 12: Warranty Registration
WARRANTY REGISTRATION CYCL PS PURCHASED FROM OWNER’S NAME TYPE OF VEHICLE VEHICLE REGO MODULE OF UNIT DATE OF INSTALL’ WARRANTY PERIOD : CONTROL MODULE REMOTES & SIREN AFTER HOURS EMERGENCY PHONE...
