SECTION I: TANK INSTALLATION
2.2 Tank connection points
1
A
EHP
F
ITEM DESCRIPTION
1 TPR valve
2 Motorised valve
3 Thermal cutout
4 Motorised valve
5 Solar pump and control
6 VELUX
See diagram in section 1, paragraph 2.8
For connection of the discharge pipe work.
WW
HW
FH
Z
HR
SV/SR
FS
KW
INSTRUCTION
Factory fitted
See paragraph 2.4
Factory fitted
See paragraph 2.4
See section l & ll
2
Boiler circuit
3
Boiler circuit
See diagram in section l, paragraph 2.1
For connection of unvented kit components
to the cold water inlet.
Collectur circuit
4
5
