CALIFORNIA TRIMMER
MOWER MAINTENANCE MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Mower and is the answer not in the manual?

Questions and answers

Leonel Hernandez
April 28, 2025

Why is it that my California trimmer will not start up. I clean the gas tank and the carburetor, any suggestions?

0
1 comments:
Mr. Anderson
May 15, 2025

Based on the context, the likely reasons your California Trimmer mower won't stay running, even after cleaning the gas tank and carburetor, include:

1. Clogged or Dirty Carburetor: Even if cleaned, internal passages may still be partially blocked, preventing proper fuel flow.

2. Bad or Leaking Gasket: A failing carburetor gasket can cause air leaks, leading to poor fuel-air mixture and stalling when the choke is turned off.

3. Fuel Tank or Fuel Line Leak: If the tank or fuel line leaks or isn't sealed properly, it may prevent consistent fuel flow.

4. Improper Carburetor Installation: If the carburetor is not tightened correctly or aligned with the gasket, it can cause vacuum leaks.

5. Old or Contaminated Fuel: Even after cleaning, using old fuel can cause poor performance. Make sure to use fresh fuel.

Inspect the gasket, check for vacuum leaks, verify fuel flow, and ensure the carburetor is fully cleaned and properly installed.

This answer is automatically generated

0
Leonel Hernandez
April 28, 2025

why is it that my California trimmmer does not start up, even thought i cleaned the carburator and gas tank and put new gas, but will not starts why

0
1 comments:
Mr. Anderson
May 15, 2025

Based on the context, possible reasons your California Trimmer mower won't start after cleaning the carburetor and gas tank and adding new gas include:

1. Contaminated Fuel: You mentioned seeing small clippings in the tank. Even if it's not "overly" dirty, debris can clog fuel lines or the carburetor.

2. Oil Overfill or Fuel in Oil: Oil started coming out when you opened the dipstick, and you noticed a gas smell in the garage. This suggests fuel may have leaked into the oil, which can prevent the engine from starting.

To fix this, drain and replace the oil, ensure the fuel is clean, and check for any remaining blockages in the fuel system.

This answer is automatically generated

0

Related Manuals for California Trimmer Mower

Summary of Contents for California Trimmer Mower

  • Page 1 CALIFORNIA TRIMMER MOWER MAINTENANCE MANUAL...
  • Page 2 California Trimmer Mower Maintenance Manual...

  • Page 3: Table Of Contents

    Page Clutch Adjustment Reel Adjustment Roller Adjustment Roller Assembly Trouble Shooting “Reel won’t turn” “Mower won’t propel” Parts List and Mower Schematics Section 3: Commercial Models Page Clutch Reel Adjustment Roller Adjustment Drive Shaft Disassembly Drive Shaft Assembly Roller Assembly Trouble Shooting “Reel won’t turn”...

  • Page 4: Handle Assembly Instructions

    3/8” Wrench Flat-Blade Screw Driver Pliers w/cutters To determine Left or Right, position yourself in the operator’s position behind the mower. Handle Assembly Connect the bottom and top section of the handle using (4) each 5/16” bolts, washers and nylock nuts. Tighten using the two (2) 1/2” wrenches.
  • Page 5 3/8” Wrench Flat-Blade Screw Driver Pliers w/cutters To determine Left or Right, position yourself in the operator’s position behind the mower. Handle Assembly Connect the bottom and top section of the handle using (4) each 5/16” bolts, washers and nylock nuts. Tighten using the two (2) 1/2” wrenches.

  • Page 6: Mower Maintenance

    California Trimmer Mower Maintenance Manual Mower Maintenance Heavy Duty & Commercial Models...
  • Page 7 California Trimmer Mower Maintenance Manual Mower Maintenance Heavy Duty & Commercial Models Commercial Use – Daily Inspection 1. Check Engine oil level. The oil should be filled to the engine specifications (see engine owner’s manual) 2. Check air cleaner. Some Honda engines have an oil bath filter. Oil should be added to maintain optimum level.
  • Page 8 California Trimmer Mower Maintenance Manual Notes ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________...

  • Page 9: Oil Change Procedures - All Models

    However, the position of the engine on the frame does not offer easy access and can cause the old oil to pour onto the mower, requiring extra clean-up time. It is easier to remove the oil-fill plug. Tip the mower forward and pour oil into a can or plastic container.

  • Page 10: Height Adjustment All Models

    4 to 5 holes of the “quadrant” (no. 3). In either height range, moving the “height adjustment lever” (no. 2) towards the front of the mower will raise the height in small increments. Moving the “height adjustment lever” (no. 2) towards the back of the mower will lower the height in small increments.

  • Page 11: Catcher And Bale Adjustment All Models

    The “V” of the catcher bale is offset to one side, making one side shorter than the other. On 20 and 25 commercial mowers the short side goes to the left, as shown. On the Home Owner mower the short side goes to the right.
  • Page 12 California Trimmer Mower Maintenance Manual Notes ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________...

  • Page 13: Clutch Adjustment

    California Trimmer Mower Maintenance Manual Home Owner Model Clutch Adjustment Tools Required: 1/2” Wrenches 1/8” Allen wrench CAUTION: ALL ADJUSTMENT MUST BE MADE WITH THE ENGINE TURNED OFF. Step 1 With the clutch rod pointing down toward the engine in the engaged position (see above) the tip of the belt guard is just off the belt.
  • Page 14 California Trimmer Mower Maintenance Manual Home Owner Model Clutch Adjustment BRACKET SWIVEL BEARING BOTTOM PULLEY Step 2 With the clutch rod pointing up in the disengaged position (see above) make sure the idler bearing does not ride on the bottom pulley. The idler bearing should be within one quarter (1/4) of an inch from the bottom pulley.

  • Page 15: Reel Adjustment

    California Trimmer Mower Maintenance Manual Home Owner Model Cutter Bar to Reel Adjustment Tools Required: Adjustable Wrench or 1/4” Open-end Wrench CAUTION: ALL ADJUSTMENTS MUST BE MADE WITH THE ENGINE TURNED OFF. The reel on the Home Owner model is fixed and stationary to the frame. The cutter bar is adjusted to the reel.
  • Page 16 Slide a piece of thin paper, such as a page from a phone book or newspaper, at small intervals, all the way across the cutter bar to test for proper adjustment. When adjusted properly the paper will be cut cleanly and evenly across the entire width of the mower.
  • Page 17 California Trimmer Mower Maintenance Manual Home Owner Model Roller Adjustment Procedures Tools Required: 5/32” Allen Wrench 7/16” Wrench Screw Driver CAUTION: ALL ADJUSTMENTS MUST BE MADE WITH THE ENGINE TURNED OFF. Step 1 Loosen roller “U” Bolts and set screws on both sides of the drive roller. This will loosen the drive roller on the yoke.

  • Page 18: Roller Adjustment

    California Trimmer Mower Maintenance Manual Home Owner Model Roller Adjustment Procedures – (Continued) To Check Move the drive roller up, past the furthest most position and the drive chain will become slack on top. Move the drive roller down, past the furthest most position and the chain will become slack on the bottom.
  • Page 19 California Trimmer Mower Maintenance Manual Home Owner Model Roller Assembly Procedures Tools Required: 1/2” Wrench One end plate of the roller has three (3) holes and the other end plate has six (6) holes. Step 1 Starting with the end that has three (3) holes, bolt the bearing holder and bearing, using the bolts, lock washers and washers.

  • Page 20: Roller Assembly

    California Trimmer Mower Maintenance Manual Home Owner Model Roller Assembly Procedures – (Continued) Step 3 Place the sprocket spacers over the remaining three (3) holes. Install a “30 Tooth” sprocket using the bolts, lock washers and washers. Try to center the sprocket as much as possible.
  • Page 21 California Trimmer Mower Maintenance Manual Home Owner Model – Trouble Shooting “Reel doesn’t turn” TURN OFF ENGINE DISENGAGE CLUTCH DOES REEL TURN ADJUST REEL SEE FREELY BY HAND INSTRUCTIONS REMOVE CHAIN GUARDS START ENGINE & ENGAGE CLUTCH REPLACE SET IS ENGINE PULLEY...
  • Page 22 California Trimmer Mower Maintenance Manual Home Owner Model – Trouble Shooting “Reel doesn’t turn” – (Continued) REPLACE 8 TOOTH IS THE CHAIN SPROCKET. SEE TURNING? NOTE 2 IS DRIVESHAFT REPLACE TURNING? SEE DRIVESHAFT. SEE NOTE 1 NOTE 2 IS 17 TOOTH...

  • Page 23: Mower Won't Propel

    California Trimmer Mower Maintenance Manual Home Owner Model – Trouble Shooting “Mower won’t propel itself” TURN OFF ENGINE DISENGAGE CLUTCH DOES REEL TURN ADJUST REEL SEE FREELY BY HAND INSTRUCTIONS REMOVE CHAIN GUARDS START ENGINE & ENGAGE CLUTCH REPLACE SET...
  • Page 24 California Trimmer Mower Maintenance Manual Home Owner Model – Trouble Shooting “Mower won’t propel itself” – (Continued) REPLACE 8 TOOTH IS THE CHAIN SPROCKET. SEE TURNING? NOTE 2 IS DRIVESHAFT REPLACE TURNING? SEE DRIVESHAFT. SEE NOTE 1 NOTE 2 IS 8 TOOTH...
  • Page 25 Step 1 Tip the mower forward up onto the front part of the frame so that the handle is resting on a table or work bench. Or support the fuel tank with a block of wood or stand like pictured below.
  • Page 26 California Trimmer Mower Maintenance Manual Heavy Duty & Commercial Clutch Adjustment – (Continued) Clutch Adjustment Bolt Part # 25321 The clutch spring is held in place by two clutch forks that are connected by the clutch adjustment bolt. The clutch adjusting bolt has two nuts set together that hold the clutch forks and spring in position once it has been adjusted to the proper tension.
  • Page 27 California Trimmer Mower Maintenance Manual Heavy Duty & Commercial Clutch Adjustment – (Continued) The proper spacing for the clutch is about the thickness or a nickel or quarter. Press the drive sprocket over toward the large fork. The proper spacing can be gauged between the clutch lining and the drive sprocket.
  • Page 28 The reel bearing holders are off centered and mounted to the side plates of the frame with the reel-shaft hole toward the front to the mower at the 10 o’clock position on the left-hand side and the 2 o’clock position on the right-hand side or the mower.

  • Page 29: Reel Adjustment

    California Trimmer Mower Maintenance Manual Heavy Duty & Commercial Reel Adjustment – (Continued) Step 2 There two shoulders or “notch” studs on each reel bearing holder. Place the screw driver or metal punch on the notch stud and using the hammer tap the studs down in the front on one side, then the other. This moves the reel bearing holder, moving the reel blades down toward the cutter bar.
  • Page 30 California Trimmer Mower Maintenance Manual Heavy Duty & Commercial Reel Adjustment – (Continued) Step 3 Take a piece of thin paper, such as from a phone book or newspaper. Place a small part of the paper between the cutter bar and blade. Carefully turn the reel downward. If the blade and cutter bar are aligned properly, the paper will be cut evenly, across the length or the cutter bar.
  • Page 31 California Trimmer Mower Maintenance Manual Heavy Duty & Commercial Roller Adjustment Procedures Tools Required: 1/8” Allen Wrench Screw Driver 7/16” Wrenches CAUTION: ALL ADJUSTMENTS MUST BE MADE WITH THE ENGINE TURNED OFF. Step 1 Loosen roller “U” Bolts and set screws on both sides of the drive roller. This will loosen the drive roller on the yoke.

  • Page 32: Roller Adjustment

    California Trimmer Mower Maintenance Manual Heavy Duty & Commercial Roller Adjustment Procedures – (Continued) To Check Move the drive roller up, past the furthest most position and the chain will become slack on top. Move the drive roller down, past the furthest most position and the chain will become slack on the bottom. Make sure the bolt heads on the sprocket clear the yoke when it spins.

  • Page 33: Drive Shaft Disassembly

    Remove the two (2) set screws from the 17 tooth outer sprocket. Unbolt the bearing holders from the frame on both sides. Remove the drive shaft assembly from the mower frame. Using a pulley Puller, remove the bearing holder from the right side.

  • Page 34: Drive Shaft Assembly

    California Trimmer Mower Maintenance Manual Heavy Duty & Commercial Drive Shaft Assembly Tools Required: 5/32” Allen Wrench Bearing Setting Tool Needle Nose Pliers Hammer 1/2” Wrenches Spring Compression Tool Secure the drive shaft, either by inserting the short end of the drive shaft into a hole in your work bench or secure in a vice.
  • Page 35 California Trimmer Mower Maintenance Manual Heavy Duty & Commercial Drive Shaft Assembly – (Continued) Step 3 Install the 39 tooth sprocket. Make sure that it is clean and dry prior to installation. The 39 tooth sprocket should spin freely on the drive shaft. You may need to install a small amount of grease to the inside of the oilite bushing.
  • Page 36 California Trimmer Mower Maintenance Manual Heavy Duty & Commercial Drive Shaft Assembly – (Continued) Step 5 Install the clutch spring and set collar. Place the drive shaft in a vise, making sure to place a rag or cloth between the jaws of the vice and the drive shaft in order to prevent marring or scratching the surface of the drive shaft.
  • Page 37 California Trimmer Mower Maintenance Manual Heavy Duty & Commercial Drive Shaft Assembly – (Continued) To compress, slide the spring compression tool, in it’s contracted length, onto the drive shaft and tighten its two (2) set screws. Turn the bottom part of the spring compression tool until the desired measurement of the spring is achieved.
  • Page 38 Leave the two (2) set screws on the set collar loose until after the wheels have been installed.
  • Page 39 Drive Shaft Assembly – (Continued) Step 11 Install the assembled drive shaft into the mower frame. Bolt the bearing holder to the frame, on the left-side, or the clutch side of the drive shaft. Bolt the bearing holder to the frame on the other side.

  • Page 40: Roller Assembly

    California Trimmer Mower Maintenance Manual Heavy Duty & Commercial Roller Assembly Tools Required: Bearing Driver Hammer 1/2” Wrenches Step 1 Install one bearing holder with the bearing on one side of the roller shaft. One end plate on the roller is set deeper inside the roller than the other.
  • Page 41 California Trimmer Mower Maintenance Manual Heavy Duty & Commercial Roller Assembly – (Continued) Step 4 Install bolts, lock washers and washers. Tighten the bolts on both ends at this time. Make sure the roller spins freely. If the roller does not spin freely one or both of the bearings may be “locked”...
  • Page 42 California Trimmer Mower Maintenance Manual Notes ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________...
  • Page 43 California Trimmer Mower Maintenance Manual Heavy Duty & Commercial – Trouble Shooting “Reel doesn’t turn” TURN OFF ENGINE DISENGAGE CLUTCH DOES REEL TURN ADJUST REEL SEE FREELY BY HAND INSTRUCTIONS REMOVE CHAIN GUARDS START ENGINE & ENGAGE CLUTCH IS ENGINE...
  • Page 44 California Trimmer Mower Maintenance Manual Heavy Duty & Commercial – Trouble Shooting “Reel doesn’t turn” – (Continued) IS THE 17 TOOTH REPLACE SET SPROCKET SCREWS. SEE TURNING? NOTE 2 REPLACE 17 TOOTH SPROCKET. IS CHAIN TURNING? SEE NOTE 2 IS FRONT SPROCKET...

  • Page 45: Mower Won't Propel

    California Trimmer Mower Maintenance Manual Heavy Duty & Commercial – Trouble Shooting “Mower won’t propel itself” TURN OFF ENGINE DISENGAGE CLUTCH DOES REEL TURN ADJUST REEL SEE FREELY BY HAND INSTRUCTIONS REMOVE CHAIN GUARDS START ENGINE & ENGAGE CLUTCH IS ENGINE SPROCKET...
  • Page 46 California Trimmer Mower Maintenance Manual Heavy Duty & Commercial – Trouble Shooting “Reel doesn’t turn” – (Continued) IS THE 17 TOOTH REPLACE SET SPROCKET SCREWS. SEE TURNING? NOTE 2 REPLACE 17 TOOTH SPROCKET. IS CHAIN TURNING? SEE NOTE 2 IS FRONT SPROCKET...
  • Page 47 California Trimmer Mower Maintenance Manual Notes ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________...
