Page 1: User Guide
USER GUIDE PoE & Optical Transmission Gigabit Ethernet PoE Switch... -
Page 2: Packing List
Statement Copyright @ 2002-2013 Optical Network Video Technologies (Shenzhen) Co., Ltd All Rights Reserved This document contains proprietary information that is protected by copyright. No part of this document may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise without the prior written permission of Optical Network Video Technologies (Shenzhen) Co., Ltd. -
Page 3: Product Overview
Product overview Product Introduction 10/100/1000M PoE switch can provide both 10/100/1000M Ethernet data and Power over network cable, it can be used as Ethernet Power Sourcing Equipment, it can automatically detect and identify whether connected devices such as IP camera comply with standard IEEE PoE 802.3af, 802.3at and supply power for them. 10/100/ 1000M PoE switch easier the deployment of Wireless AP, IP camera and IP-based network equipment. - Page 4 Technical Structure and Port Description 195mm 113mm LINK LINK 10 100 1000 M PoE Switch LINK 100M 10/100/1000M PoE Switch Power Over Ethernat Gigabit PoE Switch Power Over Ethernat Gigabit PoE Switch 44mm 36mm 1000M 185mm 279mm LINK LINK LINK AC/IN 100-240V AC 220V 50Hz Gigabit...
-
Page 5: Indicator Description
Working in 1000 rate mode Green LED ON Rate indicator: 1 00M Green LED OFF POE33064P Working in 10/100 rate mode Note Please confirm that the PD devices are complying with IEEE802.3af/at standard. Priority: this function will protect device when it is overload, if all PD consumption are higher than specified, switch port will be sorted by priority, port1, port2, port3, port N then power supply of lowest priority will be off. -
Page 6: Connection Diagram
Connection Diagram e rn G ig it P it c L IN... -
Page 7: Installation Guide
Installation guide Please install with the supporting devices. Installation Please confirm the following things before installation: 1 If the POE port power meet the power requirement of the connecting devices. 2 If the POE standard requirement and power supply match with the power receiving device, “1/2+、3/6- -span)/ 4/5+、7/8-( Mid-span). - Page 8 If there is enough space for heat sink; if the power socket is suitable for switch specification; if the power, switch and rack are properly grounded and if the connection between switch and other network equipments are normal. Tel:+86-755-33376606 Fax:+86-755-33376608 Email:onv@onv.com.cn Address: Room 1003, Block D , Tairan building , Chegongmiao, Futian district ,Shenzhen ,China www.onvcom.com...
