  • Page 1 Notebook PC Hardware User’s Manual E1825b / Dec 2004...

  • Page 2: Safety Statements

    Safety Statements Federal Communications Commission Statement This device complies with FCC Rules Part 15. Operation is subject to the following two conditions: • This device may not cause harmful interference, and • This device must accept any interference received, including interference that may cause undes- ired operation.

  • Page 3: Macrovision Corporation Product Notice

    Safety Statements Nordic Cautions (for Notebook PC with Lithium-Ion Battery) CAUTION! Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer’s instructions. (English) ATTENZIONE! Rischio di esplosione della batteria se sostituita in modo errato.
  • Page 4 Safety Statements Safety Statements The following safety precautions will increase the life of the Notebook PC. Follow all precautions and instructions. Except as described in this manual, refer all servicing to qualified personnel. Do not use damaged power cords, accessories, or other peripherals. Do not use strong solvents such as thinners, benzene, or other chemicals on or near the surface.

  • Page 5: Transportation Precautions

    Safety Statements Transportation Precautions To prepare the Notebook PC for transport, you should turn it OFF and disconnect all external periph- erals to prevent damage to the connectors. The hard disk drive’s head retracts when the power is turned OFF to prevent scratching of the hard disk surface during transport. Therefore, you should not transport the Notebook PC while the power is still ON.
  • Page 6 Safety Statements CTR 21 Approval (for Notebook PC with built-in Modem) Danish Dutch English Finnish French German Greek Italian Portuguese Spanish Swedish...

  • Page 7: Ul Safety Notices

    Safety Statements UL Safety Notices Required for UL 1459 covering telecommunications (telephone) equipment intended to be electrically connected to a telecommunication network that has an operating voltage to ground that does not exceed 200V peak, 300V peak-to-peak, and 105V rms, and installed or used in accordance with the National Electrical Code (NFPA 70).

  • Page 8: Table Of Contents

    Contents 1. Introducing the Notebook PC ..............11 About This User’s Manual ..................12 Notes For This Manual ..................12 Preparing your Notebook PC ................... 13 2. Knowing the Parts .................. 15 Top Side ........................16 Bottom Side ......................18 Right Side .........................
  • Page 9 Contents Instant Launch Keys and Status Indicators .............. 36 Instant Launch Keys .................... 36 Status Indicators (above keyboard) ..............37 Status Indicators (top cover) ................38 CD Player Control Buttons and Indicator............. 38 4. Using the Notebook PC ................. 41 Pointing Device ......................
  • Page 10 Contents Appendix ..................... 59 Optional Accessories ....................60 USB Hub (Optional) ..................... 60 USB 2.0 Slim Combo Drive (Optional) ..............60 Wireless LAN Cardbus Card or USB ..............61 USB Flash Memory Disk ..................61 USB Communication Cable ................. 61 USB Floppy Disk Drive ..................

  • Page 11: Introducing The Notebook Pc

    1. Introducing the Notebook PC About This User’s Manual Notes For This Manual Preparing your Notebook PC...

  • Page 12: About This User's Manual

    Introducing the Notebook PC About This User’s Manual You are reading the Notebook PC User’s Manual. This User’s Manual provides information on the various components in the Notebook PC and how to use them. The following are major sections of this User’s Manuals: 1.

  • Page 13: Preparing Your Notebook Pc

    Introducing the Notebook PC Preparing your Notebook PC These are only quick instructions for using your Notebook PC. Read the later pages for detailed infor- mation on using your Notebook PC. 1. Install the battery pack 2. Connect the AC Power Adapter 3.
  • Page 14 Introducing the Notebook PC...

  • Page 15: Knowing The Parts

    2. Knowing the Parts Top Side Bottom Side Right Side Left Side Rear Side Front Side...

  • Page 16: 2 Knowing The Parts

    Knowing the Parts Top Side Refer to the diagram below to identify the components on this side of the Notebook PC. Details are given starting from the top and going clockwise. Light Sensor Microphone Display Panel Status Indicators (see section 3) Power Switch / Instant Keys Keyboard Touchpad...

  • Page 17: Ambient Light Sensor

    Knowing the Parts Ambient Light Sensor Normally, changing light conditions require you to adjust the display brightness using the function keys. The light sensor, when activated using the keyboard function keys, can detect your environment’s ambient light and adjust the LCD panel’s brightness to compensate. Built-in Microphone The built-in mono microphone can be used for video conferencing, voice narrations, or simple audio recordings.

  • Page 18: Bottom Side

    Knowing the Parts Bottom Side Refer to the diagram below to identify the components on this side of the Notebook PC. Details are given starting from the top and going clockwise. (Air Vents) Compartment Mini-PCI Cooling Fan Compartment Shutdown Button Cooling Fan Optical drive Lock...

  • Page 19: Battery Lock

    Knowing the Parts Air Vents The air vents allow cool air to enter and warm air to exit the Notebook PC. IMPORTANT! Make sure that paper, books, clothing, cables, or other objects do not block any of the air vents or else overheating of the Notebook PC may occur. Mini-PCI Compartment Optional expansion cards can be installed in the mini-PCI compartment.

  • Page 20: Right Side

    Knowing the Parts Right Side Refer to the diagram below to identify the components on this side of the Notebook PC. Press here to lock module Audio Optical Drive Module Electronic Emergency Speaker (varies by model) Eject Eject Optical Drive The Notebook PC comes in various models with different optical drives.

  • Page 21: Left Side

    Knowing the Parts Left Side Refer to the diagram below to identify the components on this side of the Notebook PC. SPDIF/Phone 1394 Flash Memory PC Card Port Slot Output PC Card Eject Audio PC Card Audio Port Input Slot Speaker SPDIF Output Jack (SPDIF Output) This jack provides connection to SPDIF (Sony/Philips Digital Interface) compliant devices for digital...

  • Page 22: Rear Side

    Knowing the Parts Rear Side Refer to the diagram below to identify the components on this side of the Notebook PC. ® Power Display Kensington Input Output Lock Port Port TV-Out Port Air Vents Air Vents Modem Ports Port On selected models Air Vents The air vents allow cool air to enter and warm air to exit the Notebook PC.

  • Page 23: Lan Port

    Knowing the Parts ® Kensington Lock Port ® ® The Kensington lock port allows the Notebook PC to be secured using Kensington compatible Note- book PC security products. These security products usually include a metal cable and lock that prevent the Notebook PC to be removed from a fixed object.

  • Page 24: Front Side

    Knowing the Parts Front Side Refer to the diagram below to identify the components on the front side of the Notebook PC. CD Control Buttons (see section 3) Display Panel Latch Stereo Stereo Speaker Speaker Display Panel Latch A spring-loaded latch on the front of the Notebook PC locks the display panel in the closed position when the Notebook PC is not in use.

  • Page 25: Getting Started

    3. Getting Started Using the Battery Pack Operating Systems Power Connection Powering ON The Notebook PC Power Management Restarting or Rebooting Powering OFF The Notebook PC Using the Keyboard Instant Launch Keys and Status Indicators...

  • Page 26: 3 Getting Started

    Getting Started Using the Battery Pack Installing and Removing the Battery Pack Your Notebook PC may or may not have its battery pack installed. If your Notebook PC does not have its battery pack installed, use the following procedures to install the battery pack. IMPORTANT! Never attempt to remove the battery pack while the Notebook PC is turned ON, as this may result in the loss of working data.

  • Page 27: Battery Care

    Getting Started Charging the Battery Pack Before you use your Notebook PC on the road, you will have to charge the battery pack. The battery pack begins to charge as soon as the Notebook PC is connected to external power. Fully charge the battery pack before using it for the first time.

  • Page 28: Power Connection

    Getting Started Power Connection Your Notebook PC comes with a universal AC-DC adapter. That means that you may connect the power cord to any 100V-120V as well as 220V-240V outlets without setting switches or using power converters. Different countries may require that an adapter be used to connect the provided US-standard AC power cord to a different standard.

  • Page 29: Powering On The Notebook Pc

    Getting Started Powering ON The Notebook PC The Notebook PC’s power-ON message appears on the screen when you turn it ON. If necessary, you may adjust the brightness by using the hot keys. If you need to run the BIOS Setup to set or modify the system configuration, press [F2] upon bootup to enter the BIOS Setup.

  • Page 30: Power Management - "Stand By" & "Hibernate

    Getting Started Power Management - “Stand By” & “Hibernate” Power management settings can be found in the Windows control panel. The following shows the power options properties in Windows. You can define “Stand By” or “Shut down” for closing the display panel, pressing the power button, or activating sleep mode.

  • Page 31: Restarting Or Rebooting

    Getting Started Restarting or Rebooting After making changes to your operating system, you may be prompted to restart the system. Some installation processes will provide a dialog box to allow restart. To restart the system manually: Click the Start button and select Shut Down | and choose Restart. In case the operating system hangs (stops, freezes, crashes), try a “warm boot”...

  • Page 32: Powering Off The Notebook Pc

    Getting Started Powering OFF the Notebook PC In Windows XP, the Notebook PC can be powered OFF by using Start | Shut Down... | Turn off (or Shut down). For operating systems without proper power management (DOS, Windows NT), you must power OFF the Notebook PC by holding the power switch for 2 seconds (as opposed to 1 second to power ON) after closing applications and exiting operating systems.

  • Page 33: Using The Keyboard

    Getting Started Using the Keyboard Colored Hot Keys The following defines the colored hot keys on the Notebook PC’s keyboard. The colored commands can only be accessed by first pressing and holding the function key while pressing a key with a colored command. NOTE: The Hot Key locations on the function keys may vary depending on model but the functions should remain the same.

  • Page 34: Microsoft Windows™ Keys

    Getting Started Microsoft Windows™ Keys There are two special Windows™ keys on the keyboard as described below. The key with the Windows™ Logo activates the Start menu located at the bottom left of the Windows™ desktop. The other key, that looks like a Windows™ menu with a small cursor, activates the properties menu and is equivalent to pressing the right mouse button on a Windows™...

  • Page 35: Keyboard As Cursors

    Getting Started Keyboard as Cursors The keyboard can be used as cursors while Number Lock is ON or OFF in order to increase navigation ease while entering numeric data in spreadsheets or similar applications. With Number Lock OFF, press and one of the cursor keys shown below. For example [Fn][8] for up, [Fn][K] for down, [Fn][U] for left, and [Fn][O] for right.

  • Page 36: Instant Launch Keys And Status Indicators

    Getting Started Instant Launch Keys and Status Indicators Instant Launch Keys Email Launch Key Pressing this button will launch your Email application while Windows is running. Internet Launch Key Pressing this button will launch your Internet browser application while Windows is running. Wireless LAN Indicator (Optional) This indicator is only applicable on models with internal wireless LAN.

  • Page 37: Status Indicators (Above Keyboard)

    Getting Started Status Indicators (above keyboard) Battery Charge Indicator The battery charge indicator is an LED that shows the status of the battery’s power as follows: ON: The Notebook PC’s battery is charging Off: The Notebook PC’s battery is charged or completely drained Email Indicator Flashes when there is one or more new email(s) in your email program’s inbox.

  • Page 38: Status Indicators (Top Cover)

    Getting Started Status Indicators (top cover) Power Indicator The green LED lights to indicate that the Notebook PC is turned ON and blink when the Notebook PC is in the Suspend-to-RAM (Standby) mode. This LED is OFF when the Notebook PC is OFF or in the Suspend-to-Disk (Hibernation) mode.

  • Page 39: Cd Player Control Buttons And Indicator

    Getting Started CD Player Control Buttons and Indicator There are several CD control buttons integrated externally on the Notebook PC for convenient CD playing. The buttons activate and control your operating system’s audio player when the Notebook PC is ON. When your Notebook PC is OFF, the CD control buttons activate a CD player function that allows you to listen to audio CDs even while the Notebook PC is not turned ON.
  • Page 40 Getting Started...

  • Page 41: Using The Notebook Pc

    4. Using the Notebook PC Pointing Device Optical Drive Flash Memory Card Reader PC Card (PCMCIA) Socket Modem and Network Connections IR Wireless Communication AC Power System Battery Power System Power Management Modes Notebook PC Upgrades...

  • Page 42: 4 Using The Notebook Pc

    Using the Notebook PC Pointing Device The Notebook PC’s integrated touchpad pointing de- vice is fully compatible with all two/three-button and scrolling knob PS/2 mice. The touchpad is pressure sen- Cursor sitive and contains no moving parts; therefore, mechani- Movement cal failures can be avoided.

  • Page 43: Touchpad Usage Illustrations

    Using the Notebook PC Touchpad Usage Illustrations Clicking/Tapping - With the cursor over an item, press the left button or use your fingertip to touch the touchpad lightly, keeping your finger on the touchpad until the item is selected. The selected item will change color.

  • Page 44: Caring For The Touchpad

    Using the Notebook PC Dragging - Dragging means to pick up an item and place it anywhere on the screen you wish. You can move the cursor over the item you select, and while keeping the left button depressed, moving the cursor to the desired location, then release the button.

  • Page 45: Optical Drive

    Using the Notebook PC Optical Drive Inserting an optical disc 1. While the Notebook PC’s power is ON, 2. Gently pull on the drive’s front panel and slide press the drive’s eject button and the tray the tray completely out. Be careful not to touch will eject out partially.

  • Page 46: Removing An Optical Disc

    Using the Notebook PC Optical Drive (Cont’) Removing an optical disc 1. While the Notebook PC’s power is ON, press 2. Gently pry the edge of the disc upwards at an the drive’s eject button and the tray will eject angle to remove the disc from the hub.

  • Page 47: Pc Card (Pcmcia) Socket

    Using the Notebook PC PC Card (PCMCIA) Socket The Notebook PC supports PC Cards (or sometimes referred to as PCMCIA cards) to allow expansion like PCI cards on desktop computers. This allows you to customize your Notebook PC to meet a wide range of application needs.

  • Page 48: Removing A Pc Card (Pcmcia)

    Using the Notebook PC Inserting a PC Card (PCMCIA) Be sure the PC card is level when inserting. 1. If there is a PC Card socket protector, remove it 3. Carefully connect any cables or adapters using the “Removing a PC Card” instructions needed by the PC card.

  • Page 49: Flash Memory Card Reader

    Using the Notebook PC Flash Memory Card Reader Normally a PCMCIA memory card reader must be purchased separately in order to use memory cards from devices such as digital cameras, MP3 players, mobile phones, and PDAs. This Notebook PC has a single built-in memory card reader that can read the following flash memory cards: Secure Digital (SD), Multi-Media Card (MMC), Memory Stick (MS), Memory Stick Select (MS Select), Memory Stick Duo (with MS adapter), Memory Stick Pro, and Memory Stick Pro Duo (with MS Pro adapter).

  • Page 50: Modem Connection

    Using the Notebook PC Modem and Network Connections The built-in modem and network model comes with both an RJ-11 and an RJ-45 port. RJ-11 telephone cables have two or four wires and are used to connect telephones to telephone outlets found in the walls of residential homes and some commercial buildings (some commercial buildings may have telephone wir- ing designed for dedicated phone systems that may not be compatible).
  • Page 51 Using the Notebook PC Modem Connection The telephone wire used to connect the Notebook PC’s internal modem should have either two or four wires (only two wires (telephone line #1) is used by the modem) and should have an RJ-11 connector on both ends.

  • Page 52: Network Connection (100/10 Base)

    Using the Notebook PC Network Connection (100/10 Base) Connect a network cable, with RJ-45 connectors on each end, to the modem/network port on the Note- book PC and the other end to a hub or switch. For 100/10BASE-TX speeds, your network cable must be category 5 or better (not category 3) with twisted-pair wiring.

  • Page 53: Ac Power System

    Using the Notebook PC AC Power System The Notebook PC power is comprised of two parts, the power adapter and the battery power system. The power adapter converts AC power from a wall outlet to the DC power required by the Notebook PC.

  • Page 54: Using Battery Power

    Using the Notebook PC Using Battery Power A fully-charged battery pack provides the Notebook PC a few hours of working power. But the actual figure varies depending on how you use the power saving features, your general work habits, the CPU, system memory size, and the size of the display panel.

  • Page 55: Power Management Modes

    Using the Notebook PC Power Management Modes The Notebook PC has a number of automatic or adjustable power saving features that you can use to maximize battery life and lower Total Cost of Ownership (TCO). You can control some of these fea- tures through the Power menu in the BIOS Setup.

  • Page 56: Power State Summary

    Using the Notebook PC Power State Summary STATE ENTRY EVENT EXIT EVENT “Stand by” • “Stand by” through Windows Start button, • Any device • Timer as set though “Power Management” • Battery low in Windows Control Panel (higher priority) STR (“Stand by”) •...

  • Page 57: Notebook Pc Upgrades

    Using the Notebook PC Notebook PC Upgrades System Memory Expansion Additional memory will increase application performance by decreasing hard disk access. This is more noticeable on newer software that require more and more system resources. The BIOS automatically detects the amount of memory in the system and configures CMOS accordingly during the POST (Power-On-Self-Test) process.
  • Page 58 Using the Notebook PC...

  • Page 59: Appendix

    Appendix Optional Accessories Optional Connections Internal Modem Compliancy Glossary Notebook PC Information...

  • Page 60: Optional Accessories

    Appendix Optional Accessories These items, if desired, come as optional items to complement your Notebook PC. USB Hub (Optional) Attaching an optional USB hub will increase your USB ports and allow you to quickly connect or disconnect many USB peripherals through a single cable. USB 2.0 Slim Combo Drive (Optional) The slim combo drive features FlextraLink™...

  • Page 61: Wireless Lan Cardbus Card Or Usb

    Appendix Optional Accessories (Cont.) These items, if desired, come as optional items to complement your Notebook PC. Wireless LAN Cardbus Card or USB The SpaceLink™ Cardbus Card is a dual band (IEEE 802.11a/b) wireless LAN adapter that fits into a Notebook PC’s PCMCIA Type II slot with Cardbus support. The USB version is single band (IEEE 802.11b) but supports any computer (Notebook or Desktop) with a USB port.

  • Page 62: Usb Floppy Disk Drive

    Appendix Optional Accessories (Cont.) These items, if desired, come as optional items to complement your Notebook PC. USB Floppy Disk Drive The Notebook PC features an optional USB-interface disk drive that accepts a standard 1.44MB (or 720KB) 3.5-inch floppy diskette. The eject button is on the top edge of the floppy disk drive for easy access, unlike desktop PCs with the eject button on the bottom of the floppy disk drive.

  • Page 63: Optional Connections

    Appendix Optional Connections These items, if desired, may be purchased from third-parties. Monitor Out Connection Attaching an optional VGA/LCD monitor is just like that of a standard desktop PC (some configu- rations may require additional display driver set- tings. You can view the Notebook PC display panel while simultaneously allowing others to view the external monitor.

  • Page 64: Securing Your Notebook Pc

    Appendix Optional Connections (Cont.) These items, if desired, may be purchased from third-parties. IEEE1394 Connection 1394 is a high speed serial bus like SCSI but has simple connections and hot-plugging capabilities like USB. Up to 63 devices such as hard disk drives, scanners, removable drives, and digital cameras/ video cameras with an 1394 port can all be con- nected (more 1394 devices can be connected us-...

  • Page 65: Dvd-Rom Drive Information

    Appendix DVD-ROM Drive Information The Notebook PC comes with an optional DVD-ROM drive or a CD-ROM drive. In order to view DVD titles, you must install your own DVD viewer software. Optional DVD viewer software may be purchased with this Notebook PC. The DVD-ROM drive allows the use of both CD and DVD discs. Regional Playback Information Playback of DVD movie titles involves decoding MPEG2 video, digital AC3 audio and decryption of CSS protected content.

  • Page 66: Internal Modem Compliancy

    Appendix Internal Modem Compliancy The Notebook PC with internal modem model complies with JATE (Japan), FCC (US, Canada, Korea, Taiwan), and CTR21. The internal modem has been approved in accordance with Council Decision 98/ 482/EC for pan-European single terminal connection to the public switched telephone network (PSTN). However due to differences between the individual PSTNs provided in different countries, the approval does not, of itself, give an unconditional assurance of successful operation on every PSTN network termination point.
  • Page 67 Appendix This table shows the countries currently under the CTR21 standard. Country Applied More Testing Austria Belgium Czech Republic Not Applicable Denmark Finland France Germany Greece Hungary Not Applicable Iceland Ireland Italy Still Pending Still Pending Israel Lichtenstein Luxemburg The Netherlands Norway Poland Not Applicable...

  • Page 68: Glossary

    Appendix Glossary ACPI (Advanced Configuration and Power Management Interface) Modern standard for reducing power usage in computers. APM (Advanced Power Management) Modern standard for reducing power usage in computers. AWG (American Wire Gauge) Gauge Diam Area I@3A/mm2 Gauge Diam Area I@3A/mm2 (mm) (mm2) (ohm/km) (mA)
  • Page 69 Appendix BIOS (Basic Input/Output System) BIOS is a set of routines that affect how the computer transfers data between computer components, such as memory, disks, and the display adapter. The BIOS instructions are built into the computer’s read-only memory. BIOS parameters can be configured by the user through the BIOS Setup program. The BIOS can be updated using the provided utility to copy a new BIOS file into the EEPROM.
  • Page 70 Appendix DVD is essentially a bigger, faster CD that can hold video as well as audio and computer data. With these capacities and access rates, DVD discs can provide you with dramatically-enhanced high-color, ® full-motion videos, better graphics, sharper pictures, and Dolby Digital Surround for a theater-like experience.
  • Page 71 Appendix Laser Classifications As lasers became more numerous and more widely used, the need to warn users of laser hazards be- came apparent. To meet this need, laser classifications were established. Current classification levels vary from optically safe, requiring no controls (Class 1) to very hazardous, requiring strict controls (Class 4).
  • Page 72 Appendix POST (Power On Self Test) When you turn on the computer, it will first run through the POST, a series of software-controlled diagnostic tests. The POST checks system memory, the motherboard circuitry, the display, the key- board, the diskette drive, and other I/O devices. RAM (Random Access Memory) There are several different types of RAM such as DDR (Double Dynamic RAM), DRAM (Dynamic RAM), EDO DRAM (Extended Data Output DRAM), SDRAM (Synchronous DRAM).
  • Page 73 Appendix...

  • Page 74: Notebook Pc Information

    Appendix Notebook PC Information This page is provided for recording information concerning your Notebook PC for future reference or for technical support. Keep this User’s Manual in a secured location if passwords are filled out. Owner’s Name: __________________________ Owner’s Telephone: ________________ Manufacturer: ______________________________________ Model: ________________ Retailer: ______________________________________ Telephone: ________________ Display Size: _________ Purchase Date: _________ Serial Number: ________________...
